Socket Mobile DuraScan Wireless Barcode Scanner 36 Inch Scan Distance LED Omni-directional Connectivity Mm CX3800-2560
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Bookland EAN
- Chinese 2 of 5
- Codabar
- Code 11
- Code 39
- Code 93
- Code 128
- Composite CC-A/B
- Composite CC-C
- Composite TLC
- Discrete 2 of 5
- EAN-13/JAN
- EAN-8/JAN
- GS1 Databar
- GS1 Databar Expanded
- GS1 Databar Limited
- GS1-128
- Interleaved 2 of 5
- ISBT 128
- ISSN EAN
- Matrix 2 of 5
- MSI
- UPC/EAN/JAN
- UPC A,
- UPC EO
- Aztec
- Data Matrix
- Maxicode
- Micro PDF417
- MicroQR
- PDF417
- QR Code
Connectivity Technology: Wireless
Scanning Capability: 1D,2D
Barcode Symbology Supported: 1D:
2D:
Light Source: LED
Scan Pattern: Omni-directional
Scanning Distance: 36" (914.40 mm)
Field of View (Horizontal): 48°
Field of View (Vertical): 30°
Maximum Ambient Light: 100000 lux
Drop Specification:
6 drops to concrete - 1 on each side at 6.6 ft. (2 m)
Minimum Print Contrast: 25%
Minimum Element Resolution (Code 39): 3 mil (0.08 mm)
Maximum Element Resolution (Code 39): 20 mil (0.51 mm)
Minimum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Minimum Element Resolution (PDF417): 5 mil (0.13 mm)
Maximum Element Resolution (PDF417): 6.67 mil (0.17 mm)
Bluetooth: Yes
Form Factor: Handheld
Rugged: Yes
Product Color: White
Ingress Protection (IP) Rating: IP54
Application/Usage: Healthcare,Hospitality,Pharmacy,Retail,Warehouse,Field Sales/Service,Transportation,Inventory
Platform Supported: iOS
Country of Origin: United States
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Limited Warranty: 1 Year
- Laser-free design provides high-performance scanning without the risk of eye injury
- Wireless connectivity gives you the adaptability to transmit barcode data to your smart devices
- With Bluetooth technology, you can scan barcodes and then transmit data from the base
[custom-specifications]
| Specifications | |
| Manufacturer | Socket Mobile, Inc |
| Manufacturer Part Number | CX3800-2560 |
| Manufacturer Website Address | http://www.socketmobile.com |
| Brand Name | Socket Mobile |
| Product Line | DuraScan |
| Product Model | D755 |
| Product Name | DuraScan D755 Barcode Scanner |
| Packaged Quantity | 50 Pack |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D:
|
| Light Source | LED |
| Scan Pattern | Omni-directional |
| Scanning Distance | 36" (914.40 mm) |
| Field of View (Horizontal) | 48° |
| Field of View (Vertical) | 30° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | 6 drops to concrete - 1 on each side at 6.6 ft. (2 m) |
| Minimum Print Contrast | 25% |
| Minimum Element Resolution (Code 39) | 3 mil (0.08 mm) |
| Maximum Element Resolution (Code 39) | 20 mil (0.51 mm) |
| Minimum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Minimum Element Resolution (PDF417) | 5 mil (0.13 mm) |
| Maximum Element Resolution (PDF417) | 6.67 mil (0.17 mm) |
| Network & Communication | |
| Bluetooth | Yes |
| Physical Characteristics | |
| Form Factor | Handheld |
| Rugged | Yes |
| Product Color | White |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP54 |
| Application/Usage | Healthcare,Hospitality,Pharmacy,Retail,Warehouse,Field Sales/Service,Transportation,Inventory |
| Platform Supported | iOS |
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 1 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
[/custom-user-manual]
