Server Technology C3B36RL-2CJE0AT4 36-Outlet PDU - Basic - NEMA L6-30P - 18x C13 & 18x CX - 5 kW - 0U Rack Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This PDU operates with a 30 A input current at 60 Hz, providing stable power distribution for up to 36 devices. The inclusion of UL 489 rated magnetic-hydraulic circuit breakers or UL 248 fuses ensures compliance with UL and IEC 62368-1 requirements for branch circuit protection, safeguarding connected equipment against electrical faults.
The unit supports flexible mounting with standard button mounts and provisions for custom brackets, allowing installation in various rack and cabinet configurations. Environmental resilience is confirmed with an operating temperature range of 32°F to 140°F (0°C to 60°C) and humidity tolerance from 8% to 90%, making it suitable for controlled data center climates.
Relevant factors for this section include PDU Type, Plug/Connector Type, Receptacle Type, Input Voltage. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This PDU combines robust power distribution with advanced safety and flexibility features tailored for modern data centers. The RamLock locking outlet mechanism secures C14 and C20 plugs mechanically, preventing accidental disconnections in high-vibration environments.
HDOT Cx Outlet Versatility
The CX outlet is a UL-tested hybrid design that accepts both C14 and C20 plugs, future-proofing your power infrastructure by accommodating a broader range of device connectors without requiring adapter cables.
- Hybrid C13/C19 design
- UL tested
- Accepts C14 and C20 plugs
High-Temperature Operation
Certified for reliable performance in environments up to 60°C, this PDU meets the thermal demands of high-density server racks and hot aisle containment systems, ensuring continuous operation without derating.
- Tested to 60°C
- Data center rated
- No thermal derating needed
Color-Coded Circuit Identification
Available in six distinct colors—black, white, red, green, blue, and yellow—enabling visual circuit designation and simplified power management in multi-PDU deployments.
- Six color options
- Visual circuit labeling
- Simplified rack organization
Deployment / Use Cases
This PDU is ideal for data centers, server rooms, and network closets where centralized, high-density power distribution is required. Its 0U form factor and 36 outlets make it suitable for powering racks full of servers, switches, storage arrays, and other IT equipment without consuming valuable U-space.
Common applications include supporting blade server chassis, high-performance computing clusters, and virtualization platforms that demand multiple power feeds. The branch circuit protection and locking receptacles are particularly valuable in environments with redundant power supplies or where equipment uptime is critical.
Data Center Power Distribution
Deploy in standard 19-inch racks to distribute 5 kW of power across 36 outlets, reducing cable clutter and improving power management for server and network infrastructure.
- 19-inch rack compatible
- Reduces cable clutter
- Centralized power management
High-Availability Server Racks
Use in racks with redundant power supplies to ensure reliable power delivery to critical servers and storage systems, with locking receptacles preventing accidental unplugging during maintenance.
- Supports redundant power
- Prevents accidental disconnects
- Critical infrastructure ready
Physical Profile
The PDU measures 70 inches in height, 2.20 inches in width, and 2.50 inches in depth (1778 x 55.88 x 63.50 mm), designed to mount vertically in 0U space at the side or rear of standard server racks. The slim profile minimizes obstruction while providing full-length outlet access. Button mounts are included for secure attachment, with options for custom bracket installations to fit specific cabinet layouts.
- Width
- 2.20" (55.88 mm)
- Depth
- 2.50" (63.50 mm)
- Height
- 0U
What's in the Box
The package includes the 36-outlet PDU and standard button mounts for immediate rack installation.
Package contents include 36-Outlets PDU Standard Button Mounts, 36-Outlets PDU. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 36 outlets: 18 IEC 60320 C13 and 18 CX for versatile device connectivity.
- 5 kW power rating with 230 V AC input and 208 V AC output.
- NEMA L6-30P plug for high-current power input.
- RamLock locking receptacles secure C14 and C20 plugs mechanically.
- Branch circuit protection with UL 489 breakers or UL 248 fuses.
- 0U rack-mountable design with button mounts for space-efficient installation.
- High-temperature rated for reliable operation up to 60°C.
- Color-coded options available for circuit identification in data centers.
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | C3B36RL-2CJE0AT4 |
| Brand Name | Server Technology |
| Product Name | 36-Outlets PDU |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Basic |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | IEC 60320 C13,CX |
| Receptacle Detail | 18 x IEC 60320 C13,18 x CX |
| Protection Type | Branch Circuit,Circuit Protection,Circuit Breaker,Fuse |
| Locking Receptacles | RamLock Locking Outlet |
| Power Description | |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Power Rating (Watt) | 5 kW |
| Input Current | 30 A |
| Input Frequency | 60 Hz |
| Physical Characteristics | |
| Mount Type | Rack-mountable,Cabinet-mountable,Button Mount |
| Rack Height | 0U |
| Height | 70" (1778 mm) |
| Width | 2.20" (55.88 mm) |
| Depth | 2.50" (63.50 mm) |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 185°F (85°C) |
| Minimum Operating Humidity | 8% |
| Maximum Operating Humidity | 90% |
| Miscellaneous | |
| Package Contents | 36-Outlets PDU Standard Button Mounts |
| Application/Usage | Data Center,Server Rack/Cabinet,IT Equipment |
| Warranty | |
| Limited Warranty | 2 Year |
FAQ
What is the power capacity of this PDU?
This PDU has a power rating of 5 kW (5000 watts), with an input voltage of 230 V AC and output voltage of 208 V AC. It supports a 30 A input current at 60 Hz, making it suitable for distributing power to multiple servers, switches, and storage devices in a rack environment.
How many outlets does this PDU have and what types are they?
The PDU features 36 outlets total: 18 are IEC 60320 C13 outlets and 18 are CX outlets. The CX outlets are hybrid connectors that accept both C14 and C20 plugs, providing flexibility for connecting a wide range of IT equipment without needing adapters.
What type of plug does this PDU use for power input?
It uses a NEMA L6-30P plug, which is a locking 30-amp connector designed for 230 V AC applications. This plug type is common in data center and industrial settings for secure, high-current power connections.
Does this PDU include any safety or protection features?
Yes, it includes branch circuit protection through UL 489 rated magnetic-hydraulic circuit breakers or UL 248 fuses, complying with UL and IEC 62368-1 standards. Additionally, it has RamLock locking receptacles that mechanically secure plugs to prevent accidental disconnections.
How is this PDU mounted in a rack?
This is a 0U rack-mountable PDU, meaning it mounts vertically in the zero U space at the side or rear of a standard 19-inch rack without consuming rack units. It includes standard button mounts for installation, with provisions for custom mounting brackets if needed.
What are the environmental operating conditions for this PDU?
The PDU operates reliably in temperatures from 32°F to 140°F (0°C to 60°C) and humidity from 8% to 90%. It is specifically tested and approved for high-temperature data center environments up to 60°C, ensuring stable performance in dense server racks.
