ComNet CNFE2004S1A 2-Channel Fast Ethernet Media Converter - 2x RJ-45 - 1x SC Simplex - Single-Mode Fiber 1310/1550nm - 20 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Technically, the CNFE2004S1A operates as a transparent media converter, supporting Fast Ethernet (10/100Base-TX) over both twisted pair and optical fiber. The two RJ-45 ports handle standard Ethernet connections, while the SC simplex port interfaces with single-mode fiber cables.
It uses 1310 nm and 1550 nm wavelengths for fiber transmission, which are common for long-distance single-mode applications. The converter is powered by an included AC adapter, ensuring stable operation without PoE dependency.
This section brings together practical product details such as Total Number of Ports, Network (RJ-45), Number of Network (RJ-45) Ports, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This media converter extends network reach efficiently by converting copper Ethernet to fiber optic links, reducing signal degradation over long runs. Its dual-channel design allows two separate network segments to be converted simultaneously, saving space and cost compared to single-channel units.
Long-Distance Reliability
Supports up to 20 km on single-mode fiber, ideal for connecting remote buildings or industrial sites without signal loss.
- 1310/1550 nm wavelengths
- Single-mode fiber compatibility
Flexible Installation
Mountable and rack-mountable form factor with compact dimensions fits standard racks or wall mounts for versatile deployment.
- 1.10" height profile
- Includes power supply
Deployment / Use Cases
Deploy the CNFE2004S1A in scenarios where Ethernet needs to be extended beyond the 100-meter limit of copper cabling. It is commonly used in campus networks, industrial automation, security camera systems, and telecommunications infrastructure.
Typical use cases include connecting remote switches or devices over fiber, integrating fiber backbones into existing copper networks, and providing noise immunity in electrically noisy environments. Its two channels allow separate network segments, such as data and voice VLANs, to be converted independently.
Physical Profile
The converter has a compact design measuring 5.30 inches wide, 6.10 inches deep, and 1.10 inches high, making it suitable for dense rack installations. Its mountable and rack-mountable form factor includes mounting hardware for secure placement in network closets or industrial enclosures.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.10" (27.94 mm), 5.30" (134.62 mm), 6.10" (154.94 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 5.30" (134.62 mm)
- Depth
- 6.10" (154.94 mm)
- Height
- 1.10" (27.94 mm)
- Length
- 1310 nm,1550 nm
What's in the Box
The package includes the media converter unit and a DC plug-in power supply, ensuring immediate deployment out of the box.
Highlights
- Converts between 2 RJ-45 twisted pair ports and 1 SC simplex single-mode fiber port
- Supports Fast Ethernet (10/100Base-TX) with up to 100 Mbps data rates
- Uses 1310 nm and 1550 nm wavelengths on single-mode fiber for long-distance transmission
- Maximum fiber distance of 20 kilometers (12.43 miles)
- Compact, mountable form factor for rack or wall installation
- Powered by included AC adapter for reliable operation
- Dual-channel design converts two network segments simultaneously
- Environmentally friendly and backed by a lifetime warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | ACRE |
| Manufacturer Part Number | CNFE2004S1A |
| Brand Name | ComNet |
| Product Series | CNFE200(X)POE(M,S)(1,2)[HO][/M] |
| Product Name | 2 Channel 10/100 Mbps Ethernet 1310/1550nm |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 3 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of SC Ports | 1 |
| SC Port Type | Simplex |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Fiber Mode Supported | Single-mode |
| Fiber Optic Cable Wavelength | 1310 nm,1550 nm |
| Maximum Distance Supported | 20 km (12.43 Mile) |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Technology | 10/100Base-TX |
| Power Description | |
| Power Source | AC Adapter |
| Physical Characteristics | |
| Form Factor | Mountable,Rack-mountable |
| Height | 1.10" (27.94 mm) |
| Width | 5.30" (134.62 mm) |
| Depth | 6.10" (154.94 mm) |
| Miscellaneous | |
| Package Contents | 2 Channel 10/100 Mbps Ethernet 1310/1550nm DC Plug-in Power Supply |
| Environmentally Friendly | Yes |
| Country of Origin | United States |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What does this media converter do?
It converts Ethernet signals between two RJ-45 twisted pair ports and one SC simplex single-mode fiber port, allowing network extension over fiber optic cables up to 20 kilometers while maintaining Fast Ethernet (10/100Base-TX) speeds.
What types of fiber does it support?
It supports single-mode fiber optic cables with 1310 nm and 1550 nm wavelengths. Single-mode fiber is ideal for long-distance applications, and this converter is compatible with standard SC simplex connectors.
How far can it transmit over fiber?
It supports a maximum distance of 20 kilometers (12.43 miles) over single-mode fiber. This makes it suitable for connecting remote network segments, such as between buildings or across large campuses, without signal degradation.
What is the data transfer rate?
It supports Fast Ethernet technology with data transfer rates up to 100 Mbps over both twisted pair and fiber connections. This aligns with 10/100Base-TX standards for reliable network performance in most business environments.
How is it powered?
It is powered by an included AC adapter, which plugs into standard wall outlets. This provides stable power without relying on Power over Ethernet (PoE), ensuring consistent operation in various installation scenarios.
Can it be mounted in a rack?
Yes, it features a mountable and rack-mountable form factor with dimensions of 5.30" W x 6.10" D x 1.10" H. It includes mounting hardware for secure installation in standard network racks or on walls, saving space in network closets.
