Opticon OPN-4000n CCD Bluetooth Companion Scanner - Cable/Wireless Connectivity - 20.47" (519.94 mm) Scan Distance - 1D - LED - CCD, - (OPN4000N-00)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS) (exl.stacked), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSM-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
- Chinese Post, Korean Postal Authority Code
- OPN-4000n CCD Bluetooth Companion Scanner
- USB Cable
- Neck Strap
Connectivity Technology: Cable/Wireless
Scanning Capability: 1D
Barcode Symbology Supported:
1D:
POSTAL CODES:
Light Source: LED
Image Sensor Type: CCD,Linear
Scan Pattern: Single Pass
Scanning Distance: 20.47" (519.94 mm)
Number of Keys: 2
Cable Type Included: USB
Reading Angle (Skew): 65°
Reading Angle (Pitch): 50°
Reading Angle (Roll): 25°
Maximum Ambient Light: 100000 lux
Drop Specification:
5 ft (1.5 m) onto concrete
Minimum Element Resolution (Code 39): 5 mil (0.13 mm)
Maximum Element Resolution (Code 39): 39 mil (0.99 mm)
Features: Beep,Notification LED,Vibration
Standard Memory: 96 KB
Flash Memory: 1 MB
Processor Speed: 96 MHz
Bluetooth: Yes
Host Interface: USB
Battery Chemistry: Lithium Polymer (Li-Polymer)
Battery Capacity: 600 mAh
Maximum Battery Run Time: 25 Hour
Operating Temperature: 32°F (0°C) to 122°F (50°C)
Storage Temperature: -4°F (-20°C) to -140°F (-95.6°C)
Humidity (Non-condensing): 20% to 85%
Color Family: White
Product Color: White
Product Material: Acrylonitrile Butadiene Styrene (ABS)
Durability: Dust Resistant
Height: 3.27" (83.06 mm)
Width: 1.42" (36.07 mm)
Depth: 0.85" (21.59 mm)
Weight (Approximate): 1.87 oz (53.01 g)
Package Contents:
Ingress Protection (IP) Rating: IP42
Application/Usage: Retail,Inventory,Asset Tracking
Platform Supported: Android,PC,iOS
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 2 Year
- LED aimer is a perfect choice for patient-facing applications
- Bluetooth technology - Allows compatibility with most of your smart devices
[custom-specifications]
| Specifications | |
| Manufacturer | Opticon Sensors Europe |
| Manufacturer Part Number | OPN4000N-00 |
| Manufacturer Website Address | http://www.opticon.com |
| Brand Name | Opticon |
| Product Model | OPN-4000n |
| Product Name | OPN-4000n CCD Bluetooth Companion Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Cable/Wireless |
| Scanning Capability | 1D |
| Barcode Symbology Supported | 1D:
POSTAL CODES:
|
| Light Source | LED |
| Image Sensor Type | CCD,Linear |
| Scan Pattern | Single Pass |
| Scanning Distance | 20.47" (519.94 mm) |
| Number of Keys | 2 |
| Cable Type Included | USB |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 50° |
| Reading Angle (Roll) | 25° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | 5 ft (1.5 m) onto concrete |
| Minimum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Maximum Element Resolution (Code 39) | 39 mil (0.99 mm) |
| Features | Beep,Notification LED,Vibration |
| Memory | |
| Standard Memory | 96 KB |
| Flash Memory | 1 MB |
| Processor & Chipset | |
| Processor Speed | 96 MHz |
| Network & Communication | |
| Bluetooth | Yes |
| Interfaces/Ports | |
| Host Interface | USB |
| Battery Information | |
| Battery Chemistry | Lithium Polymer (Li-Polymer) |
| Battery Capacity | 600 mAh |
| Maximum Battery Run Time | 25 Hour |
| Environmental Conditions | |
| Operating Temperature | 32°F (0°C) to 122°F (50°C) |
| Storage Temperature | -4°F (-20°C) to -140°F (-95.6°C) |
| Humidity (Non-condensing) | 20% to 85% |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Product Material | Acrylonitrile Butadiene Styrene (ABS) |
| Durability | Dust Resistant |
| Height | 3.27" (83.06 mm) |
| Width | 1.42" (36.07 mm) |
| Depth | 0.85" (21.59 mm) |
| Weight (Approximate) | 1.87 oz (53.01 g) |
| Miscellaneous | |
| Package Contents |
|
| Ingress Protection (IP) Rating | IP42 |
| Application/Usage | Retail,Inventory,Asset Tracking |
| Platform Supported | Android,PC,iOS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
[/custom-user-manual]
