APC by Schneider Electric AP7568 Basic Rack PDU - 12. 5kVA - 208V - 0U Vertical Mount - 30x C13 & 6x C19 Outlets - 3ft Cord
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This basic PDU operates at 208V input and output, delivering 12.5kVA of power capacity for demanding IT loads. The CS8365C plug connects to standard 208V power sources, while the 30 C13 and 6 C19 outlets accommodate both standard and high-power equipment connections.
The vertical mounting design positions the PDU along the side of the rack with a 0U footprint, making efficient use of rack real estate. The 3-foot input cord provides flexibility in power source placement, and the black finish matches standard rack aesthetics.
This section brings together practical product details such as PDU Type, Plug/Connector Type, Receptacle Type, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The AP7568 combines high-density power distribution with space-saving design, offering several advantages for modern IT infrastructure deployment.
Space Optimization
Zero U vertical mounting preserves all horizontal rack space for servers, switches, and other critical equipment, maximizing rack utilization efficiency.
- Mounts vertically along rack side
- 0U rack height requirement
- Does not consume equipment U space
High-Density Power Distribution
With 36 total outlets (30 C13 + 6 C19), this PDU supports numerous devices while maintaining proper power distribution for mixed equipment environments.
- 30 standard C13 outlets
- 6 high-power C19 outlets
- 12.5kVA total capacity
Simplified Deployment
The toolless mounting kit and included installation hardware enable rapid deployment without specialized tools or technical expertise.
- Toolless mounting brackets included
- Complete installation kit
- Clear documentation provided
Deployment / Use Cases
The APC Basic Rack PDU is engineered for data centers, server rooms, and network closets where reliable power distribution and space efficiency are critical. Its 12.5kVA capacity and 36 outlets make it suitable for dense server deployments, network equipment racks, and storage array installations.
The vertical 0U design is particularly valuable in full-height racks where every horizontal U of space is allocated to revenue-generating equipment. The mix of C13 and C19 outlets supports both standard servers and higher-power devices like blade chassis or storage systems that require C19 connections.
Data Center Server Racks
Power multiple servers, switches, and storage units in a single rack while maintaining zero U footprint for maximum equipment density.
Network Equipment Rooms
Distribute 208V power to networking gear, security appliances, and communication equipment with the space-saving vertical mounting design.
Physical Profile
The PDU features a slim profile measuring 70" in height, 2.20" in width, and 3.50" in depth, designed to fit vertically in standard 19-inch racks. The black finish blends with typical rack equipment, while the 15.32 lb weight ensures stable mounting without excessive load on rack rails. The vertical orientation and side placement provide easy access to all outlets while maintaining clean cable routing along the rack's side channels.
- Width
- 2.20" (56 mm)
- Depth
- 3.50" (89 mm)
- Height
- 0U
- Weight
- 15.32 lb (6949.04 g)
- Length
- 3 ft (0.90 m)
What's in the Box
The package includes all necessary components for immediate deployment and operation.
Highlights
- 12.5kVA power capacity at 208V for demanding IT loads
- 36 total outlets: 30 C13 and 6 C19 for versatile equipment support
- Zero U vertical mounting preserves all horizontal rack space
- Toolless installation with included mounting hardware
- 3-foot input cord provides placement flexibility
- Black finish matches standard rack aesthetics
- RoHS compliant for environmental responsibility
- 2-year limited warranty for peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | AP7568 |
| Brand Name | APC by Schneider Electric |
| Product Line | Basic Rack |
| Product Name | Basic Rack 12.5k VA PDU |
| Packaged Quantity | 1 Each |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Basic |
| Plug/Connector Type | CS8365C |
| Receptacle Type | IEC 60320 C13,IEC 60320 C19 |
| Receptacle Detail | 30 x IEC 60320 C13,6 x IEC 60320 C19 |
| Power Description | |
| Input Voltage | 208 V |
| Output Voltage | 208 V AC |
| Power Rating (VA) | 12.50 kVA |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Mounting Orientation | Vertical |
| Mount Type | Rack-mountable |
| Placement | Side |
| Rack Height | 0U |
| Cord Length | 3 ft (0.90 m) |
| Height | 70" (1778 mm) |
| Width | 2.20" (56 mm) |
| Depth | 3.50" (89 mm) |
| Weight (Approximate) | 15.32 lb (6949.04 g) |
| Miscellaneous | |
| Package Contents | Basic Rack 12.5k VA PDU Cord retention bracket(s) Documentation CD Installation guide Rack mounting brackets Toolless mounting kit |
| Country of Origin | India |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the power capacity of the APC AP7568 PDU?
The APC AP7568 Basic Rack PDU delivers 12.5kVA of power capacity at 208V. This rating indicates the maximum apparent power the unit can distribute to connected equipment, making it suitable for dense server deployments and mixed IT environments requiring substantial power distribution.
How many outlets does this PDU have and what types?
This PDU features 36 total outlets: 30 IEC 60320 C13 outlets for standard equipment and 6 IEC 60320 C19 outlets for higher-power devices. The C13 outlets support typical servers and networking gear, while the C19 outlets accommodate equipment with higher power requirements such as blade servers or storage arrays.
What does 'Zero U' mounting mean for this PDU?
Zero U mounting means the PDU consumes no horizontal rack units (U) in the standard 19-inch rack. Instead, it mounts vertically along the side of the rack, preserving all horizontal space for servers, switches, and other equipment. This design maximizes rack utilization efficiency while providing full power distribution capabilities.
What voltage does this PDU require and deliver?
The APC AP7568 operates at 208V for both input and output. It connects to 208V power sources via the CS8365C plug and delivers 208V AC power to all connected equipment. This voltage is standard for three-phase power distribution in North American data centers and commercial installations.
Is installation difficult for this vertical-mount PDU?
Installation is straightforward with the included toolless mounting kit. The package contains all necessary brackets and hardware for vertical side mounting without requiring specialized tools. The installation guide provides clear instructions, and the toolless design enables rapid deployment by IT staff without extensive technical expertise.
What warranty coverage does this PDU include?
The APC AP7568 Basic Rack PDU comes with a 2-year limited warranty from the manufacturer. This warranty covers defects in materials and workmanship under normal use conditions. The unit is also RoHS compliant, meeting environmental standards for hazardous substance restrictions.
What power capacity is listed for this UPS?
The listed power specification is 12.50 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 208 V, which helps position the unit for the right load level and installation role.
