Perle 05062220 CM-1000MM-S2SC10 Media Converter - 2 x SC Duplex Ports - 1000Base-SX/LX/LH - 10 km - Internal
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter operates at Layer 1 of the OSI model, performing transparent electrical-to-optical signal conversion without protocol translation. It supports multimode fiber with 62.5/125 µm and 50/125 µm core/cladding specifications, ensuring compatibility with common enterprise fiber cabling installations.
The converter maintains full duplex operation across both SC ports, enabling simultaneous bidirectional data flow at Gigabit speeds. Built with industrial-grade components, it delivers consistent performance across temperature variations typical in data center and telecom environments.
Key Product Advantages
The CM-1000MM-S2SC10 extends network reach while maintaining signal quality across fiber segments. Its support for multiple 1000Base standards provides deployment flexibility in diverse fiber infrastructure scenarios.
Distance Extension
Enables reliable Gigabit connectivity across 10 km fiber runs, far exceeding copper Ethernet distance limitations.
- Eliminates signal degradation over long distances
- Maintains full 1000 Mbps throughput
Media Conversion
Transparently converts between fiber optic media types while preserving data integrity and timing characteristics.
- No protocol translation required
- Supports multiple fiber standards
Space-Efficient Design
Internal form factor integrates directly into equipment racks without external footprint, optimizing installation density.
- 149.7 g lightweight construction
- Minimal power consumption
Deployment / Use Cases
This media converter is ideal for extending Gigabit Ethernet networks across building-to-building fiber links or within large facilities where copper distance limitations would otherwise require additional switching infrastructure.
Common deployment scenarios include connecting network switches across separate floors or buildings, integrating fiber backbone segments with copper-based edge networks, and upgrading existing fiber installations to Gigabit speeds without replacing entire cabling systems.
Campus Network Extension
Connect administrative buildings to data centers across campus fiber infrastructure while maintaining Gigabit performance.
Data Center Interconnect
Bridge between equipment racks or data hall segments using existing multimode fiber pathways.
Physical Profile
Designed as an internal component, this converter installs directly within compatible networking equipment or enclosures. The 149.7 g weight ensures minimal load on mounting structures while the compact dimensions optimize space utilization in dense rack environments.
- Weight
- 149.7 g
Highlights
- 2 SC duplex fiber ports for reliable optical connectivity
- Supports 1000Base-SX, 1000Base-LX, and 1000Base-LH standards
- Maximum 10 km distance for extended network reach
- Compatible with 62.5/125 µm and 50/125 µm multimode fiber
- Internal form factor for space-efficient installation
- 149.7 g lightweight construction
- Environmentally friendly design
- Manufactured in Canada with lifetime warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Perle Systems, Inc |
| Manufacturer Part Number | 05062220 |
| Brand Name | Perle |
| Product Model | CM-1000MM-S2SC10 |
| Product Name | CM-1000MM-S2SC10 Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Number of SC Ports | 2 |
| SC Port Type | Duplex |
| Media & Performance | |
| Maximum Distance Supported | 10 km |
| Fiber Optic Cable Core/Cladding Specification | 62.5/125 µm,50/125 µm |
| Network & Communication | |
| Network Technology | 1000Base-SX,1000Base-LX,1000Base-LH |
| Physical Characteristics | |
| Form Factor | Internal |
| Weight (Approximate) | 149.7 g |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Country of Origin | Canada |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What types of fiber cable does this media converter support?
The CM-1000MM-S2SC10 supports multimode fiber optic cables with 62.5/125 µm and 50/125 µm core/cladding specifications. These are common multimode fiber types used in enterprise and data center environments for short to medium distance connections.
What is the maximum distance this converter can support?
This media converter supports fiber connections up to 10 kilometers (approximately 6.21 miles) while maintaining full Gigabit Ethernet performance. The actual achievable distance may vary based on fiber quality, connectors, and environmental conditions.
What does 'internal form factor' mean for installation?
Internal form factor means this converter is designed to install inside compatible networking equipment, racks, or enclosures rather than as a standalone external device. This saves valuable external space and integrates seamlessly with existing infrastructure without additional mounting hardware.
What network standards does this converter support?
The converter supports 1000Base-SX, 1000Base-LX, and 1000Base-LH Gigabit Ethernet standards over fiber optic media. These standards cover different wavelength and distance specifications for multimode and single-mode fiber applications.
