RUCKUS 8200-24 Ethernet Switch - 24 Ports - Manageable - Gigabit Ethernet, 25 Gigabit Ethernet - 1000Base-T, 25GBase-X - 3 Layer - - W (ICX8200-24)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Total Number of Network Ports: 24
Network (RJ-45): Yes
Uplink Port: Yes
Modular: Yes
Stack Port: Yes
Port/Expansion Slot Details: 4 x 25 Gigabit Ethernet Uplink/Stacking,24 x Gigabit Ethernet Network
Media Type Supported: Optical Fiber,Twisted Pair
Ethernet Technology: Gigabit Ethernet,25 Gigabit Ethernet
Network Technology: 1000Base-T,25GBase-X
Total Number of Expansion Slots: 4
Expansion Slot Type: SFP28
Layer Supported: 3
Networking Standards: IEEE 802.3ad,IEEE 802.3bz,IEEE 802.1ab,IEEE 802.3,IEEE 802.3x,IEEE 802.1p,IEEE 802.1br,IEEE 802.3ae,IEEE 802.3u,IEEE 802.1Q,IEEE 802.1D,IEEE 802.3z,IEEE 802.1w,IEEE 802.1s,IEEE 802.3bt,IEEE 802.1AX,IEEE 802.1x,IEEE 802.3az,IEEE 802.3ab
Manageable: Yes
Input Voltage: 120 V AC,230 V AC
Power Source: AC,Power Supply
Power Consumption: 31 W
Plug/Connector Type: C14
Form Factor: Wall Mountable,DIN Rail Mountable,Rack-mountable
Height: 1.73" (43.94 mm)
Width: 17.32" (439.93 mm)
Depth: 11.02" (279.91 mm)
Weight (Approximate): 8.25 lb (3740 g)
TAA Compliant: Yes
- Cascade to other network devices through the uplink port to expand your local area network
- Stack port provides an easy and hassle-free way to extend your office network
- Features 24 networking ports to meet the requirements of the most demanding workgroups
- Can work as layer 3 routing for scalable network design
- With Wall mounting feature, you can conveniently install the switch while keeping the wires and cables organized
- Management capability provides control over setup and configuration of your network
- Gigabit Ethernet port for ultra-fast network speeds
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
[custom-specifications]
| Specifications | |
| Manufacturer | CommScope, Inc |
| Manufacturer Part Number | ICX8200-24 |
| Manufacturer Website Address | http://www.commscope.com |
| Brand Name | RUCKUS |
| Product Series | ICX 8200 |
| Product Model | 8200-24 |
| Product Name | 8200-24 Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Stack Port | Yes |
| Port/Expansion Slot Details | 4 x 25 Gigabit Ethernet Uplink/Stacking,24 x Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | Gigabit Ethernet,25 Gigabit Ethernet |
| Network Technology | 1000Base-T,25GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP28 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3ad,IEEE 802.3bz,IEEE 802.1ab,IEEE 802.3,IEEE 802.3x,IEEE 802.1p,IEEE 802.1br,IEEE 802.3ae,IEEE 802.3u,IEEE 802.1Q,IEEE 802.1D,IEEE 802.3z,IEEE 802.1w,IEEE 802.1s,IEEE 802.3bt,IEEE 802.1AX,IEEE 802.1x,IEEE 802.3az,IEEE 802.3ab |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | AC,Power Supply |
| Power Consumption | 31 W |
| Plug/Connector Type | C14 |
| Physical Characteristics | |
| Form Factor | Wall Mountable,DIN Rail Mountable,Rack-mountable |
| Height | 1.73" (43.94 mm) |
| Width | 17.32" (439.93 mm) |
| Depth | 11.02" (279.91 mm) |
| Weight (Approximate) | 8.25 lb (3740 g) |
| Miscellaneous | |
| TAA Compliant | Yes |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
[/custom-user-manual]
