Ruckus Wireless ICX8200-48PF2-E RUCKUS Ethernet Switch - 48 Port PoE+ with 740W Budget - 4 x 25GbE SFP28 Uplinks - Layer 3 Managed - Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates at Layer 3, supporting advanced routing protocols and features like DHCP snooping and access control lists (ACLs) for enhanced network security and traffic management. It complies with a comprehensive set of IEEE networking standards, including 802.3af/at/bt for PoE, 802.3bz for 2.5G/5GBASE-T, and 802.1Q for VLAN tagging, ensuring interoperability in mixed-vendor environments.
The hardware architecture includes hot-swappable power supplies and supports In-Service Software Upgrade (ISSU), allowing firmware updates without network downtime. Data link protocols such as HTTP and HTTPS enable secure web-based management, while the switch's 854W power consumption rating reflects its capacity to handle full PoE load across all ports.
Relevant factors for this section include Data Link Protocols, Features, Total Number of Network Ports, Uplink Port. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ICX8200-48PF2-E stands out with its balanced combination of port density, PoE power, and high-speed uplink readiness. Its 740W PoE budget is substantial for modern IoT and unified communications deployments, eliminating the need for external power injectors and simplifying cabling.
High-Density PoE+ Connectivity
Forty-eight Gigabit Ethernet ports with PoE+ support deliver both data and power to connected devices, streamlining infrastructure for wireless networks, security systems, and digital signage.
- Eliminates separate power runs
- Centralized power management
- Scalable for growing device counts
Future-Ready Uplink Architecture
Four 25GbE SFP28 ports provide flexible options for high-speed stacking, fiber uplinks, or aggregation, ensuring the switch can handle increased bandwidth demands from connected access points and servers.
- Supports optical fiber for long-distance links
- Enables switch stacking for simplified management
- Provides headroom for network expansion
Deployment / Use Cases
This switch is ideal for medium to large enterprise environments where reliable, high-performance access switching is critical. Its rack-mountable form factor and comprehensive management features make it a fit for centralized IT deployments in offices, schools, and healthcare facilities.
Common deployment scenarios include serving as the primary access switch in a campus network, aggregating traffic from multiple floors or buildings, or acting as a distribution layer switch in a hierarchical network design. The support for wall and DIN rail mounting also allows for flexible installation in space-constrained locations like retail kiosks or industrial control panels.
Campus Network Access
Deploy at the edge of a campus network to connect end-user devices, wireless access points, and IP phones, leveraging Layer 3 features for segmented network traffic and improved security.
Unified Communications Backbone
Power and connect VoIP phones, video conferencing systems, and collaboration endpoints with consistent PoE delivery and low-latency switching for clear audio and video quality.
Physical Profile
The switch features a compact 1U rack-mountable chassis with a depth of 14.57 inches, fitting standard 19-inch racks. Its brushed metal finish and clean front-panel design present a professional appearance in server rooms and network closets. Optional wall-mount and DIN rail kits provide installation flexibility for environments where rack space is limited or where decentralized switching is preferred.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.73" (44 mm), 17.32" (440 mm), 14.57" (370 mm), 12.15 lb (5510 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.32" (440 mm)
- Depth
- 14.57" (370 mm)
- Height
- 1.73" (44 mm)
- Weight
- 12.15 lb (5510 g)
What's in the Box
The package includes all essential components for immediate deployment.
Package contents include ICX8200-48PF Ethernet Switch, 1 x Power Supply, 1 x Fan. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 48 Gigabit Ethernet ports with PoE+ support for simultaneous data and power delivery
- 740W total PoE budget to power high-demand devices like wireless APs and PTZ cameras
- Four 25GbE SFP28 uplink/stacking ports for high-speed backbone connectivity
- Layer 3 managed switching with advanced routing and security features
- Fanless, energy-efficient design for quiet operation in office environments
- Rack-mountable, wall-mountable, and DIN rail-mountable form factors
- Hot-swappable power supplies and In-Service Software Upgrade (ISSU) capability
- Comprehensive IEEE standards compliance including 802.3af/at/bt PoE and 802.1Q VLAN
- Lifetime limited warranty with three-year remote TAC support
- Environmental compliance with WEEE, RoHS, and REACH directives
Specifications
| Specifications | |
|---|---|
| Manufacturer | CommScope, Inc |
| Manufacturer Part Number | ICX8200-48PF2-E |
| Brand Name | RUCKUS |
| Product Series | ICX 8200 |
| Product Model | ICX8200-48PF |
| Product Name | ICX8200-48PF Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Data Link Protocols | HTTP,HTTPS |
| Features | Fanless,In-Service Software Upgrade (ISSU),Hot-swappable,DHCP Snooping,Access Control List,Energy Efficient |
| Interfaces/Ports | |
| Total Number of Network Ports | 48 |
| Uplink Port | Yes |
| Stack Port | Yes |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet PoE+,4 × 25 Gigabit Ethernet SFP28 Stacking/ Uplink-Ports |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | 25 Gigabit Ethernet,Gigabit Ethernet |
| Network Technology | 25GBase-X,10/100/1000Base-T |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP28 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1ab,IEEE 802.1D,IEEE 802.1p,IEEE 802.1w,IEEE 802.1s,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.1AX,IEEE 802.3ae,IEEE802.3af,IEEE 802.3at,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z,IEEE 802.1Q,IEEE 802.1br,IEEE 802.3az,IEEE 802.3bt |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 740 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply,PoE,AC |
| Power Consumption | 854 W |
| Plug/Connector Type | C14 |
| Physical Characteristics | |
| Form Factor | Rack-mountable,Wall Mountable,DIN Rail Mountable |
| Height | 1.73" (44 mm) |
| Width | 17.32" (440 mm) |
| Depth | 14.57" (370 mm) |
| Weight (Approximate) | 12.15 lb (5510 g) |
| Miscellaneous | |
| Package Contents | ICX8200-48PF Ethernet Switch 1 x Power Supply 1 x Fan |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | Lifetime |
| Additional Warranty Information | Three-year remote TAC support |
User Manual
FAQ
What is the PoE budget of this switch, and how many devices can it power?
The RUCKUS ICX8200-48PF2-E has a 740W PoE budget. This substantial power allocation can support numerous PoE+ devices simultaneously, such as 802.11ax wireless access points, IP cameras with heaters, or VoIP phones. The exact number of devices depends on each device's power draw, but the budget is designed for high-density deployments common in modern offices and campuses.
How many uplink ports does this switch have, and what speeds do they support?
This switch includes four 25 Gigabit Ethernet SFP28 ports dedicated to uplink and stacking functions. These ports support high-speed connections to network cores, aggregation switches, or other ICX switches for stacking. They accept SFP28 optical or DAC cables, providing flexibility for fiber or copper uplinks over longer distances or within racks.
Is this switch Layer 2 or Layer 3 capable?
The ICX8200-48PF2-E is a Layer 3 managed switch. It supports advanced routing protocols, inter-VLAN routing, and features like access control lists (ACLs) and DHCP snooping. This allows for more sophisticated network segmentation, improved traffic management, and enhanced security compared to basic Layer 2 switches, making it suitable for larger, more complex network designs.
Can this switch be mounted in a standard server rack?
Yes, this switch is designed for standard 19-inch server racks and occupies 1U of vertical space (1.73 inches in height). Its dimensions are 17.32 inches wide and 14.57 inches deep, compatible with most rack enclosures. It also includes mounting options for wall and DIN rail installations, offering flexibility for various deployment scenarios outside of traditional racks.
What management features are available on this switch?
As a fully manageable switch, it supports web-based management via HTTP and HTTPS, CLI access, and SNMP for monitoring. Key management features include VLAN configuration, QoS settings, port mirroring, and comprehensive system logging. The In-Service Software Upgrade (ISSU) capability allows for firmware updates without disrupting network traffic, which is critical for maintaining uptime in production environments.
What type of warranty and support does this switch include?
RUCKUS provides a lifetime limited warranty for this switch, covering defects in materials and workmanship. Additionally, it includes three years of remote Technical Assistance Center (TAC) support, providing access to expert assistance for configuration, troubleshooting, and best practices. This support structure ensures long-term reliability and helps resolve issues quickly during deployment and operation.
