Perle 05061470 C-1000MM-M2SC2 Gigabit Fiber to Fiber Media Converter Module - 2 SC Ports Multi-mode 1000Base-LX/SX - 2 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter operates on 1000Base-LX and 1000Base-SX network technologies, delivering data transfer rates up to 1000 Mbps over optical fiber. It supports multi-mode fiber cables with core/cladding specifications of 62.5/125 µm and 50/125 µm, ensuring compatibility with standard multi-mode fiber installations.
The internal form factor allows for convenient installation within compatible chassis or enclosures, reducing clutter and simplifying network topology. With a lightweight design of approximately 149.7 grams, it integrates efficiently into rack-mounted or embedded systems without adding significant bulk.
Key Product Advantages
This converter provides durable performance with minimal signal loss, enabling fast data transfers over greater distances compared to copper-based solutions. The optical fiber support reduces susceptibility to electromagnetic interference, ensuring stable network connectivity in electrically noisy environments.
Extended Reach
Supports fiber optic connections up to 2 kilometers, ideal for connecting remote network segments or buildings within campus environments.
- Eliminates distance limitations of copper Ethernet
- Maintains signal integrity over long runs
Media Conversion Flexibility
Converts between fiber optic media types within multi-mode networks, allowing integration of fiber segments without replacing existing infrastructure.
- Compatible with standard 62.5/125 µm and 50/125 µm cables
- Supports both 1000Base-LX and 1000Base-SX standards
Simplified Deployment
Internal form factor enables clean installation within network equipment, reducing cable clutter and simplifying network management.
- Lightweight design at 149.7 grams
- No external power adapter required
Deployment / Use Cases
This media converter is particularly valuable in scenarios where network segments need to be extended beyond the 100-meter limit of traditional copper Ethernet. It enables reliable connectivity between buildings, across large facilities, or in environments where electromagnetic interference could degrade copper-based signals.
Common applications include connecting network switches in separate buildings within a campus, extending network reach in manufacturing facilities with electrical noise, and integrating fiber backbone segments into existing Gigabit Ethernet networks. The converter also supports data center deployments where fiber optic connectivity is required between racks or across different sections of the facility.
Campus Network Extension
Connect network equipment between buildings up to 2 kilometers apart while maintaining Gigabit Ethernet performance over fiber optic cable.
EMI-Prone Environments
Deploy in industrial settings where electromagnetic interference could disrupt copper-based networks, utilizing fiber's immunity to electrical noise.
Physical Profile
The internal form factor is designed for installation within compatible networking equipment chassis or enclosures. With an approximate weight of 149.7 grams, it adds minimal load to host systems while providing reliable media conversion functionality. The compact design integrates seamlessly into rack-mounted configurations, supporting efficient use of rack space in data center and network closet deployments.
- Weight
- 149.7 g
Highlights
- Gigabit Ethernet fiber to fiber media converter module with 2 SC duplex ports
- Supports multi-mode fiber optic cable up to 2 kilometers maximum distance
- 1000Base-LX and 1000Base-SX network technology for up to 1000 Mbps data transfer
- Compatible with 62.5/125 µm and 50/125 µm multi-mode fiber cables
- Internal form factor for convenient installation within network equipment
- Lightweight design at approximately 149.7 grams
- Environmentally compliant with REACH, RoHS, and WEEE standards
- Manufactured in Canada with lifetime limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Perle Systems, Inc |
| Manufacturer Part Number | 05061470 |
| Brand Name | Perle |
| Product Model | C-1000MM-M2SC2 |
| Product Name | C-1000MM-M2SC2 - Gigabit Ethernet Fiber to Fiber Media Converter Module |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| DVI | No |
| USB | No |
| Management Port | No |
| Number of SC Ports | 2 |
| SC Port Type | Duplex |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Maximum Distance Supported | 2 km |
| Fiber Optic Cable Core/Cladding Specification | 62.5/125 µm,50/125 µm |
| Network & Communication | |
| Network Technology | 1000Base-LX,1000Base-SX |
| Physical Characteristics | |
| Form Factor | Internal |
| Weight (Approximate) | 149.7 g |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Canada |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of fiber optic cable does this media converter support?
The Perle C-1000MM-M2SC2 supports multi-mode fiber optic cables with core/cladding specifications of 62.5/125 µm and 50/125 µm. It is designed specifically for multi-mode fiber installations, not single-mode fiber. The converter uses SC duplex connectors for reliable optical connections in standard multi-mode network deployments.
What is the maximum distance this converter can support between network devices?
This media converter supports fiber optic connections up to 2 kilometers (approximately 1.24 miles) between network devices. This extended reach makes it suitable for connecting network segments across buildings or large facilities where copper Ethernet would exceed its 100-meter limitation. The distance capability depends on using compatible multi-mode fiber cable within the supported specifications.
What network standards does this converter support for Gigabit Ethernet?
The converter supports both 1000Base-LX and 1000Base-SX Gigabit Ethernet standards over multi-mode fiber. These standards provide data transfer rates up to 1000 Mbps (1 Gbps) using optical fiber media. The dual-standard support ensures compatibility with various network equipment implementing either 1000Base-LX or 1000Base-SX interfaces for flexible deployment in existing network environments.
How is this media converter installed in a network?
This converter features an internal form factor designed for installation within compatible networking equipment chassis or enclosures. It does not require an external power adapter as it draws power from the host system. The installation involves connecting multi-mode fiber optic cables to the two SC duplex ports and integrating the module into the host device, providing a clean, rack-mountable solution that reduces cable clutter.
