Manhattan 130554 Smart Video Multiport Dock - 5-Port HDMI - USB-A - USB-C with 45W Power Delivery - Ultra-Compact Design
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This docking station features a total of five ports: one HDMI output, two USB-A ports, and two USB-C ports. The USB-C configuration includes one port with Power Delivery up to 45W for charging compatible devices and another standard USB-C port operating at 5V/1A for data transfer.
The dock supports a range of display resolutions, including 1920x1080 (Full HD), 1920x1200 (WUXGA), and lower legacy resolutions for broad compatibility. It connects via a USB Type-C host interface, requiring no external software for basic functionality across supported operating systems.
Relevant factors for this section include Connectivity Technology, Supported Resolutions, Device Supported, Host Interface. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Manhattan 130554 combines high-performance connectivity with exceptional portability, making it an ideal solution for mobile professionals and hybrid work environments. Its design prioritizes both functionality and compact form factor.
Versatile Port Expansion
Adds HDMI video output, two USB-A ports, and two USB-C ports to any compatible USB-C device, enabling simultaneous display, data transfer, and charging.
- HDMI output for external displays
- Multiple USB-A and USB-C data ports
- 45W Power Delivery for device charging
Ultra-Compact Design
With dimensions of just 3.14" deep and weighing only 7.62 oz, this dock maintains a minimal footprint while delivering full connectivity capabilities.
- Portable enough for daily transport
- Minimal desk space requirements
- Lightweight construction
Deployment / Use Cases
The Manhattan 130554 Smart Video Multiport Dock serves multiple roles in modern computing environments, from basic peripheral expansion to complete mobile workstation setups.
Its combination of video output, data transfer capabilities, and device charging makes it particularly valuable for professionals who need to quickly adapt their mobile devices to different work scenarios.
Mobile Presentation Setup
Connect a notebook or smartphone to projectors or conference room displays via HDMI while simultaneously charging the device and connecting presentation peripherals.
- HDMI output for external displays
- 45W Power Delivery keeps devices charged
- Multiple USB ports for clickers and storage
Compact Desktop Expansion
Transform a minimal notebook setup into a full workstation with external display support, peripheral connections, and reliable power delivery in an ultra-compact form factor.
- Extended desktop capabilities
- Peripheral connectivity
- Space-efficient design
Physical Profile
Designed for maximum portability, the Manhattan 130554 measures just 1.18" H x 2.48" W x 3.14" D (29.97 x 62.99 x 79.76 mm) and weighs only 7.62 oz (216 g). Its compact dimensions make it easy to transport in laptop bags or briefcases while maintaining robust connectivity capabilities.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.18" (29.97 mm), 2.48" (62.99 mm), 3.14" (79.76 mm), 7.62 oz (216 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 2.48" (62.99 mm)
- Depth
- 3.14" (79.76 mm)
- Height
- 1.18" (29.97 mm)
- Weight
- 7.62 oz (216 g)
Highlights
- 5-port expansion hub with HDMI, USB-A, and USB-C connectivity
- 45W Power Delivery via USB-C for charging compatible devices
- Supports display resolutions up to 1920x1200 (WUXGA)
- Ultra-compact design at just 3.14" deep and 7.62 oz weight
- Plug-and-play operation with Windows and macOS systems
- Internal power supply for reliable performance
- RoHS compliant and environmentally friendly construction
- 3-year limited warranty for peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | IC INTRACOM |
| Manufacturer Part Number | 130554 |
| Brand Name | Manhattan |
| Product Model | 130554 |
| Product Name | Smart Video Power Delivery Charging Hub |
| Product Type | Docking Station |
| Technical Information | |
| Connectivity Technology | Wired |
| Supported Resolutions | 1920 x 1080,1920 x 1200,1024 x 768,800 x 600,640 x 480 |
| Device Supported | Smartphone,Notebook |
| Interfaces/Ports | |
| Host Interface | USB Type C |
| Total Number of USB Ports | 4 |
| USB Type-C | Yes |
| USB Type-C Detail | One USB-C Power Delivery Port up to 45 W, One USB-C Port up to 5 V/1 A |
| Number of HDMI Outputs | 1 |
| HDMI | Yes |
| Software | |
| Operating System Supported | Windows,macOS |
| Power Description | |
| Maximum Power Supply Wattage | 45 W |
| Physical Characteristics | |
| Height | 1.18" (29.97 mm) |
| Width | 2.48" (62.99 mm) |
| Depth | 3.14" (79.76 mm) |
| Weight (Approximate) | 7.62 oz (216 g) |
| Miscellaneous | |
| Package Contents | Smart Video Power Delivery Charging Hub 1.8 m (6 ft.) Power Cord 0.5 m (1.5 ft.) USB-C Male to USB-C Male Cable Quick Instruction Guide |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What devices are compatible with this docking station?
The Manhattan 130554 Smart Video Multiport Dock supports smartphones and notebooks with USB-C connectivity. It's compatible with both Windows and macOS operating systems, providing plug-and-play functionality without requiring additional drivers for basic operation.
What display resolutions does this dock support?
This docking station supports resolutions up to 1920x1200 (WUXGA), including 1920x1080 (Full HD), 1024x768, 800x600, and 640x480. This range ensures compatibility with modern displays while maintaining support for legacy monitor configurations.
How does the Power Delivery feature work?
One of the USB-C ports provides up to 45W of Power Delivery, enabling charging of compatible devices while connected. The other USB-C port operates at 5V/1A for data transfer, allowing simultaneous charging and data connectivity through separate dedicated ports.
What is included in the package?
The package contains the Smart Video Power Delivery Charging Hub, a 1.8 meter (6 foot) power cord, a 0.5 meter (1.5 foot) USB-C Male to USB-C Male cable for host connection, and a quick instruction guide for setup and operation.
Does this docking station require external software or drivers?
No external software or drivers are required for basic functionality. The dock operates as a plug-and-play device with both Windows and macOS systems, though optimal performance may benefit from keeping host device operating systems updated to their latest versions.
What are the physical dimensions and weight of this dock?
The Manhattan 130554 measures 1.18 inches in height, 2.48 inches in width, and 3.14 inches in depth (29.97 x 62.99 x 79.76 mm). It weighs just 7.62 ounces (216 grams), making it exceptionally portable for mobile professionals who need connectivity on the go.
