Socket Mobile CX4511-3722 DuraSled DS860 Wireless Barcode Scanner - 30" Scan Distance - Bluetooth - IP40 - LED Imager
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The DuraSled DS860 operates on Bluetooth wireless technology, eliminating cable constraints and enabling flexible movement during scanning tasks. Its 700 mAh lithium polymer battery provides up to 25 hours of continuous operation on a single charge, with a maximum recharge time of 8 hours.
The scanner maintains reliable performance in challenging environmental conditions, operating within a temperature range of 32°F to 122°F (0°C to 50°C) and tolerating humidity levels from 5% to 95% non-condensing. Its IP40 rating provides basic protection against solid objects larger than 1.0 mm.
This section brings together practical product details such as Connectivity Technology, Light Source, Image Sensor Type, Bluetooth, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The DuraSled DS860 delivers tangible productivity benefits through its combination of wireless freedom, extended battery life, and rugged construction. Its design prioritizes both user convenience and operational reliability in mobile scanning scenarios.
Wireless Mobility
Bluetooth connectivity enables cable-free operation, allowing users to move freely while scanning without being tethered to a base station or device.
- Eliminates cable management issues
- Reduces tripping hazards in busy environments
- Enables scanning from comfortable positions
Extended Operational Time
With 25 hours of battery life, the scanner supports full-shift or multi-day use without frequent recharging, minimizing downtime in continuous operations.
- Supports extended work shifts
- Reduces charging interruptions
- Maintains productivity through long deployments
Rugged Construction
Built to withstand multiple drops onto vinyl-covered concrete from 3 feet, the DS860 maintains functionality in demanding physical environments.
- Survives accidental drops
- Withstands rough handling
- Maintains reliability in mobile use cases
Deployment / Use Cases
The DuraSled DS860 is engineered for professional environments where mobile barcode scanning enhances operational efficiency. Its combination of wireless connectivity, durable construction, and platform compatibility makes it suitable for diverse industry applications.
In healthcare settings, the LED aimer provides a patient-friendly scanning solution for medication administration, specimen tracking, and patient identification. The wireless design allows healthcare professionals to scan without disturbing patients or interrupting workflow.
Retail & Inventory Management
Retail staff can conduct inventory counts, price checks, and receiving operations without being constrained by cables, improving efficiency during stock management tasks.
- Mobile stock counting
- Price verification on sales floor
- Receiving and put-away operations
Field Service & Logistics
Field technicians and logistics personnel benefit from the scanner's durability and wireless operation when tracking assets, verifying deliveries, or conducting maintenance checks in various locations.
- Delivery verification
- Asset tracking in warehouses
- Maintenance record updates
Highlights
- Wireless Bluetooth connectivity for cable-free operation
- 30-inch (762 mm) scanning distance for flexible positioning
- 25-hour battery life supports extended shifts
- IP40 rating provides basic dust and moisture protection
- Survives multiple drops from 3 feet onto hard surfaces
- Wide 42° horizontal field of view captures barcodes efficiently
- Compatible with iOS, Mac, and smartphone platforms
- LED light source suitable for patient-facing applications
- Operates in temperatures from 32°F to 122°F (0°C to 50°C)
- Supports logistics, healthcare, retail, hospitality, and field service applications
Specifications
| Specifications | |
|---|---|
| Manufacturer | Socket Mobile, Inc |
| Manufacturer Part Number | CX4511-3722 |
| Brand Name | Socket Mobile |
| Product Line | DuraSled |
| Product Model | DS860 |
| Product Name | DuraSled DS860 Barcode Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Wireless |
| Light Source | LED |
| Image Sensor Type | Imager |
| Scanning Distance | 30" (762 mm) |
| Field of View (Horizontal) | 42° |
| Field of View (Vertical) | 28° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | Multiple drops to vinyl covered concrete at 3 feet or 1 meter |
| Minimum Print Contrast | 25% |
| Minimum Element Resolution (Code 39) | 4 mil (0.10 mm) |
| Maximum Element Resolution (Code 39) | 20 mil (0.51 mm) |
| Minimum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Image Sensor Resolution | 1280 x 800 |
| Features | Notification LED,Scan Button |
| Network & Communication | |
| Bluetooth | Yes |
| Battery Information | |
| Battery Chemistry | Lithium Polymer (Li-Polymer) |
| Battery Capacity | 700 mAh |
| Maximum Battery Run Time | 25 Hour |
| Maximum Battery Recharge Time | 8 Hour |
| Environmental Conditions | |
| Operating Temperature | 32°F (0°C) to 122°F (50°C) |
| Storage Temperature | -22°F (-30°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 5% to 95% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP40 |
| Application/Usage | Logistics,Healthcare,Hospitality,Field Sales/Service,Retail |
| Platform Supported | iOS,Mac,Smartphone |
User Manual
FAQ
What is the maximum scanning distance of the DuraSled DS860?
The DuraSled DS860 has a maximum scanning distance of 30 inches (762 mm). This range allows users to scan barcodes from a comfortable distance without needing to position the scanner directly against the barcode surface, providing flexibility in various operational scenarios.
How long does the battery last on a single charge?
The scanner's 700 mAh lithium polymer battery provides up to 25 hours of continuous operation on a single charge. This extended battery life supports full work shifts or multiple days of typical use without requiring frequent recharging, minimizing operational interruptions.
What devices and platforms is this scanner compatible with?
The DuraSled DS860 is compatible with iOS devices, Mac computers, and various smartphone platforms. This broad compatibility enables integration with mobile devices commonly used in field service, retail, healthcare, and logistics environments without requiring specialized hardware.
How durable is this barcode scanner for daily professional use?
The DS860 is designed to withstand multiple drops from 3 feet (1 meter) onto vinyl-covered concrete surfaces. This durability testing ensures the scanner maintains functionality despite accidental drops or rough handling in active work environments like warehouses, retail floors, or healthcare facilities.
What environmental conditions can this scanner operate in?
The scanner operates effectively in temperatures ranging from 32°F to 122°F (0°C to 50°C) and tolerates humidity levels from 5% to 95% non-condensing. These specifications make it suitable for both climate-controlled indoor environments and variable conditions in warehouses, loading docks, or field service applications.
What types of barcodes can the DS860 read effectively?
The scanner reads Code 39 barcodes with element resolutions from 4 mil (0.10 mm) to 20 mil (0.51 mm) and DataMatrix codes down to 10 mil (0.25 mm) resolution. It handles barcodes with minimum print contrast of 25% and performs reliably under ambient light up to 100,000 lux.
What duplex or duty-cycle detail is listed?
the specifications are intended to help buyers confirm fit, compatibility, and expected day-to-day operation. In practical terms, the best reading of this product comes from how its hardware, connectivity, and deployment details work together.
What connectivity options are listed?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
