Netgear GS728TPP-300NAS ProSafe 24-Port Gigabit PoE+ Managed Switch - 4 SFP Slots - 720W PoE Budget - Layer 4 - Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates as a full Gigabit Ethernet platform, supporting network technologies 10/100/1000Base-T and 1000Base-X across all ports. The 24 RJ-45 ports are IEEE 802.3af/at compliant, delivering PoE+ power to connected devices, while the 4 dedicated SFP slots enable fiber optic connectivity for extended distance runs or high-bandwidth backbone links.
Layer 4 switching capabilities provide advanced traffic classification and bandwidth management, essential for multi-tenant or multi-department deployments. The switch complies with a comprehensive suite of IEEE networking standards, including 802.1Q for VLANs, 802.1x for port-based authentication, 802.3ad for link aggregation, and 802.3az for energy-efficient Ethernet.
Relevant factors for this section include Total Number of Network Ports, Uplink Port, Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The GS728TPP-300NAS combines high-density PoE deployment with professional-grade management in a single rack-optimized unit. Its 720W power budget allows simultaneous support of numerous power-hungry devices without external injectors, simplifying cabling and reducing total cost of ownership.
High-Power PoE+ Ready
All 24 RJ-45 ports deliver IEEE 802.3at PoE+ power, supporting devices requiring up to 30W per port. The 720W total budget ensures ample power for modern IP cameras, wireless access points, and VoIP phones.
- 24 ports with PoE+
- 720W total budget
- IEEE 802.3af/at compliant
Flexible Uplink Options
Four SFP slots provide fiber optic connectivity options for extending network reach beyond copper limitations or creating high-speed backbone links between switches.
- 4 SFP slots
- 1000Base-X support
- Fiber or copper SFP modules
Advanced Traffic Management
Layer 4 capabilities enable sophisticated traffic classifiers and bandwidth limits, allowing administrators to prioritize critical applications and ensure consistent network performance.
- Layer 4 switching
- Traffic classification
- Bandwidth management
Deployment / Use Cases
This switch is ideally suited for medium-sized business networks, educational facilities, retail environments, and multi-tenant office buildings where reliable PoE delivery and managed switching are required. The combination of high PoE budget and smart management makes it effective for unified communications deployments, wireless networking infrastructure, and IP surveillance systems.
In retail environments, the switch can power point-of-sale systems, digital signage, and security cameras while providing VLAN segmentation for different departments. For office deployments, it supports VoIP phone systems, wireless access points, and desktop connections with QoS prioritization for voice and video traffic. The rack-mountable design and included mounting hardware facilitate clean installation in server rooms or network closets.
Physical Profile
The switch features a standard 1U rack-mountable form factor measuring 1.73" high, 17.32" wide, and 10.12" deep, compatible with 19-inch rack systems. The compact design maximizes port density while minimizing rack space consumption. The included rack-mounting kit simplifies installation, and the built-in power supply with international power cord support ensures reliable operation in various geographic locations.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.73" (44 mm), 17.32" (440 mm), 10.12" (257 mm), 9.61 lb (4360 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.32" (440 mm)
- Depth
- 10.12" (257 mm)
- Height
- 1.73" (44 mm)
- Weight
- 9.61 lb (4360 g)
What's in the Box
The package includes all necessary components for immediate deployment and management of the switch.
Highlights
- 24 Gigabit Ethernet ports with PoE+ support (IEEE 802.3af/at)
- 720W total PoE budget for powering multiple devices simultaneously
- 4 SFP slots for fiber optic uplinks or expansion
- Layer 4 switching with advanced traffic classification
- Smart managed with web interface and SCC software
- Rack-mountable 1U form factor for standard 19-inch racks
- Comprehensive IEEE standards support including 802.1Q, 802.1x, 802.3ad
- Built-in power supply with international power cord
- Lifetime limited warranty from Netgear
- Supports twisted pair and optical fiber media types
Specifications
| Specifications | |
|---|---|
| Manufacturer | Netgear, Inc |
| Manufacturer Part Number | GS728TPP-300NAS |
| Brand Name | Netgear |
| Product Line | ProSafe |
| Product Model | GS728TPP |
| Product Name | ProSafe GS728TPP Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Uplink Port | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet PoE,4 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 4 |
| Networking Standards | IEEE 802.3az,IEEE 802.3af,IEEE 802.3at,IEEE 802.1x,IEEE 802.1p,IEEE 802.3,IEEE 802.3i,IEEE 802.3u,IEEE 802.3ab,IEEE 802.1Q,IEEE 802.3x,IEEE 802.3z,IEEE 802.3ae,IEEE 802.3ad,IEEE 802.1ab,IEEE 802.1D,IEEE 802.1s,IEEE 802.1w |
| Management & Protocols | |
| Manageable | Yes |
| Switch Management Type | Smart Managed |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 720 W |
| Power Source | Power Supply |
| Power Consumption | 483.50 W |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.73" (44 mm) |
| Width | 17.32" (440 mm) |
| Depth | 10.12" (257 mm) |
| Weight (Approximate) | 9.61 lb (4360 g) |
| Miscellaneous | |
| Package Contents | ProSafe GS728TPP Ethernet Switch Power Cord Rack-Mounting Kit Resource CD with Links to Online Documentation, Installation Guides, Web-Management User Manual, Smart Control Center (SCC) Software and User Guide. |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the total PoE budget of this switch?
The Netgear ProSafe GS728TPP-300NAS provides a 720W total PoE budget. This substantial power allocation allows all 24 RJ-45 ports to deliver IEEE 802.3at PoE+ power simultaneously, supporting power-hungry devices like PTZ cameras, high-performance wireless access points, and VoIP phones without requiring additional power injectors.
How many SFP slots does this switch have?
This switch includes 4 dedicated SFP (Small Form-factor Pluggable) slots. These slots support both copper and fiber optic SFP modules, enabling flexible uplink configurations, extended distance connections beyond 100 meters, or integration into existing fiber infrastructure for backbone links between network segments.
What layer switching does this Netgear switch support?
The GS728TPP-300NAS supports Layer 4 switching capabilities. This provides advanced traffic management features including traffic classifiers based on TCP/UDP port numbers, bandwidth limiting per port or per flow, and enhanced Quality of Service (QoS) for prioritizing critical applications like voice and video across the network.
Is this switch rack-mountable?
Yes, this switch features a standard 1U rack-mountable form factor. It measures 1.73 inches in height, 17.32 inches in width, and 10.12 inches in depth, making it compatible with 19-inch rack systems. The package includes a complete rack-mounting kit for secure installation in server rooms or network closets.
What management options are available for this switch?
This is a smart managed switch that can be configured through a web-based interface, Netgear's Smart Control Center (SCC) software included on the resource CD, or via SNMP. Management features include VLAN configuration, QoS settings, port mirroring, link aggregation, PoE management per port, and comprehensive monitoring of switch status and traffic statistics.
What type of warranty comes with this Netgear switch?
Netgear provides a lifetime limited warranty for the ProSafe GS728TPP-300NAS switch. This warranty covers defects in materials and workmanship for the lifetime of the product, offering long-term protection and peace of mind for business deployments where network reliability is critical to operations.
