Newline STV-7524 Digital Signage Display - 75" (1905 mm) LCD - High Dynamic Range (HDR) - 16 Hours/ 7 Days Operation - ARM Cortex A55 (STV-7524)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- STV-7524 Digital Signage Display
- 1 x RCA Cable
- 1 x Power Conrd
- 1 x Remote Control
- 2 x AAA Battery
Bezel Width (Top): 70.87 mil (1.80 mm)
Bezel Width (Bottom): 0.76" (19.30 mm)
Bezel Width (Left): 70.87 mil (1.80 mm)
Bezel Width (Right): 70.87 mil (1.80 mm)
Operation Hours: 16 Hours/ 7 Days
Processor Manufacturer: ARM
Processor Type: Cortex A55
Processor Core: Quad-core (4 Core)
Standard Memory: 2 GB
Number of Screens: 1
Viewable Screen Size: 75" (1905 mm)
Display Screen Type: LCD
High Dynamic Range (HDR): Yes
Response Time: 6.50 ms
Display Resolution: 3840 x 2160
Orientation: Landscape
Graphics Modes: 4K UHD
Backlight Technology: LED
Graphics Controller Manufacturer: ARM
Graphics Controller Model: Mali-G31 MC2
Aspect Ratio: 16:9
Scan Format: 2160p
Dynamic Contrast Ratio: 4,000:1
Brightness: 300 cd/m²
Ethernet: Yes
Wireless LAN: Yes
Bluetooth: Yes
USB: Yes
HDMI: Yes
Number of USB 2.0 Ports: 1
Number of USB 3.0 Ports: 1
Number of HDMI Inputs: 3
HDMI Input (Rear): Yes
Number of Network (RJ-45) Ports: 1
Number of Audio Line Out: 1
Number of HDMI 2.0 Ports: 3
Operating System: Android 11
Input Voltage: 120 V AC,230 V AC
VESA Mount Standard: 400 x 300
Mount Type: Wall Mountable
Installation Type: Hanging
Height: 37.60" (955.04 mm)
Width: 65.60" (1666.24 mm)
Depth: 3.40" (86.36 mm)
Weight (Approximate): 50.07 lb (22711.37 g)
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Minimum Storage Temperature: -4°F (-20°C)
Maximum Storage Temperature: 140°F (60°C)
Minimum Operating Humidity: 20%
Maximum Operating Humidity: 80%
Minimum Storage Humidity: 0%
Maximum Storage Humidity: 85%
Package Contents:
Application/Usage: Conference Room,Entertainment,Airport,Collaboration
- Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
- Experience luminescent visual images with LCD display
- Features a 4k Ultra HD 3840 x 2160 resolution
- Engages your customers and makes their viewing experience breathtaking with its 2160p content
- LED backlight enhances display performance that delivers an outstanding color range and contrast ratios
[custom-specifications]
| Specifications | |
| Manufacturer | Newline Interactive |
| Manufacturer Part Number | STV-7524 |
| Manufacturer Website Address | http:/ewline-interactive.com |
| Brand Name | Newline |
| Product Series | STV |
| Product Model | STV-7524 |
| Product Name | STV-7524 Digital Signage Display |
| Product Type | Digital Signage Display |
| Technical Information | |
| Bezel Width (Top) | 70.87 mil (1.80 mm) |
| Bezel Width (Bottom) | 0.76" (19.30 mm) |
| Bezel Width (Left) | 70.87 mil (1.80 mm) |
| Bezel Width (Right) | 70.87 mil (1.80 mm) |
| Operation Hours | 16 Hours/ 7 Days |
| Processor & Chipset | |
| Processor Manufacturer | ARM |
| Processor Type | Cortex A55 |
| Processor Core | Quad-core (4 Core) |
| Memory | |
| Standard Memory | 2 GB |
| Display & Graphics | |
| Number of Screens | 1 |
| Viewable Screen Size | 75" (1905 mm) |
| Display Screen Type | LCD |
| High Dynamic Range (HDR) | Yes |
| Response Time | 6.50 ms |
| Display Resolution | 3840 x 2160 |
| Orientation | Landscape |
| Graphics Modes | 4K UHD |
| Backlight Technology | LED |
| Graphics Controller Manufacturer | ARM |
| Graphics Controller Model | Mali-G31 MC2 |
| Aspect Ratio | 16:9 |
| Video | |
| Scan Format | 2160p |
| Dynamic Contrast Ratio | 4,000:1 |
| Brightness | 300 cd/m² |
| Network & Communication | |
| Ethernet | Yes |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Number of USB 2.0 Ports | 1 |
| Number of USB 3.0 Ports | 1 |
| Number of HDMI Inputs | 3 |
| HDMI Input (Rear) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of Audio Line Out | 1 |
| Number of HDMI 2.0 Ports | 3 |
| Software | |
| Operating System | Android 11 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Physical Characteristics | |
| VESA Mount Standard | 400 x 300 |
| Mount Type | Wall Mountable |
| Installation Type | Hanging |
| Height | 37.60" (955.04 mm) |
| Width | 65.60" (1666.24 mm) |
| Depth | 3.40" (86.36 mm) |
| Weight (Approximate) | 50.07 lb (22711.37 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Storage Temperature | -4°F (-20°C) |
| Maximum Storage Temperature | 140°F (60°C) |
| Minimum Operating Humidity | 20% |
| Maximum Operating Humidity | 80% |
| Minimum Storage Humidity | 0% |
| Maximum Storage Humidity | 85% |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | Conference Room,Entertainment,Airport,Collaboration |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
Manufacturer-Brochure
Additional-pdf2
[/custom-user-manual]
