Product Features
Technical Overview
This fiber optic cable utilizes multi-mode technology with a 50/125 µm core/cladding specification, optimized for short to medium-range high-speed data transmission. The SC connectors offer secure, push-pull mating for stable connections in rack-mounted or patching applications.
With a rated data transfer speed of 10 Gbit/s, the cable supports high-bandwidth network demands, including backbone links, server connections, and storage area networks. The duplex design separates transmit and receive channels, reducing crosstalk and ensuring consistent performance.
Key Product Advantages
This cable combines robust construction with practical features for dependable network infrastructure. The lifetime warranty underscores its durability and Axiom's commitment to quality.
High-Speed Performance
Supports 10 Gbit/s data transfer, ideal for bandwidth-intensive applications and future-proof network upgrades.
- OM3 multimode fiber
- Low attenuation
- Minimal signal loss
Reliable Connectivity
SC connectors provide secure, low-insertion-loss connections that resist accidental disconnection in high-density environments.
- Push-pull latching
- Precision alignment
- Durable construction
Deployment / Use Cases
This fiber optic cable is suited for various network scenarios requiring stable, high-speed data links. Its 30-meter length and SC connectors make it versatile for both structured cabling and direct device connections.
Common applications include connecting switches to servers in data centers, linking network equipment in telecom cabinets, and patching fiber panels in enterprise networks. The multimode design is cost-effective for distances under 300 meters, while the duplex configuration supports full-duplex communication.
Data Center Interconnects
Use for linking top-of-rack switches to aggregation layers or connecting storage arrays to servers, ensuring low-latency data flow.
Enterprise Network Backbone
Deploy as part of structured cabling systems to support high-bandwidth traffic between floors or buildings, with SC connectors simplifying maintenance.
Highlights
- 30-meter (98.4-foot) multimode duplex fiber optic cable
- SC connectors on both ends for secure network connections
- Supports 10 Gbit/s data transfer rates
- OM3-grade 50/125 µm fiber for reliable performance
- Aqua green jacket for easy identification
- Duplex design enables bidirectional data transmission
- Compatible with network devices like switches and servers
- Lifetime warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axiom Memory Solutions |
| Manufacturer Part Number | SCSC10GA-30M-AX |
| Brand Name | Axiom |
| Product Name | SC/SC 10G Multimode Duplex OM3 50/125 Fiber Optic Cable 30m |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Fiber Optic |
| Fiber Optic Mode | Multi-mode |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm |
| Cable Length | 98.4 ft |
| Connector Type on First End | SC Network - Male |
| Connector on First End Details | 2 x SC Network - Male |
| Connector Type on Second End | SC Network - Male |
| Connector on Second End Details | 2 x SC Network - Male |
| Device Supported | Network Device |
| Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Color Family | Green |
| Product Color | Aqua |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of fiber optic cable is this?
This is a multimode duplex fiber optic cable with OM3-grade 50/125 µm fiber. It uses multi-mode technology optimized for short to medium-distance high-speed data transmission, typically up to 300 meters at 10 Gbit/s speeds. The duplex design separates transmit and receive channels for full-duplex communication.
What connectors does this cable have?
Both ends of the cable feature two SC male connectors each, providing a total of four SC connectors. The SC connectors use a push-pull latching mechanism for secure connections, making them suitable for rack-mounted equipment and patch panels in data centers and enterprise networks.
What is the cable length and data transfer rate?
The cable is 30 meters long (equivalent to 98.4 feet) and supports data transfer rates up to 10 Gbit/s. This length is ideal for typical network runs within server rooms or between adjacent racks, while the 10 Gbit/s speed handles high-bandwidth applications like server connections and network backbones.
What color is the cable and why does it matter?
The cable has an aqua green jacket, which is the industry-standard color for OM3 multimode fiber optic cables. This color coding helps network technicians quickly identify cable types during installation and maintenance, reducing errors and improving organization in complex cabling environments.
