SonicWall 02-SSC-8368 SWS12-8POE 8-Port Gigabit PoE Managed Switch - 2 SFP Uplinks - 55W PoE Budget - Layer 2 - Desktop
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The SWS12-8POE operates at Layer 2, supporting 1000Base-T on twisted-pair ports and 1000Base-X on SFP slots. The switch delivers up to 128 MB/s throughput, ensuring high-speed data transfer for bandwidth-intensive applications. It complies with IEEE 802.1x for network access control, IEEE 802.1p for QoS, and IEEE 802.3af for PoE, providing standards-based interoperability.
The built-in fan ensures adequate cooling even under full PoE load. The switch supports a maximum power draw of 63.20 W, with input voltage at 54 V DC via the included power adapter. Its compact dimensions (9.45" x 4.13" x 1.06") and lightweight design (1.41 lb) make it easy to integrate into space-constrained environments.
This section brings together practical product details such as Features, Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The SonicWall SWS12-8POE combines essential Layer 2 switching with PoE capability and fiber uplinks in a compact desktop form factor. Its 55 W PoE budget supports up to 8 powered devices, reducing cabling complexity and enabling flexible device placement. The two SFP slots provide scalable fiber uplinks for long-distance connections or integration with existing optical infrastructure.
Simplified Deployment
- Zero-Touch Provisioning (ZTP) for plug-and-play setup
- Compact desktop design fits anywhere
Advanced Traffic Management
- VLANs for network segmentation
- IGMP snooping for multicast optimization
- QoS for prioritizing critical traffic
Security & Reliability
- ACLs and DHCP snooping
- IEEE 802.1x network access control
- Redundant SFP uplinks
Deployment / Use Cases
The SWS12-8POE is ideal for edge deployments, such as retail stores, classrooms, and branch offices where space is limited. Its PoE ports simplify power delivery to security cameras, wireless access points, and VoIP handsets, while the SFP uplinks ensure reliable connectivity back to the core network.
In conjunction with SonicWall wireless network management, the switch supports unified wired and wireless deployment scenarios. Use cases include setting up a small business network with centralized management, extending network reach via fiber to remote buildings, or powering a surveillance system with 55 W PoE budget.
Retail & Branch Offices
Power IP cameras and Wi-Fi APs with PoE, while using SFP uplinks for a secure fiber backbone.
Remote Site Connectivity
Leverage two SFP slots to connect remote locations with high-bandwidth fiber links.
Physical Profile
The SonicWall SWS12-8POE features a compact desktop form factor (1.06" H x 9.45" W x 4.13" D) weighing only 1.41 lb. Its small footprint allows flexible placement on desks, shelves, or wall mounts (bracket not included). The front panel provides easy access to port LEDs and SFP slots, while the rear houses the DC power input and a built-in fan for thermal management.
- Width
- 9.45" (240 mm)
- Depth
- 4.13" (105 mm)
- Height
- 1.06" (27 mm)
- Weight
- 1.41 lb (640 g)
Highlights
- 8 Gigabit Ethernet PoE ports with 55 W total PoE budget
- 2 SFP slots for fiber uplinks or expansion
- Layer 2 managed switch with VLAN, QoS, IGMP snooping
- Zero-Touch Provisioning for simplified deployment
- Desktop form factor ideal for space-constrained environments
- Built-in fan for reliable cooling under load
- IEEE 802.1x, 802.1p, and 802.3af compliant
- Power consumption: 63.20 W
Specifications
| Specifications | |
|---|---|
| Manufacturer | SonicWall Inc. |
| Manufacturer Part Number | 02-SSC-8368 |
| Brand Name | SonicWall |
| Product Model | SWS12-8POE |
| Product Name | SWS12-8POE Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Built-in Fan,Zero-Touch Provisioning (ZTP),Quality of Service (QoS),Energy Efficient,Virtual LAN (VLAN),IGMP Snooping,DHCP Snooping,Access Control List,Flow Control |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE,2 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T,1000Base-X |
| Maximum Data Transfer Rate | 128 MB/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1x,IEEE 802.1p,IEEE 802.3af |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 55 W |
| Input Voltage | 54 V DC |
| Power Source | Power Adapter |
| Power Consumption | 63.20 W |
| Physical Characteristics | |
| Form Factor | Desktop,Compact |
| Height | 1.06" (27 mm) |
| Width | 9.45" (240 mm) |
| Depth | 4.13" (105 mm) |
| Weight (Approximate) | 1.41 lb (640 g) |
| Miscellaneous | |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
How many PoE ports does the SonicWall SWS12-8POE have?
The switch has 8 Gigabit Ethernet PoE ports. All 8 ports support Power over Ethernet (IEEE 802.3af), with a total PoE budget of 55 W, allowing you to power devices such as IP cameras, wireless access points, and VoIP phones directly from the switch.
What are the SFP slots used for on this switch?
The two SFP slots provide uplink connectivity using fiber optic modules (sold separately). They support 1000Base-X standards, enabling high-speed connections to a core network, linking remote buildings, or aggregating traffic from other switches over longer distances than copper cabling.
Is the SonicWall SWS12-8POE manageable?
Yes, the switch is fully manageable. It supports advanced features such as VLANs, Quality of Service (QoS), IGMP snooping, DHCP snooping, Access Control Lists (ACLs), and Flow Control. Zero-Touch Provisioning (ZTP) simplifies initial configuration.
What is the power consumption and input voltage?
The switch has a maximum power consumption of 63.20 W and requires a 54 V DC input via the included power adapter. The PoE budget of 55 W is included within this total, leaving 8.20 W for switch operation.
Can the switch be mounted on a wall?
The SonicWall SWS12-8POE is designed as a desktop or compact device. It does not include rack-mount brackets, but its small size (9.45" x 4.13" x 1.06") and light weight (1.41 lb) make it suitable for placement on a shelf, desk, or wall with appropriate mounting hardware (not included).
What networking standards does this switch support?
The switch complies with IEEE 802.1x for port-based authentication, IEEE 802.1p for traffic prioritization (QoS), and IEEE 802.3af for Power over Ethernet. It also supports 1000Base-T (copper) and 1000Base-X (fiber) on respective ports.
What uplink, SFP, fiber, or media support detail is listed?
The warranty or support detail listed is Optical Fiber,Twisted Pair, giving buyers a clearer picture of expected coverage after purchase.
Does the product support PoE or wireless networking?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
