Reolink WCEO5MPO6PTAF E540 5MP Outdoor PT Security Camera - Color Spotlight Night Vision - 3x Optical Zoom - Wi-Fi/Bluetooth/PoE - IP65 Weatherproof
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The Reolink E540 incorporates a 1/2.7" CMOS image sensor that captures 5-megapixel video at 20 frames per second using H.264 compression. The varifocal lens provides 3x optical zoom with a focal length range of 2.8mm to 8mm, allowing for flexible field of view adjustment from wide-angle to telephoto perspectives. The camera's adjustable field of view spans horizontally from 90° to 50° and vertically from 53° to 30°, enabling precise coverage area configuration.
Network connectivity includes both wired Fast Ethernet and dual-band wireless options, supporting comprehensive protocols including HTTPS, SSL, TCP/IP, RTSP, ONVIF, and P2P for seamless integration with various surveillance systems. The camera features built-in storage support for memory cards up to 512GB, providing local recording capability without requiring external network video recorders.
Key Product Advantages
The Reolink E540 stands out with its combination of high-resolution imaging, intelligent detection, and flexible installation options. The camera's spotlight-enhanced color night vision maintains detailed color imagery in low-light conditions, while the 10 infrared LEDs provide traditional black-and-white night vision when complete darkness requires it. This dual-approach to nighttime surveillance ensures optimal image quality regardless of lighting conditions.
Smart Detection Technology
Advanced AI algorithms distinguish between people, vehicles, and animals, reducing false alarms and focusing attention on relevant security events. The system includes audio detection, motion detection with customizable zones, and human detection for precise event triggering.
- Person/Vehicle/Animal Detection
- Audio Detection
- Motion Detection Zones
- Human Detection Focus
Pan-Tilt Flexibility
The PT mount design allows for manual adjustment of viewing angles, while preset point functionality enables quick positioning to frequently monitored areas. This flexibility complements the optical zoom capability for comprehensive area coverage.
- Manual Pan-Tilt Adjustment
- Preset Point Memory
- Wide Coverage Area
- Precise Positioning
Deployment / Use Cases
The Reolink E540 is engineered for diverse surveillance applications where reliable outdoor monitoring is essential. Its compact form factor and flexible mounting options make it suitable for residential properties, small businesses, retail environments, and perimeter security installations. The camera's weatherproof construction ensures consistent performance in rain, snow, and temperature extremes.
For residential security, the E540 provides comprehensive property monitoring with smart detection that filters out pets and wildlife while alerting homeowners to human presence. In commercial applications, the camera supports retail loss prevention, parking lot surveillance, and building perimeter security with its combination of high-resolution imaging and intelligent analytics. The ONVIF compliance ensures compatibility with most professional surveillance systems, while the standalone operation with local storage offers a complete solution without requiring additional recording equipment.
Physical Profile
The Reolink E540 features a compact spherical design with a 3.54-inch (90mm) diameter and lightweight construction at just 1.01 pounds (458g). The PT mount provides flexible installation on walls, ceilings, or poles, with weatherproof sealing that maintains IP65 protection against dust and water jets. The camera operates reliably across a wide temperature range from 14°F to 131°F (-10°C to 55°C) and humidity conditions from 20% to 85%, ensuring year-round performance in diverse climates.
- Weight
- 1.01 lb (458 g)
- Length
- 2.8 mm (0.11")
Highlights
- 5MP Super HD resolution (2560x1920) for detailed surveillance footage
- Color spotlight night vision with 40 ft (12.19 m) infrared/color range
- 3x optical zoom with varifocal 2.8-8mm lens for flexible field adjustment
- Smart detection distinguishes people, vehicles, and animals
- Dual-band Wi-Fi and Bluetooth for wireless connectivity options
- PoE and 12V DC power support for flexible installation
- IP65 weatherproof rating for reliable outdoor operation
- Local storage support for microSD cards up to 512GB
- ONVIF compliant for professional system integration
- Compact PT mount design with manual pan-tilt adjustment
Specifications
| Specifications | |
|---|---|
| Manufacturer | Reolink Digital Technology Co., Ltd. |
| Manufacturer Part Number | WCEO5MPO6PTAF |
| Brand Name | Reolink |
| Product Series | E |
| Product Model | E540 |
| Product Name | Smart 5MP HD Dual-Band Wi-Fi PT Security Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 40 ft (12.19 m) |
| Night Vision Type | Infrared/Color |
| Number of IR LEDs | 10 |
| Virtual Assistant Supported | Smart Home,Google Assistant |
| Infrared (IR) Cut-off Filter | Yes |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.7" |
| Color Supported | Color |
| Field of View | Horizontal: 90°-50°,Vertical: 53°-30° |
| Effective Camera Resolution | 5 Megapixel |
| Video | |
| Video Formats | H.264 |
| Maximum Video Resolution | 2560 x 1920 |
| Maximum Frame Rate | 20 fps |
| Audio | |
| Audio Support | Yes |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 2.8 mm (0.11") |
| Maximum Focal Length | 8 mm (0.31") |
| Lens Included | Yes |
| Maximum Aperture | f/1.6 |
| Optical Zoom | 3x |
| Exposure | |
| PTZ Modes | Preset Point |
| Network & Communication | |
| Connectivity Technology | Wired & Wireless |
| Remote Management | Yes |
| Wireless Technology | Wi-Fi,Bluetooth |
| Ethernet Technology | Fast Ethernet |
| Protocols | HTTPS,SSL,TCP/IP,UDP,HTTP,IPv4,UPnP,RTSP,RTMP,ONVIF,SMTP,NTP,DHCP,DNS,DDNS,FTP,P2P |
| Storage | |
| Storage Type | Memory Card |
| Internal Memory | 512 GB |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | PoE,DC |
| Physical Characteristics | |
| Mount Type | PT Mount |
| Form Factor | Compact |
| Durability | Weather Proof |
| Diameter | 3.54" (90 mm) |
| Weight (Approximate) | 1.01 lb (458 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Minimum Operating Humidity | 20% |
| Maximum Operating Humidity | 85% |
| Miscellaneous | |
| Features | Day/Night,Infrared Detection,Audio Detection,Built-in Infrared Illuminator,Built-in Microphone,LED Spotlight,Motion Detection,Human Detection,Built-in Speaker,Smart Tracking,HTTPS Encryption |
| Indoor/Outdoor | Outdoor |
| Ingress Protection Rating | IP65 |
| Warranty | |
| Limited Warranty | 2 Year |
FAQ
What is the maximum resolution of the Reolink E540 camera?
The Reolink E540 captures 5-megapixel Super HD video at 2560 x 1920 resolution. This high-resolution imaging provides clear, detailed footage that allows for identification of faces, license plates, and other important details in surveillance scenarios. The camera maintains this resolution at up to 20 frames per second using efficient H.264 compression for optimal bandwidth usage.
How does the night vision system work on this camera?
The E540 features dual-mode night vision with both infrared and color capabilities. During low-light conditions, the camera's built-in LED spotlight provides color night vision, while 10 infrared LEDs deliver traditional black-and-white infrared night vision for complete darkness. The system automatically switches between modes based on lighting conditions and provides clear surveillance up to 40 feet (12.19 meters) in total darkness.
What connectivity options does this security camera support?
The camera offers both wired and wireless connectivity options. For wired connections, it includes Fast Ethernet (RJ-45) with PoE support for combined power and data transmission. Wireless connectivity includes dual-band Wi-Fi and Bluetooth for flexible installation without cabling constraints. The camera supports comprehensive network protocols including HTTPS, SSL, RTSP, ONVIF, and P2P for seamless integration with various surveillance systems.
Can this camera be used outdoors in all weather conditions?
Yes, the Reolink E540 is specifically designed for outdoor use with an IP65 weatherproof rating. This certification ensures protection against dust ingress and water jets from any direction, making the camera suitable for installation in rain, snow, and other challenging weather conditions. The camera operates reliably across a temperature range of 14°F to 131°F (-10°C to 55°C) and humidity from 20% to 85%.
What smart detection features does the E540 include?
The camera incorporates advanced AI detection that distinguishes between people, vehicles, and animals to reduce false alarms. Additional detection capabilities include motion detection with customizable zones, audio detection for sound-based triggering, and human detection that focuses specifically on human forms. These smart features work together to provide relevant security alerts while filtering out irrelevant motion from pets, wildlife, or environmental factors.
How is video storage handled on this camera?
The Reolink E540 supports local storage through a microSD card slot that accommodates cards up to 512GB capacity. This allows for continuous recording or event-based recording directly on the camera without requiring external network video recorders. The camera also supports cloud storage options and can integrate with network video recorders through its ONVIF compliance and RTSP streaming capabilities for centralized storage solutions.
