CyberPower CP550SLG Standby UPS - 550VA/330W Desktop Battery Backup - 8 Outlets - 120V - USB - PowerPanel Personal - Compact Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The CyberPower CP550SLG Standby UPS delivers reliable battery backup and surge protection for essential desktop equipment with 550VA/330W power capacity. This compact unit features eight NEMA 5-15R outlets—four providing battery backup plus surge protection and four offering surge-only protection—ensuring critical devices remain operational during power interruptions while accommodating less essential equipment.
Designed specifically for desktop computers, workstations, home theater systems, networking equipment, and VoIP devices, this UPS offers practical protection with a 4ms transfer time and simulated sine wave output. The GreenPower UPS high-efficiency design minimizes energy waste while providing consistent power conditioning, making it suitable for both office and home environments where reliable power backup is essential for preventing data loss and equipment damage.
The unit includes a 5-foot NEMA 5-15P power cord for convenient connection to standard North American wall outlets. With its compact desktop form factor measuring 9.8 inches wide by 5.8 inches high by 3.3 inches deep, the CP550SLG fits easily on desktops or under workstations without requiring dedicated rack space. The black enclosure integrates smoothly into professional and residential environments while providing substantial protection capacity for typical computing setups.
Built with a sealed lead-acid battery rated at 12V with 5500 mAh capacity, this UPS delivers consistent backup performance with 2 minutes of runtime at full load and 8 minutes at half load. The system includes LED status indicators for power monitoring and a battery mode alarm for user notification during outages, while the 8-hour typical recharge time ensures quick recovery after power events. Additional protection features include dataline protection via RJ-11 connections and comprehensive environmental compliance with RoHS standards.
Technical Overview
This standby topology UPS maintains power quality with input voltage ranging from 96 to 140 V AC and output stabilized at 120 V AC, ensuring compatibility with standard North American electrical systems. The unit accepts 60 Hz input and delivers 50/60 Hz output compatibility for international equipment support, providing flexibility for various deployment scenarios.
Internal protection features include a sealed lead-acid battery rated at 12V with 5500 mAh capacity, delivering consistent backup performance with 2 minutes of runtime at full load and 8 minutes at half load. The system includes LED status indicators for power monitoring and a battery mode alarm for user notification during outages, while the 8-hour typical recharge time ensures quick recovery after power events. Additional technical safeguards include dataline protection via RJ-11 connections and comprehensive environmental compliance with RoHS standards.
Key Product Advantages
The CP550SLG combines essential protection features with practical design considerations. The compact form factor fits easily on desktops or under workstations while providing substantial power capacity for typical office and home computing environments.
Comprehensive Outlet Protection
Eight outlets provide flexible device connectivity with four offering battery backup plus surge protection and four providing surge-only protection for less critical equipment.
- 4 battery & surge outlets
- 4 surge-only outlets
- NEMA 5-15P plug with 5 ft cord
Intelligent Power Management
USB connectivity enables PowerPanel Personal Edition software for automated system shutdown, runtime monitoring, and power event logging.
- HID-compliant USB port
- Free management software
- Battery status monitoring
Deployment / Use Cases
This UPS serves multiple deployment scenarios where reliable power backup is essential for maintaining operational continuity. For home theater systems, it protects audio/video equipment from power fluctuations that can damage sensitive electronics while providing sufficient runtime for safe shutdown procedures during extended outages.
In small office environments, the unit safeguards electronic equipment including printers, scanners, and external storage devices, supporting business continuity by preventing data corruption and hardware damage. The compact design makes it suitable for space-constrained installations while delivering adequate runtime for orderly system shutdown procedures, and its 120V input/output configuration ensures seamless integration with standard North American power infrastructure. Additional applications include protecting medical monitoring equipment, point-of-sale systems, and security devices where uninterrupted power is critical for safety and operational requirements.
Desktop Computer Protection
Ideal for protecting desktop computers and workstations from power interruptions, allowing time for proper system shutdown and preventing data loss during outages while safeguarding against voltage fluctuations that can damage sensitive components.
Network Infrastructure Support
Suitable for routers, modems, and VoIP devices that require continuous operation to maintain network connectivity and communication services, ensuring uninterrupted internet access and telephony functions during power disturbances.
Physical Profile
The black compact enclosure measures 9.8 inches wide by 5.8 inches high by 3.3 inches deep, with a weight of 7.5 pounds. This desktop form factor integrates smoothly into office and home environments without requiring dedicated rack space.
The unit operates within 32°F to 104°F (0°C to 40°C) temperature ranges and 0% to 90% humidity conditions, with storage capability from -15°C to 45°C. RoHS compliance ensures environmentally responsible manufacturing.
- Width
- 9.80" (248.92 mm)
- Depth
- 3.30" (83.82 mm)
- Height
- 5.80" (147.32 mm)
- Weight
- 7.50 lb (3401.94 g)
- Length
- 5 ft (1.52 m)
What's in the Box
The package includes the complete UPS system with all necessary components for immediate deployment.
Highlights
- 550VA/330W power capacity for desktop equipment protection
- Eight NEMA 5-15R outlets (4 battery+surge, 4 surge-only)
- USB connectivity with PowerPanel Personal management software
- 4ms transfer time with simulated sine wave output
- Compact desktop form factor (9.8" × 5.8" × 3.3")
- 120V input/output with 96-140V input range
- 2-minute runtime at full load, 8 minutes at half load
- 3-year limited warranty with environmental compliance
- EMI/RFI noise filtering and overload protection
- GreenPower UPS high-efficiency design
Specifications
| Specifications | |
|---|---|
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | CP550SLG |
| Brand Name | CyberPower |
| Product Series | Standby UPS |
| Product Model | CP550SLG |
| Product Name | CP550SLG Standby UPS Systems |
| Product Type | Standby UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Number of Battery & Surge Outlets | 4 |
| Number of Surge-only Outlets | 4 |
| Dataline Protection | RJ-11 |
| Overload Protection | Yes |
| Cord Length | 5 ft (1.52 m) |
| Transfer Time | 4 ms |
| EMI/RFI Noise Filter | Yes |
| Energy Saving | GreenPower UPS™ High-Efficiency Design |
| Application/Usage | Desktop Computer,Workstation,Home Theater,Electronic Equipment,Home Network,Router,Modem,VoIP Device |
| Power Description | |
| Load Capacity (VA) | 550 VA |
| Load Capacity (Watt) | 330 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 96 V AC - 140 V AC |
| Output Voltage | 120 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 50 Hz,60 Hz |
| Waveform Type | Sine Wave,Simulated Sine Wave |
| Surge Energy Rating | 890 J |
| Circuit Breaker | Yes |
| Output Power Factor | 0.6 |
| Management | |
| Alarm | Battery Mode |
| Controls/Indicators | |
| Status Indicators | LED Indicators: Power On |
| Interfaces/Ports | |
| Serial Port | No |
| USB | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| Number of Batteries | 1 |
| Battery Characteristics | Sealed |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 5500 mAh |
| Backup/Run Time (Full Load) | 2 Minute |
| Backup/Run Time (Half Load) | 8 Minute |
| Typical Battery Recharge Time | 8 Hour |
| Replaceable Battery | No |
| Environmental Conditions | |
| Storage Temperature | 5°F (-15°C) - 113°F (45°C) |
| Operating Humidity | 0% - 90% |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Physical Characteristics | |
| Product Color | Black |
| Height | 5.80" (147.32 mm) |
| Width | 9.80" (248.92 mm) |
| Depth | 3.30" (83.82 mm) |
| Form Factor | Compact |
| Weight (Approximate) | 7.50 lb (3401.94 g) |
| Miscellaneous | |
| Package Contents | Standby CP550SLG 550 VA Desktop UPS User Manual USB A+B Type Cable Warranty Registration Card |
| Software Included | PowerPanel Personal Edition UPS Management Software |
| Energy Star | No |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
