StarTech. com N6PAT10BLS CAT6 Patch Cable - 10 ft Blue Slim Snagless RJ45 Gigabit Ethernet - 28 AWG LSZH
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This CAT6 patch cable meets ANSI/TIA-568-C.2 specifications, ensuring compliance with industry standards for Gigabit Ethernet performance. The 28 AWG copper wire construction provides optimal conductivity while maintaining the cable's slim form factor, and the tight buffer design enhances durability in high-flex applications.
The cable utilizes minimized Near-End Crosstalk (NEXT) technology to maintain signal integrity across all four twisted pairs, supporting data transfer rates up to 1 Gbps at 100 MHz bandwidth. The 50-micron gold plating on the RJ45 connectors ensures consistent electrical contact and corrosion resistance, while the snagless boots prevent latch breakage during frequent insertions and removals.
Key Product Advantages
This slim CAT6 patch cable delivers several distinct advantages for network administrators and IT professionals. The reduced diameter allows for better airflow in enclosed spaces and easier routing through tight cable management systems, while maintaining full CAT6 performance specifications.
Space Optimization
The 36% slimmer profile enables installation in crowded network cabinets and high-density patch panels where standard cables would create congestion.
- Reduced cable bulk
- Improved airflow
- Easier cable management
Installation Protection
Snagless boots prevent RJ45 connector clips from catching on adjacent ports or equipment during installation and maintenance.
- Prevents latch breakage
- Reduces installation errors
- Extends connector lifespan
Environmental Safety
The LSZH (Low Smoke Zero Halogen) jacket minimizes toxic emissions in case of fire, making it suitable for enclosed spaces and public installations.
- RoHS compliant
- REACH certified
- WEEE compliant
Deployment / Use Cases
This cable is specifically designed for patch panel applications where space optimization and frequent reconfiguration are common requirements. The slim profile makes it ideal for data centers, server rooms, and network closets with high port density, where standard cables would create excessive bulk and impede airflow.
Common deployment scenarios include connecting switches to patch panels, linking workstations to wall outlets, and interconnecting network equipment in rack-mounted configurations. The blue color provides visual identification for specific network segments or applications, while the flexible stranded construction allows for tight bends without performance degradation.
Data Center Patching
Connect servers, switches, and storage devices in high-density rack environments where space is limited and cable management is critical.
Office Network Infrastructure
Link wall outlets to patch panels in commercial buildings where multiple cables must route through conduits and cable trays.
Physical Profile
The cable features a distinctive blue LSZH jacket that provides both visual identification and fire safety characteristics. With a weight of just 1.90 ounces, this lightweight cable reduces stress on connectors and equipment ports while maintaining durability through its stranded copper construction. The flexible design allows for tight radius bends without kinking, making it suitable for installations where cables must navigate around obstacles or through crowded pathways.
- Weight
- 1.90 oz (53.86 g)
- Length
- 10 ft (3.05 m)
Highlights
- 10 ft (3.05 m) CAT6 patch cable with Gigabit Ethernet performance
- 36% slimmer profile for installations in crowded network spaces
- Snagless RJ45 connectors prevent latch damage during installation
- 28 AWG stranded copper conductors with gold-plated contacts
- LSZH (Low Smoke Zero Halogen) jacket for reduced toxic emissions
- Blue color for easy network segment identification
- Meets ANSI/TIA-568-C.2 CAT6 specifications
- Minimized Near-End Crosstalk (NEXT) for signal integrity
- Flexible construction for tight bending radius applications
- Lifetime warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | N6PAT10BLS |
| Brand Name | StarTech.com |
| Product Name | Cat.6 Patch Network Cable |
| Packaged Quantity | 1 Each |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Category 6 |
| Cable Characteristic | Patch Cable |
| Cable Length | 10 ft (3.05 m) |
| Connector Type on First End | RJ-45 Network - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Connector Plating | Gold |
| Shielding | No |
| Jacket Type | LSZH |
| Device Supported | Network Device |
| American Wire Gauge | 28 AWG |
| Boot Type | Snagless |
| Features | Minimized Near-End Crosstalk (NEXT),Flexible,Tight Buffer,Stranded |
| Physical Characteristics | |
| Color Family | Blue |
| Product Color | Blue |
| Weight (Approximate) | 1.90 oz (53.86 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum data transfer speed supported by this CAT6 cable?
This CAT6 patch cable supports Gigabit Ethernet speeds up to 1 Gbps with a bandwidth of 100 MHz. It meets ANSI/TIA-568-C.2 specifications for Category 6 performance, ensuring reliable data transmission for standard network applications including file transfers, video streaming, and VoIP communications.
How does the slim design benefit network installations?
The 36% slimmer profile reduces cable bulk in crowded network cabinets and patch panels, improving airflow and making cable management significantly easier. This design allows more cables to fit in the same space compared to standard CAT6 cables, which is particularly valuable in high-density data center environments and network closets with limited room.
What are the advantages of snagless RJ45 connectors?
Snagless connectors feature protective boots that cover the RJ45 latch, preventing it from catching on adjacent ports or equipment during installation and removal. This design reduces the risk of broken latches, which are a common failure point in frequently reconfigured network environments, extending the cable's usable lifespan and reducing maintenance issues.
What does LSZH jacket mean and why is it important?
LSZH stands for Low Smoke Zero Halogen, indicating the jacket material produces minimal smoke and no halogen gases when exposed to fire. This is crucial for enclosed spaces like data centers and office buildings, as it reduces toxic emissions and improves visibility during evacuation. The cable is also RoHS, REACH, and WEEE compliant for environmental safety.
Can this cable be used for PoE (Power over Ethernet) applications?
Yes, this CAT6 cable with 28 AWG copper conductors can support standard PoE applications. The stranded construction and gold-plated connectors ensure reliable power delivery alongside data transmission for devices like VoIP phones, wireless access points, and security cameras that receive power through their Ethernet connection.
What is the warranty coverage for this patch cable?
StarTech.com provides a lifetime warranty for this CAT6 patch cable, covering defects in materials and workmanship for the product's usable life. This warranty reflects the cable's durable construction with quality components including gold-plated connectors, LSZH jacket, and stranded copper conductors designed for long-term reliability in professional networking environments.
