SMART Board T075-P T Pro Series 75" QLED 4K UHD Interactive Display with HyPr Touch - 50-Point Multi-Touch - 40W Audio & VESA Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The T075-P features a 75-inch QLED panel with 4K UHD resolution (3840 × 2160), delivering sharp imagery with 850 cd/m² brightness and wide 178° viewing angles. The display's 8 ms response time ensures smooth motion handling, while the tempered glass surface provides durability and scratch resistance for high-traffic environments.
HyPr Touch technology enables precise 50-point multi-touch interaction, supporting simultaneous input from multiple users. The integrated audio system includes two speakers with 40W RMS output and an 8-element microphone array for clear voice pickup, complemented by connectivity options such as HDMI, two USB ports, Ethernet (RJ-45), serial, and S/PDIF out. Power input supports 120V AC and 230V AC, with Energy Star and Ecodesign compliance for energy efficiency.
Key Product Advantages
The T075-P combines display, touch, and audio functionalities into a single unit, reducing clutter and simplifying setup in meeting rooms. The ambient light sensor automatically adjusts brightness based on room conditions, while VESA mount compatibility (800 × 400) supports wall or stand mounting for space-efficient installations.
Enhanced Collaboration
The 50-point multi-touch capability with HyPr Touch technology allows multiple participants to interact simultaneously, while SMART Meeting Pro software provides tools for real-time annotation, file sharing, and remote collaboration.
- 50-point simultaneous touch input
- SMART Meeting Pro included
- SMART Ink for digital annotation
Integrated Audio-Visual
Built-in 40W audio with two speakers and an 8-microphone array eliminates the need for external audio equipment, delivering clear sound capture and playback for video conferences and presentations.
- 40W RMS audio output
- 8-element microphone array
- S/PDIF out for external audio
Deployment / Use Cases
This display is designed for environments requiring robust collaboration tools, such as corporate boardrooms, university lecture halls, and training facilities. The combination of high-resolution visuals, multi-touch interaction, and built-in audio makes it effective for hybrid meetings, where local and remote participants can interact seamlessly.
Installation flexibility via VESA mounting allows for permanent wall mounting or mobile cart setups, adapting to room layouts and usage patterns. The included remote control and pens further enhance usability for presenters and facilitators.
Conference Rooms
Ideal for mid to large conference rooms, the 75-inch screen provides ample visibility for presentations, video calls, and collaborative whiteboarding, with integrated microphones and speakers ensuring clear audio during meetings.
Education & Training
Suitable for classrooms and training centers, the interactive touchscreen facilitates engaging lessons, group activities, and remote learning sessions, supported by SMART software tools for educational content.
Physical Profile
The T075-P measures 67.28 inches in width, 40.71 inches in height, and 3.54 inches in depth, with a weight of approximately 103.62 pounds (47 kg). Its slim profile and tempered glass construction provide a modern aesthetic, while VESA 800 × 400 mount compatibility enables secure installation on walls or compatible stands. The display's weight and dimensions should be considered for mounting hardware and structural support requirements.
- Width
- 67.28" (1709 mm)
- Depth
- 3.54" (90 mm)
- Height
- 40.71" (1034 mm)
- Weight
- 103.62 lb (47000 g)
What's in the Box
The package includes the T Pro series interactive display unit, power cable, USB cables (16' 5" USB 2.0 A to B and 6' USB 3.2 Gen 1 Type-C), two pens, remote control with AAA batteries, illustrated installation instructions, and important information documents. Software bundles include SMART Meeting Pro, SMART Product Drivers, and SMART Ink.
Highlights
- 75-inch QLED 4K UHD display with 3840 × 2160 resolution
- HyPr Touch technology with 50-point multi-touch capability
- Integrated 40W audio system with two speakers
- 8-element microphone array for clear voice capture
- VESA 800 × 400 mount compatible for flexible installation
- Includes SMART Meeting Pro, SMART Product Drivers, and SMART Ink software
- Tempered glass surface with ambient light sensor
- Connectivity: HDMI, USB (2 ports), Ethernet, serial, S/PDIF out
- Energy Star and Ecodesign compliant for energy efficiency
- Supports 120V AC and 230V AC input voltage
Specifications
| Specifications | |
|---|---|
| Manufacturer | SMART Technologies, Inc |
| Manufacturer Part Number | T075-P |
| Brand Name | SMART Board |
| Product Series | T Pro |
| Product Model | T075 Pro |
| Product Name | T Pro series interactive displays - 75" |
| Product Type | Collaboration Display |
| Display & Graphics | |
| Viewable Screen Size | 75" (1905 mm) |
| Screen Size Class | 75" (1905 mm) |
| Display Screen Type | QLED |
| Screen Mode | 4K UHD |
| Screen Resolution | 3840 x 2160 |
| Scan Format | 2160p |
| Aspect Ratio | 16:9 |
| Response Time | 8 ms |
| Brightness | 850 cd/m² |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Tempered Glass | Yes |
| Ambient Light Sensor | Yes |
| Touchscreen Information | |
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Number of Touch Points | 50 |
| Touchscreen Technology | HyPr Touch Technology |
| Audio | |
| Speakers | Yes |
| Number of Speakers | 2 |
| Microphone | Yes |
| Number of Microphone Array Elements | 8 |
| RMS Output Power | 40 W |
| Network & Communication | |
| Ethernet | Yes |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 2 |
| USB | Yes |
| Network (RJ-45) | Yes |
| Serial | Yes |
| S/PDIF Out | Yes |
| Software | |
| Software Included | SMART Meeting Pro SMART Product Drivers SMART Ink |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Physical Characteristics | |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 800 x 400 |
| Height | 40.71" (1034 mm) |
| Width | 67.28" (1709 mm) |
| Depth | 3.54" (90 mm) |
| Weight (Approximate) | 103.62 lb (47000 g) |
| Miscellaneous | |
| Package Contents | T Pro series interactive displays - 75" 1 x power cable 1 x 16' 5" (5 m) USB 2.0 A to B cable 1 x 6' (1.8 m) USB 3.2 Gen 1 Type-C cable, 5A 2 x Pens 1 x Remote control 2 x AAA batteries 1 x Illustrated installation instructions 1 x Important information document |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Energy Efficiency Compliance | Ecodesign |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
User Manual
FAQ
What is the screen size and resolution of the SMART Board T075-P?
The SMART Board T075-P features a 75-inch (1905 mm) QLED display with 4K UHD resolution of 3840 × 2160 pixels. This high-resolution screen provides sharp, detailed visuals suitable for presentations, video conferencing, and collaborative work, with a brightness of 850 cd/m² and wide 178° viewing angles for clear visibility from various positions in a room.
How many touch points does this interactive display support?
This display supports 50-point multi-touch using HyPr Touch technology, allowing up to 50 simultaneous touch inputs. This capability enables multiple users to interact with the screen at once, making it ideal for collaborative activities like group brainstorming, interactive lessons, or team presentations without lag or interference.
Does the T075-P have built-in audio and microphone capabilities?
Yes, the T075-P includes an integrated audio system with two speakers delivering 40W RMS output power and an 8-element microphone array. This built-in setup provides clear sound playback and voice capture for video calls and presentations, reducing the need for external audio equipment in meeting rooms.
What mounting options are available for this display?
The display is VESA mount compatible with an 800 × 400 standard, allowing for secure wall mounting or attachment to compatible stands. This flexibility supports various installation setups, such as fixed wall mounts in conference rooms or mobile carts for shared spaces, ensuring the display fits different room layouts and usage requirements.
What software is included with the SMART Board T075-P?
The display comes with SMART Meeting Pro, SMART Product Drivers, and SMART Ink software. These tools enhance collaboration by providing features for real-time annotation, file sharing, remote participation, and seamless integration with other devices, supporting effective meeting and presentation workflows in business and educational settings.
What connectivity ports does the T075-P offer?
The T075-P includes HDMI, two USB ports (total), Ethernet (RJ-45), serial, and S/PDIF out ports. These connections support integration with computers, peripherals, networks, and external audio systems, facilitating versatile setup options for video conferencing, content sharing, and extended display configurations in collaborative environments.
