Raritan PX3-5495X2-P1 Monitored Rack PDU - 10 kVA - 230V AC Input - 12x C19 & 36x C13 Outlets - NEMA L6-30P - 0U Vertical Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This single-phase PDU operates with a 30A input current and utilizes a NEMA L6-30P (2P3W) plug configuration, supporting robust power delivery for enterprise applications. The 10 kVA power rating translates to substantial capacity for powering multiple devices simultaneously, making it suitable for rack enclosures with high power demands. The unit's electrical design ensures stable output voltage regulation, maintaining 208V AC across all outlets for consistent device performance.
Network management is facilitated through an RJ-45 port, enabling integration into existing IT infrastructure for remote monitoring and control. Supported protocols include HTML, JSON-RPC, SSH, Telnet, MODBUS/TCP, SNMPv3, TFTP, DHCP/PXE, and SSH(CLI), offering flexibility for various network environments and management systems. This protocol diversity allows seamless compatibility with data center infrastructure management (DCIM) tools and custom monitoring solutions.
This section brings together practical product details such as PDU Type, Phase, Plug/Connector Type, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The PX3-5495X2-P1 combines high power capacity with intelligent monitoring features, providing a reliable power distribution solution for modern data centers. Its 10 kVA rating supports demanding server loads, while the monitored functionality enables proactive power management to optimize efficiency and prevent downtime.
High-Density Outlet Configuration
With 12 C19 and 36 C13 outlets, this PDU accommodates diverse equipment types, from servers with high-power C19 connections to networking gear with standard C13 plugs, reducing the need for additional power strips.
- 12 x C19 for high-power devices
- 36 x C13 for standard equipment
- Total of 48 outlets per unit
Comprehensive Network Management
Multiple protocol support including SNMPv3, MODBUS/TCP, and SSH allows integration with various monitoring systems, providing detailed power metrics and remote control capabilities for efficient infrastructure management.
- SNMPv3 for secure monitoring
- MODBUS/TCP for industrial systems
- SSH for command-line access
Space-Optimized Rack Design
The 0U vertical mounting configuration preserves valuable rack space for equipment, while the slim 2.10" width ensures compatibility with standard rack depths without interfering with cable management.
- 0U rack height
- Vertical orientation
- Slim 2.10" profile
Deployment / Use Cases
This monitored rack PDU is engineered for data center environments where reliable power distribution and management are critical. It serves as a central power source for server racks containing multiple devices, providing both high-capacity power delivery and monitoring capabilities for infrastructure oversight.
In colocation facilities, the PDU enables remote power monitoring for hosted equipment, allowing providers to track power usage and respond to issues without physical access. Enterprise server rooms benefit from its outlet density and management features, supporting virtualization clusters, storage arrays, and network equipment while maintaining power visibility. The unit's 230V AC input compatibility makes it suitable for regions with this voltage standard, while the 208V AC output aligns with common server power requirements in North American data centers.
Data Center Server Racks
Power high-density server configurations with multiple C19 and C13 connections, providing monitored power for critical applications and virtualization platforms.
Network Equipment Cabinets
Distribute power to switches, routers, and other networking gear while monitoring consumption through network management protocols for optimal operation.
Physical Profile
The PDU features a vertical mounting design with dimensions of 85.80" height, 2.10" width, and 2.60" depth, engineered for installation in standard 19-inch rack enclosures. Its 0U rack height configuration mounts vertically along the rack side, preserving horizontal space for equipment. The unit weighs 22.05 lb (10000 g), with construction suitable for data center environments. The vertical orientation facilitates cable management along the rack's side channels, while the slim profile minimizes interference with equipment installation and airflow.
- Width
- 2.10" (53.34 mm)
- Depth
- 2.60" (66.04 mm)
- Height
- 0U
- Weight
- 22.05 lb (10000 g)
Highlights
- 10 kVA power capacity for high-density server racks
- 12 IEC 60320 C19 and 36 IEC 60320 C13 outlets
- NEMA L6-30P (2P3W) plug with 230V AC input
- Monitored PDU with network management via RJ-45
- 0U vertical rack mounting with slim 2.10" width
- Supports HTML, JSON-RPC, SSH, SNMPv3, MODBUS/TCP protocols
- Overload protection for connected equipment safety
- 2-year limited warranty for reliable operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | PX3-5495X2-P1 |
| Brand Name | Raritan |
| Product Series | PX |
| Product Model | PX3-5495X2-P1 |
| Product Name | Rack PDU PX3-5495X2-P1 |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Monitored |
| Phase | Single Phase |
| Plug/Connector Type | NEMA L6-30P (2P3W) |
| Plug/Connector Detail | 2 x NEMA L6-30P (2P3W) |
| Receptacle Type | IEC 60320 C19,IEC 60320 C13 |
| Receptacle Detail | 12 x IEC 60320 C19,36 x IEC 60320 C13 |
| Protection Type | Overload Protection |
| Power Description | |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Power Rating (VA) | 10 kVA |
| Input Current | 30 A |
| Management | |
| Management | Protocols: HTML JSON-RPC SSH Telnet MODBUS/TCP SNMPv3 TFTP DHCP/PXE SSH(CLI) |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Mounting Orientation | Vertical |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Height | 85.80" (2179.32 mm) |
| Width | 2.10" (53.34 mm) |
| Depth | 2.60" (66.04 mm) |
| Weight (Approximate) | 22.05 lb (10000 g) |
| Miscellaneous | |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the power capacity of this Raritan PDU?
The Raritan PX3-5495X2-P1 delivers 10 kVA (kilovolt-amperes) of power capacity, which provides substantial power distribution for high-density server racks and networking equipment in data center environments.
How many outlets does this PDU have and what types?
This PDU features 48 total outlets: 12 IEC 60320 C19 outlets for high-power devices like servers and 36 IEC 60320 C13 outlets for standard equipment such as switches and routers, accommodating diverse power needs in rack configurations.
What input voltage and plug type does this PDU use?
The PDU requires 230 V AC input power and uses a NEMA L6-30P (2P3W) plug configuration, which is designed for higher-voltage applications commonly found in data centers and commercial installations.
How is this PDU mounted in a rack?
This PDU is designed for 0U vertical mounting, meaning it installs vertically along the side of a standard 19-inch rack without consuming horizontal rack units, preserving space for equipment while providing power distribution along the rack's height.
What management capabilities does this monitored PDU offer?
The PDU includes network management through an RJ-45 port, supporting protocols like SNMPv3, MODBUS/TCP, SSH, and HTML for remote monitoring, power usage tracking, and control integration with data center management systems.
What protection features are included with this PDU?
This PDU includes overload protection to safeguard connected equipment against excessive current draw, helping prevent damage to servers and networking gear while ensuring reliable power distribution in critical infrastructure environments.
What power capacity is listed for this UPS?
The listed power specification is 10 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 230 V AC, which helps position the unit for the right load level and installation role.
