Minuteman EC2000RT2U Encompass 2000VA Double Conversion Online UPS - 2U Rack/Tower - 120V AC - 1. 80kW/2kVA - 3 Minute Runtime
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This double conversion online UPS continuously converts incoming AC power to DC and back to AC, providing complete isolation from utility power issues. It accepts a 120V AC input with a wide range of 0-160V AC, delivering a regulated 120V AC sine wave output. The 2 kVA/1.80 kW capacity supports substantial loads, with a 3-minute runtime at full load to facilitate safe shutdowns or bridge short outages.
The electrical design includes automatic voltage regulation (AVR) to correct minor fluctuations without switching to battery, extending battery life. The pure sine wave output is compatible with active PFC power supplies found in modern servers and networking gear, preventing potential compatibility issues and ensuring optimal performance.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The EC2000RT2U combines high capacity, flexible installation, and robust protection in a single unit. Its double conversion topology offers the highest level of power conditioning, making it ideal for environments where power quality is critical.
Maximum Power Protection
Double conversion technology ensures zero transfer time to battery and complete isolation from input anomalies, providing the cleanest possible power to connected equipment.
- Pure sine wave output
- Full isolation from utility power
- AVR for minor corrections
Deployment Flexibility
The 2U rack/tower design adapts to various spaces, from crowded server racks to office floors. Hot-swappable batteries allow for easy maintenance without interrupting protected loads.
- 2U rack height
- Tower or rack mounting
- Hot-swappable battery
Connectivity & Efficiency
Six NEMA 5-15/20R outlets support multiple devices, while Energy Star certification confirms energy-efficient operation, reducing operational costs over time.
- 6 outlets
- NEMA 5-20P plug
- Energy Star certified
Deployment / Use Cases
This UPS is specifically suited for protecting network infrastructure and security systems where uninterrupted operation is non-negotiable. Its 3-minute runtime at full load provides a critical window for executing graceful shutdowns or riding out brief power disturbances.
In network closets, it can safeguard switches, routers, and access points. For security systems, it ensures cameras, NVRs, and access control panels remain online during outages. The unit's robust 1.80kW capacity also makes it a fit for small server nodes or telecom equipment that requires clean, reliable power.
Network Infrastructure Protection
Ideal for switches, routers, and firewalls in closets or small server rooms, ensuring network continuity during power events.
Security & Surveillance Systems
Keeps cameras, recorders, and access control panels operational to maintain security coverage when utility power fails.
Physical Profile
The UPS measures 3.50" in height, 18.90" in width, and occupies 2U of rack space, making it a compact solution for standard 19-inch racks. Its approximate weight of 44.10 lb reflects a solid construction with internal batteries. The rack/tower form factor includes hardware for both installation methods, offering versatility whether you need to conserve rack space or prefer a standalone tower setup. The design prioritizes serviceability with accessible components for maintenance.
- Width
- 18.90" (480.06 mm)
- Height
- 3.50" (88.90 mm)
- Weight
- 44.10 lb (20003.42 g)
What's in the Box
The package includes the Minuteman Encompass EC2000RT2U 2000VA Tower/Rack Mountable UPS unit with its internal battery, ready for installation. All necessary mounting hardware for rack or tower deployment is included.
Highlights
- 2000VA/1.80kW double conversion online UPS for maximum power protection
- 2U rack/tower form factor with flexible installation options
- 3-minute runtime at full load for safe shutdowns
- 120V AC input and output with pure sine wave
- 6 x NEMA 5-15/20R outlets for multiple device connections
- Hot-swappable battery for maintenance without downtime
- Energy Star certified for energy efficiency
- 3-year limited warranty for long-term reliability
- RoHS 2 compliant and environmentally friendly
- Ideal for network closets, security systems, and critical IT loads
Specifications
| Specifications | |
|---|---|
| Manufacturer | Para Systems, Inc |
| Manufacturer Part Number | EC2000RT2U |
| Brand Name | Minuteman |
| Product Line | Encompass |
| Product Model | EC2000RT2U |
| Product Name | Encompass EC2000RT2U 2000VA Tower/Rack Mountable UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type | NEMA 5-15/20R |
| Receptacle Detail | 6 x NEMA 5-15/20R |
| Application/Usage | Network Closet,Security System,Network |
| Power Description | |
| Load Capacity (VA) | 2 kVA |
| Load Capacity (Watt) | 1.80 kW |
| Input Voltage | 120 V AC |
| Input Voltage Range | 0 V AC - 160 V AC |
| Output Voltage | 120 V AC |
| Waveform Type | Sine Wave |
| Battery Information | |
| Backup/Run Time (Full Load) | 3 Minute |
| Hot Swappable | Yes |
| Physical Characteristics | |
| Height | 3.50" (88.90 mm) |
| Width | 18.90" (480.06 mm) |
| Rack Height | 2U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 44.10 lb (20003.42 g) |
| Miscellaneous | |
| Package Contents | Encompass EC2000RT2U 2000VA Tower/Rack Mountable UPS Battery |
| Energy Star | Yes |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2 |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this Minuteman UPS?
The Minuteman EC2000RT2U has a load capacity of 2 kVA (2000 VA) or 1.80 kW. This rating indicates the maximum apparent power and real power it can support, making it suitable for protecting substantial IT equipment like network switches, servers, or security system components during power outages or fluctuations.
How long will this UPS run at full load?
At full load (1.80 kW), this UPS provides a backup runtime of 3 minutes. This duration offers a critical window to save work and perform graceful shutdowns of connected equipment, or to bridge very short utility power interruptions, ensuring operational continuity in network closets and security applications.
Can this UPS be installed in a server rack?
Yes, the EC2000RT2U is designed for both rack and tower installation. It has a 2U rack height, meaning it occupies two rack units (3.5 inches) in a standard 19-inch rack. The unit includes the necessary hardware for secure rack mounting, and its form factor is explicitly listed as Rack/Tower for deployment flexibility.
What type of power output does this UPS provide?
This UPS provides a pure sine wave output at 120V AC. A pure sine wave is the cleanest form of AC power, identical to utility power, which ensures compatibility with sensitive electronics, including servers with active PFC power supplies. This prevents potential damage or instability that can occur with simulated sine wave outputs.
How many devices can I connect to this UPS?
The UPS features 6 NEMA 5-15/20R receptacles, allowing you to connect up to six devices directly. These outlets support both standard 5-15P and 5-20P plugs. The unit itself uses a NEMA 5-20P plug to connect to your wall outlet, providing a robust connection for its 1.80kW capacity.
What is the warranty for this Minuteman UPS?
The Minuteman Encompass EC2000RT2U comes with a 3-year limited warranty from the manufacturer. This warranty covers defects in materials and workmanship, providing assurance of the product's reliability and durability for critical power protection applications over an extended period.
What power capacity is listed for this UPS?
The listed power specification is 2 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 120 V AC, which helps position the unit for the right load level and installation role.
