Panduit P12B19M Horizontal Basic PDU - 1. 90 kVA - 12x NEMA 5-20R Outlets - 120V AC - 1U Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This basic PDU operates on single-phase power with a 120V AC input and output voltage, supporting equipment within a 120V AC to 240V AC output voltage range. The 20A input current capacity enables the full 1.90 kVA power rating, ensuring adequate power availability for connected devices.
The electrical design focuses on fundamental power distribution without remote outlet switching or advanced monitoring features. This simplicity translates to reliable operation and straightforward installation in environments where basic power distribution meets operational requirements.
This section brings together practical product details such as PDU Type, Phase, Plug/Connector Type, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Panduit P12B19M delivers essential power distribution with Panduit's quality construction and environmental compliance. Its straightforward design eliminates complexity while providing reliable power to rack-mounted equipment.
High-Density Outlet Configuration
Twelve NEMA 5-20R outlets in a 1U form factor maximize power distribution capacity within minimal rack space, supporting multiple devices in compact installations.
- 12 outlets in 1U space
- Standard NEMA 5-20R connectors
- Consistent 120V AC output
Rack-Optimized Design
Horizontal mounting orientation and 1U rack height ensure seamless integration into standard 19-inch rack environments without sacrificing valuable vertical space.
- Horizontal mounting
- 1U rack height
- Standard 19-inch rack compatible
Environmental Compliance
Manufactured with RoHS and REACH compliance, this PDU meets environmental standards while delivering reliable performance in commercial and data center applications.
- RoHS compliant
- REACH compliant
- Environmentally friendly construction
Deployment / Use Cases
This basic PDU serves as a fundamental power distribution component in environments where reliable, unmanaged power delivery is sufficient. Its twelve-outlet configuration supports moderate-density equipment installations without the complexity of remote management capabilities.
Typical deployments include network closets with multiple switches and routers, server racks with basic computing equipment, and telecommunications installations requiring consistent power distribution. The horizontal mounting orientation makes it particularly suitable for standard rack configurations where front-to-back or side-mounted PDUs would interfere with equipment placement or cable management.
Network Infrastructure Support
Power multiple network switches, routers, and access points in telecommunications rooms and data center edge locations where basic power distribution meets operational needs.
Server Rack Power Distribution
Provide reliable power to rack-mounted servers, storage devices, and supporting equipment in environments where remote outlet control is not required for daily operations.
Physical Profile
The P12B19M features compact dimensions optimized for rack installation, measuring 1.60 inches in height, 17.50 inches in width, and 2 inches in depth. This 1U form factor occupies minimal vertical space while providing full-width mounting stability in standard 19-inch racks.
The horizontal mounting orientation positions the unit along the rack's horizontal plane, with outlets accessible from the front or rear depending on installation preferences. The design emphasizes straightforward installation without complex mounting hardware or special tools.
- Width
- 17.50" (444.50 mm)
- Depth
- 2" (50.80 mm)
- Height
- 1U
Highlights
- 1.90 kVA power capacity for reliable equipment support
- Twelve NEMA 5-20R outlets in compact 1U form factor
- Horizontal mounting orientation for standard rack installation
- 120V AC input and output voltage compatibility
- Single-phase operation with 20A input current
- NEMA 5-20P input plug for standard power connections
- RoHS and REACH environmental compliance
- 3-year limited warranty for long-term reliability
- Manufactured in the United States
- Rack-mountable design without remote management features
Specifications
| Specifications | |
|---|---|
| Manufacturer | PANDUIT CORP |
| Manufacturer Part Number | P12B19M |
| Brand Name | Panduit |
| Product Line | SmartZone |
| Product Model | P12B19M |
| Product Name | P12B19M Horizontal Basic Power Distribution Unit |
| Packaged Quantity | 1 |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Basic |
| Phase | Single Phase |
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type | NEMA 5-20R |
| Receptacle Detail | 12 x NEMA 5-20R |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Output Voltage Range | 120 V AC - 240 V AC |
| Power Rating (VA) | 1.90 kVA |
| Input Current | 20 A |
| Management | |
| Remote Outlet Switching | No |
| Physical Characteristics | |
| Mounting Orientation | Horizontal |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.60" (40.64 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 2" (50.80 mm) |
| Miscellaneous | |
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this Panduit PDU?
The Panduit P12B19M delivers 1.90 kVA power capacity, supporting equipment with a total load up to this rating. This capacity is distributed across twelve NEMA 5-20R outlets, providing adequate power for multiple rack-mounted devices in typical IT environments.
How many outlets does this PDU have and what type are they?
This power distribution unit features twelve NEMA 5-20R outlets, all providing 120V AC output. The consistent outlet type simplifies equipment connections and ensures compatibility with standard North American power cords for IT equipment.
What rack space does this PDU require for installation?
The P12B19M occupies 1U of vertical rack space with horizontal mounting orientation. Its dimensions of 1.60 inches high by 17.50 inches wide by 2 inches deep fit standard 19-inch rack configurations without requiring special mounting hardware.
What input voltage and plug type does this PDU use?
This PDU accepts 120V AC input power through a NEMA 5-20P plug. The single-phase design operates at 20A input current to deliver the full 1.90 kVA capacity to connected equipment through the twelve output outlets.
Does this PDU support remote outlet switching or management?
No, the P12B19M is a basic power distribution unit without remote outlet switching capabilities. It provides straightforward power distribution without network management features, making it suitable for environments where simple, reliable power delivery is the primary requirement.
What warranty coverage does Panduit provide for this PDU?
Panduit backs the P12B19M with a 3-year limited warranty, providing coverage for manufacturing defects and workmanship issues. This warranty period reflects the product's construction quality and expected reliability in commercial power distribution applications.
What power capacity is listed for this UPS?
The listed power specification is 1.90 kVA, which helps position the unit for the right load level and installation role.
How many outlets are available?
The product includes No, which helps buyers understand how many connected devices it can support in its intended deployment.
