TP-LINK TL-PoE10R Power over Ethernet Splitter - 12V DC - 2A Output - IEEE 802.3af Compliant - Plug-and-Play
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The TP-Link TL-POE10R Power over Ethernet Splitter provides a reliable solution for delivering both data and power to network devices through a single Ethernet cable. This compact unit converts PoE power from a compatible switch or injector into a usable DC output, eliminating the need for separate power adapters at remote installation points.
Designed for straightforward deployment, the splitter supports IEEE 802.3af standards and operates with plug-and-play simplicity. Its selectable power output allows compatibility with various low-voltage devices, while the 10/100Base-TX ports maintain network connectivity without configuration overhead.
Relevant factors for this section include Minimum Output Voltage, Maximum Output Voltage, Maximum Output Current, Input Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Technical Overview
The TL-POE10R delivers DC power within a 9-12V range at up to 2A maximum current, suitable for powering typical IP surveillance cameras, VoIP phones, and other PoE-capable endpoints. The splitter accepts PoE input through a single 10/100Base-TX port and outputs both data and converted power through a corresponding output port.
Compliance with IEEE 802.3af ensures interoperability with standard PoE infrastructure, while built-in protection mechanisms maintain stable operation. The unit's compact form factor and lightweight design facilitate discreet placement in ceiling mounts, wall enclosures, or equipment racks.
Relevant factors for this section include Minimum Output Voltage, Maximum Output Voltage, Maximum Output Current, Input Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This PoE splitter simplifies network deployments by reducing cable clutter and eliminating local power outlets at device locations. The selectable voltage output provides flexibility for different equipment requirements, while the compact design supports space-constrained installations.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Simplified Installation, Standards Compliance.
Simplified Installation
Delivers both data and power through a single Ethernet cable, reducing installation complexity and hardware requirements at remote endpoints.
- No separate power adapter needed
- Plug-and-play operation
- Standard RJ45 connections
Standards Compliance
Built to IEEE 802.3af specifications for reliable interoperability with existing PoE infrastructure and network equipment.
- Certified compatibility
- Stable power delivery
- Wide device support
Deployment / Use Cases
The TL-POE10R is ideal for extending PoE capabilities to devices that lack built-in PoE support or require specific voltage levels. Common applications include powering IP surveillance cameras in locations without convenient power outlets, supporting VoIP phones in office environments, and enabling wireless access points in ceiling-mounted configurations.
The splitter works seamlessly with TP-LINK's PoE switches and access points, including the TL-SF1008P Desktop PoE Switch and TL-WA601G Wireless Access Point. Its compatibility extends to various third-party IP cameras and phones that operate within the 9-12V DC range.
Relevant factors for this section include Minimum Output Voltage, Maximum Output Voltage, Maximum Output Current, Input Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Surveillance Systems
Power IP cameras in remote locations while maintaining network connectivity through a single cable run.
Voice over IP Deployments
Support desk phones without requiring separate power adapters at each workstation.
Physical Profile
Measuring 3.19" wide by 2.13" deep by 0.94" high (81 x 54 x 24 mm), the splitter features a compact footprint suitable for discreet placement. The lightweight construction and simple mounting options allow installation in ceiling voids, wall cavities, or equipment enclosures without significant space requirements.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.94" (24 mm), 3.19" (81 mm), 2.13" (54 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 3.19" (81 mm)
- Depth
- 2.13" (54 mm)
- Height
- 0.94" (24 mm)
What's in the Box
The package includes all necessary components for immediate deployment.
Package contents include TL-POE10R Power over Ethernet Splitter Power Cord RJ45 Cable Installation Guide, TL-POE10R Power over Ethernet Splitter. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- IEEE 802.3af compliant for standard PoE compatibility
- Selectable 9-12V DC output at up to 2A maximum current
- 10/100Base-TX input and output ports for network connectivity
- Plug-and-play operation requires no configuration
- Compact dimensions for discreet installation
- Compatible with IP cameras, VoIP phones, and wireless access points
- Includes power cord and RJ45 cable for immediate deployment
- RoHS compliant for environmental responsibility
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | TL-PoE10R |
| Brand Name | TP-Link |
| Product Model | TL-POE10R |
| Product Name | TL-POE10R Power over Ethernet Splitter |
| Product Type | PoE Splitter |
| Power Description | |
| Minimum Output Voltage | 9 V DC |
| Maximum Output Voltage | 12 V DC |
| Maximum Output Current | 2 A |
| Interfaces/Ports | |
| Input Ports | 1 x 10/100Base-TX |
| Output Ports | 1 x 10/100Base-TX |
| Physical Characteristics | |
| Height | 0.94" (24 mm) |
| Width | 3.19" (81 mm) |
| Depth | 2.13" (54 mm) |
| Miscellaneous | |
| Package Contents | TL-POE10R Power over Ethernet Splitter Power Cord RJ45 Cable Installation Guide |
| Compatibility | IP Cameras IP Phones TP-LINK TL-SF1008P Desktop PoE Switch TP-LINK TL-WA601G 108M Wireless Access Point TP-LINK TL-SF1008D 10/100M Desktop Switch |
| Certifications & Standards | FCC |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
FAQ
What devices are compatible with the TL-POE10R PoE splitter?
The splitter is compatible with various low-voltage network devices that operate within the 9-12V DC range, including IP surveillance cameras, VoIP phones, and wireless access points. It has been tested with TP-LINK equipment such as the TL-SF1008P PoE Switch and TL-WA601G Wireless Access Point, but works with any IEEE 802.3af compliant PoE source and compatible endpoint devices.
Does this splitter support gigabit network speeds?
The TL-POE10R features 10/100Base-TX ports, which support Fast Ethernet speeds up to 100 Mbps. It does not support gigabit (1000 Mbps) network connections. For applications requiring higher bandwidth, consider a PoE splitter specifically designed for gigabit compatibility while maintaining the necessary power output specifications.
What power output does the splitter provide?
The splitter delivers DC power within a 9-12V range with a maximum output current of 2A. This selectable voltage output allows compatibility with various devices that require different operating voltages within this range. The actual voltage delivered depends on the connected device's requirements and the PoE source's capabilities.
Is any configuration required for installation?
No configuration is required. The TL-POE10R operates as a plug-and-play device. Simply connect the input port to a PoE source (such as a PoE switch or injector), connect the output port to the target device, and the splitter automatically converts and delivers both data and power without any software setup or manual adjustments.
What certifications does this product have?
The splitter is FCC certified for electromagnetic compatibility and RoHS compliant, meaning it meets Restriction of Hazardous Substances standards for environmental responsibility. It also complies with IEEE 802.3af PoE standards, ensuring interoperability with other compliant networking equipment in commercial and residential installations.
What is included in the package?
The package contains the TL-POE10R Power over Ethernet Splitter unit, a power cord for optional direct power connection, an RJ45 Ethernet cable for network connectivity, and an installation guide. These components provide everything needed for immediate deployment in typical PoE extension scenarios without requiring additional accessories.
