Advantech 1750003418 Antenna - 2. 4 GHz - 9 dBi - Wireless Module for EWM-W151H Mini PCIe Card
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The Advantech 1750003418 antenna is a dedicated 2.4 GHz wireless module antenna engineered to enhance signal strength and network reliability in industrial and embedded applications. This high-gain antenna is specifically designed to pair with Advantech's EWM-W151H Mini PCIe wireless card, providing a robust connectivity solution for systems requiring stable wireless communication.
With a focused 9 dBi isotropic gain, this antenna optimizes transmission and reception performance in the 2.4 GHz band, making it suitable for environments where signal clarity and range are critical. Its targeted compatibility ensures seamless integration with supported hardware, reducing deployment complexity and supporting consistent wireless performance across compatible devices.
Technical Overview
This antenna operates exclusively within the 2.4 GHz frequency range, a common band for Wi-Fi and other wireless protocols, ensuring broad compatibility with standard wireless networks. The 9 dBi isotropic gain specification indicates a focused radiation pattern that enhances signal directionality and strength compared to lower-gain antennas, which can improve link stability and effective range in suitable deployments.
The antenna is application-specific, intended for use with wireless modules rather than as a standalone consumer accessory. This design focus supports integration into embedded systems, industrial PCs, and other hardware where modular wireless components are employed. The technical design prioritizes reliable performance in the 2.4 GHz spectrum, which remains widely used for IoT, machine-to-machine communication, and legacy Wi-Fi networks.
Key Product Advantages
The Advantech 1750003418 antenna offers several distinct advantages for wireless module deployments, centered on enhanced signal performance and targeted compatibility.
High-Gain Performance
With 9 dBi isotropic gain, this antenna provides stronger signal transmission and reception than standard low-gain antennas, which can lead to improved wireless range and reduced signal dropout in challenging environments.
- Enhanced signal strength
- Improved range potential
- Reduced interference sensitivity
Specific Compatibility
Designed explicitly for the Advantech EWM-W151H 802.11 b/g/n Mini PCIe card, this antenna ensures optimal electrical and mechanical integration, eliminating guesswork and compatibility issues during installation.
- Guaranteed fit with EWM-W151H
- Simplified procurement
- Reliable performance pairing
Deployment / Use Cases
This antenna is ideal for deployments where wireless modules are integrated into larger systems, particularly in industrial, commercial, or embedded contexts. Its high-gain design and specific compatibility make it a practical choice for applications requiring dependable wireless connectivity without the variability of generic antennas.
Common use cases include industrial automation systems where wireless sensors or control units communicate over 2.4 GHz networks, embedded computing platforms that incorporate Mini PCIe wireless cards for connectivity, and legacy Wi-Fi setups that benefit from enhanced signal strength. The antenna supports 802.11 b/g/n standards through its compatible card, making it suitable for environments where these protocols are in use, such as warehouses, manufacturing floors, or remote monitoring stations.
Highlights
- 2.4 GHz operating frequency for broad wireless compatibility
- 9 dBi isotropic gain enhances signal strength and range
- Specifically designed for wireless module applications
- Compatible with Advantech EWM-W151H 802.11 b/g/n Mini PCIe card
- Supports industrial and embedded wireless deployments
- Manufactured by Advantech Co., Ltd in Taiwan
Specifications
| Specifications | |
|---|---|
| Manufacturer | Advantech Co., Ltd |
| Manufacturer Part Number | 1750003418 |
| Brand Name | Advantech |
| Product Name | Antenna |
| Product Type | Antenna |
| Technical Information | |
| Operating Frequency Range | 2.4 GHz |
| Antenna Gain (Isotropic) | 9 dBi |
| Miscellaneous | |
| Application/Usage | Wireless Module |
| Compatibility | Advantech EWM-W151H 802.11 b/g/n Mini PCIe Card |
| Country of Origin | Taiwan |
FAQ
What frequency does this Advantech antenna operate on?
This antenna operates exclusively in the 2.4 GHz frequency range. This band is commonly used for Wi-Fi (802.11 b/g/n), Bluetooth, and various IoT wireless protocols, making the antenna suitable for standard wireless networks and legacy systems that utilize this spectrum.
What is the antenna gain of the Advantech 1750003418?
The antenna provides 9 dBi isotropic gain. This gain level indicates a focused radiation pattern that enhances signal strength and directionality compared to lower-gain antennas, which can improve wireless range and connection stability in appropriate deployments.
What is this antenna compatible with?
This antenna is specifically compatible with the Advantech EWM-W151H 802.11 b/g/n Mini PCIe wireless card. It is designed for wireless module applications, ensuring optimal performance and fit when used with this particular Mini PCIe card in embedded or industrial systems.
What type of applications is this antenna designed for?
The antenna is designed for wireless module applications, meaning it is intended to be integrated with wireless cards in systems like industrial PCs, embedded computers, or automation equipment. It is not a standalone consumer antenna but rather a component for modular wireless setups.
Does this antenna support PoE or require external power?
No, this antenna is a passive component and does not support Power over Ethernet (PoE) or require external power. It operates purely as a signal-enhancing element that connects to a compatible wireless module, which itself handles power and data transmission.
Who manufactures the Advantech 1750003418 antenna?
The antenna is manufactured by Advantech Co., Ltd, a reputable provider of industrial computing and networking solutions. It is produced in Taiwan, reflecting Advantech's global manufacturing standards for reliable hardware components.
