Altronix 8-Port Managed 802.3bt Midspan Injecto - 120 V AC, 230 V AC Input - 8 x PoE Input Port(s) - 8 x PoE Output Port(s) - 480 W - (NETWAY8BT)

Marketing Information: Altronix NetWay8BT is a 8-port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+/Hi PoE up to 90W (802.3bt compliant) power per port, 480W total max. and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup and embed- ded LINQ™ Technology to monitor, control, and report power and diagnostics from anywhere over the network.

Input Voltage: 120 V AC,230 V AC

Maximum Input Current: 5.50 A

Maximum Output Power: 480 W

Input Ports: 8 x PoE

Output Ports: 8 x PoE

Form Factor: Rack Mountable

Rack Height: 1U

Height: 8.50" (215.90 mm)

Width: 1.63" (41.28 mm)

Length: 19.13" (485.78 mm)

Weight (Approximate): 2.90 kg

Certifications & Standards:

• IEEE 802.3af (15W)
• IEEE 802.3at (30W)
• IEEE802.3bt
• CE
• UL60950-1
• UL294

Country of Origin: United States

Limited Warranty: Lifetime
