SimplyNUC 91C-0EG0-091 NUC13BRFA2 Bravo Canyon Mini Desktop - Intel Atom x7211E Dual-Core - 8 GB DDR5 - 256 GB NVMe SSD - Intel UHD Graphics - 2. 5GbE
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the heart of the Bravo Canyon NUC13BRFA2 is the Intel Atom x7211E, a dual-core processor capable of reaching 3.20 GHz turbo speeds. This CPU is paired with an Intel chipset and 8 GB of DDR5 SDRAM running at 4800 MHz, providing modern memory bandwidth for smooth application performance.
Storage is handled by a 256 GB PCI Express NVMe 3.0 x2 SSD in the M.2 form factor, offering fast boot times and rapid data access. Graphics are powered by Intel UHD Graphics with shared DDR5 memory, suitable for display output and basic multimedia tasks without requiring a discrete GPU.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Bravo Canyon NUC13BRFA2 combines compact form factor with robust connectivity and durability features ideal for specialized deployments. Its rugged design and comprehensive I/O options make it a versatile solution beyond traditional office desktops.
Advanced Connectivity Suite
Equipped with 2.5 Gigabit Ethernet for high-speed wired networking, plus Wi-Fi 6 and Bluetooth for wireless flexibility. Six USB ports (including USB 3.2 Gen 2) provide ample peripheral connectivity.
- 2.5GbE for faster network transfers
- Wi-Fi 6 for reliable wireless
- Multiple USB generations for compatibility
Rugged Reliability
Built to withstand demanding environments with rugged construction, making it suitable for industrial, retail, or embedded applications where standard PCs might fail.
- Enhanced durability for challenging conditions
- Suitable for non-office deployments
- Long-term reliability focus
Deployment / Use Cases
The SimplyNUC Bravo Canyon NUC13BRFA2 excels in environments where space is limited but connectivity and durability are paramount. Its compact size and rugged design make it ideal for wall-mounted or concealed installations.
Common deployment scenarios include digital signage displays in retail or hospitality settings, kiosk systems for public information or transaction terminals, light office workstations for administrative tasks, and embedded computing in industrial automation or monitoring applications. The system's 2.5GbE and Wi-Fi 6 capabilities ensure reliable network performance in both wired and wireless configurations.
Digital Signage & Kiosks
Perfect for driving displays in retail, hospitality, or public spaces with reliable performance and compact form factor.
Industrial & Embedded Computing
Rugged construction withstands vibration, temperature variations, and challenging environments where standard PCs would fail.
What's in the Box
The package includes all essential components for immediate setup and operation.
Package contents include Bravo Canyon NUC13BRFA2 Desktop Computer Power Adapter, Bravo Canyon NUC13BRFA2 Desktop Computer. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Atom x7211E dual-core processor with 3.20 GHz turbo speed
- 8 GB DDR5 memory at 4800 MHz for responsive multitasking
- 256 GB NVMe SSD with PCI Express 3.0 x2 interface for fast storage
- Intel UHD Graphics with shared DDR5 memory for display output
- 2.5 Gigabit Ethernet (i225-V) for high-speed wired networking
- Wi-Fi 6 (802.11ax) and Bluetooth for wireless connectivity
- Six USB ports including USB 3.2 Gen 2 for peripheral expansion
- Rugged design for durability in challenging environments
- 65 W power supply for energy-efficient operation
- 1-year limited warranty for peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | SimplyNUC |
| Manufacturer Part Number | 91C-0EG0-091 |
| Brand Name | SimplyNUC |
| Product Line | Bravo Canyon |
| Product Model | NUC13BRFA2 |
| Product Name | Bravo Canyon NUC13BRFA2 Desktop Computer |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Atom |
| Processor Model | x7211E |
| Processor Core | Dual-core (2 Core) |
| Maximum Turbo Speed | 3.20 GHz |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Standard Memory | 8 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Speed | 4800 MHz |
| Memory Configuration | 1 x 8GB |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 256 GB |
| Solid State Drive Interface | PCI Express NVMe 3.0 x2 |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | UHD Graphics |
| Graphics Memory Technology | DDR5 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| LAN Model | i225-V |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 2.0 Ports (Front) | 2 |
| Number of Onboard USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 2 |
| Power Description | |
| Maximum Power Supply Wattage | 65 W |
| Physical Characteristics | |
| Rugged | Yes |
| Miscellaneous | |
| Package Contents | Bravo Canyon NUC13BRFA2 Desktop Computer Power Adapter |
| Features | Security Slot |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What processor does the SimplyNUC Bravo Canyon NUC13BRFA2 use?
This desktop computer features an Intel Atom x7211E dual-core processor with a maximum turbo speed of 3.20 GHz. The Atom x7211E is designed for efficient performance in compact systems, providing adequate processing power for everyday business applications, digital signage, kiosk operations, and light office workloads without excessive power consumption.
How much memory and storage does this system include?
The Bravo Canyon NUC13BRFA2 comes with 8 GB of DDR5 SDRAM running at 4800 MHz in a single 8 GB module configuration. For storage, it includes a 256 GB PCI Express NVMe 3.0 x2 SSD in the M.2 form factor. This combination provides responsive multitasking capability and fast storage access for operating systems and applications.
What graphics capabilities does this desktop offer?
Graphics are handled by integrated Intel UHD Graphics with shared DDR5 memory. This solution supports basic visual tasks, display output for monitors, and light multimedia applications. It's suitable for business productivity, digital signage content playback, and kiosk interfaces, but not designed for intensive gaming or professional 3D rendering workloads.
What networking and connectivity options are available?
The system features comprehensive connectivity including 2.5 Gigabit Ethernet via an i225-V controller for high-speed wired networking, Wi-Fi 6 (IEEE 802.11ax) for reliable wireless connectivity, and Bluetooth for peripheral pairing. It also offers six USB ports total: two USB 2.0 ports on the front, two USB 2.0 ports onboard, and two USB 3.2 Gen 2 ports for faster data transfer.
Is this desktop computer suitable for industrial environments?
Yes, the Bravo Canyon NUC13BRFA2 features a rugged design specifically engineered to withstand challenging conditions. This makes it appropriate for industrial settings, retail environments, digital signage installations, kiosk deployments, and other applications where standard desktop computers might not endure vibration, temperature variations, or physical stresses.
What comes in the box with this SimplyNUC desktop?
The package includes the Bravo Canyon NUC13BRFA2 desktop computer itself along with a power adapter for immediate setup and operation. No additional components or peripherals such as monitors, keyboards, or mice are included, so these will need to be sourced separately based on your specific deployment requirements.
