StarTech. com S45PATCH100B 100 ft Blue Shielded Cat5e Snagless Patch Cable - RJ45 Male to RJ45 Male
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Cat5e patch cable delivers consistent performance for Fast Ethernet applications with its precise engineering and quality materials. The cable utilizes 24 AWG stranded copper conductors within a CMG-rated PVC jacket, providing both electrical reliability and physical protection. Gold-plated contacts on the RJ45 connectors ensure minimal signal loss and resistance over thousands of insertion cycles.
The cable's shielding system combines both foil and braid elements to protect against electromagnetic interference and radio frequency interference. This design maintains signal integrity in environments with multiple electronic devices or industrial equipment. The snagless boots feature a release tab that prevents accidental disconnection while allowing easy removal when needed.
Key Product Advantages
This shielded Cat5e patch cable offers several advantages for network installations where reliability and durability are paramount. The combination of shielding, quality materials, and thoughtful design elements creates a cable that performs consistently in demanding environments.
Enhanced Signal Integrity
The shielded design protects against electromagnetic and radio frequency interference, maintaining clean signal transmission even in electrically noisy environments. Gold-plated contacts further ensure minimal signal degradation over the cable's lifetime.
- EMI/RF protection
- Crosstalk reduction
- Gold contact plating
Durable Physical Construction
Molded strain relief at both connector ends prevents wire fatigue and breakage, while the stranded conductors provide flexibility without compromising conductivity. The CMG-rated PVC jacket offers protection against physical damage and environmental factors.
- Molded strain relief
- Stranded conductors
- CMG-rated jacket
Practical Installation Features
Snagless boots prevent accidental disconnection in crowded patch panels, and the blue color allows for easy visual identification and organization in network cabinets. The cable's flexibility makes routing through conduits and around obstacles straightforward.
- Snagless boot design
- Color-coded identification
- Flexible routing
Deployment / Use Cases
This 100-foot shielded Cat5e patch cable is ideal for various networking scenarios where longer cable runs are required between network devices. Its combination of length, shielding, and durability makes it suitable for both permanent installations and temporary setups.
In office environments, the cable can connect workstations to network switches located in distant wiring closets or connect network equipment across large rooms. The shielding makes it particularly useful in areas with multiple electronic devices that could cause interference. For data centers, the cable provides reliable connections between servers and switches in racks that may be separated by considerable distance.
The cable also works well for connecting networking equipment in educational institutions, retail spaces, and industrial settings where longer cable runs are necessary. Its environmental compliance with RoHS, REACH, and WEEE directives makes it appropriate for organizations with sustainability requirements.
Physical Profile
The cable features a blue PVC jacket that provides both visual identification and physical protection. With a total length of 100 feet (30.48 meters) and weighing approximately 2.40 ounces (68.04 grams), this cable offers substantial reach without excessive bulk. The CMG-rated jacket is suitable for use in plenum spaces where fire safety regulations apply, though specific local codes should always be verified before installation.
- Weight
- 2.40 oz (68.04 g)
- Length
- 100 ft (30.48 m)
Highlights
- 100-foot length provides extended reach for network connections
- Shielded Cat5e construction for EMI/RF protection and crosstalk reduction
- RJ45 male to RJ45 male connectors with gold-plated contacts
- Snagless boots prevent accidental disconnection in crowded panels
- Blue color allows for easy visual identification and organization
- 24 AWG stranded conductors for flexibility and durability
- CMG-rated PVC jacket for plenum-rated installations
- Meets or exceeds Category 5e specifications for Fast Ethernet
- Environmental compliance with RoHS, REACH, and WEEE directives
- Lifetime limited warranty for long-term reliability assurance
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | S45PATCH100B |
| Brand Name | StarTech.com |
| Product Name | 100 ft Blue Snagless Shielded Cat5e Patch Cable |
| Packaged Quantity | 1 Each |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Category 5e |
| Cable Characteristic | Patch Cable |
| Cable Length | 100 ft (30.48 m) |
| Connector Type on First End | RJ-45 Network - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Connector Plating | Gold |
| Contact Plating | Gold |
| Shielding | Yes |
| Jacket Type | CMG |
| Device Supported | Network Device,Network Adapter,Hub,Switch,Router,Modem,ATM |
| American Wire Gauge | 24 AWG |
| Boot Type | Snagless |
| Features | Molded,Strain Relief,Flexible,Stranded,EMI/RF Protection,Crosstalk Protection,Damage Resistant,Near End Cross Talk (NEXT) |
| Physical Characteristics | |
| Jacket Color | Blue |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Weight (Approximate) | 2.40 oz (68.04 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum data transfer speed supported by this Cat5e cable?
This shielded Cat5e patch cable supports data transfer speeds up to 1000 Mbps (1 Gigabit per second) at 100 MHz bandwidth. It is designed for Fast Ethernet and Gigabit Ethernet applications, providing reliable performance for most office and data center networking needs. The cable meets or exceeds Category 5e specifications, ensuring compatibility with standard networking equipment.
What does the shielding on this cable provide?
The shielding on this Cat5e cable provides protection against electromagnetic interference (EMI) and radio frequency interference (RFI). This helps maintain signal integrity in environments with multiple electronic devices, industrial equipment, or other potential sources of electrical noise. The shielding also reduces crosstalk between adjacent cables, ensuring cleaner data transmission over longer distances.
What are the benefits of the snagless boot design?
The snagless boot design prevents accidental disconnection when cables are installed in crowded patch panels or network cabinets. The boots feature a release tab that must be depressed to unplug the cable, reducing the risk of network downtime from unintentional disconnections. This design maintains a clean, professional appearance while providing practical protection in high-density installations.
What types of devices can I connect with this patch cable?
This RJ45 patch cable can connect various network devices including computers, network adapters, hubs, switches, routers, modems, and ATM equipment. It is compatible with any device featuring standard RJ45 Ethernet ports. The male-to-male configuration makes it ideal for connecting endpoint devices to network infrastructure or linking networking equipment together.
Is this cable suitable for plenum space installations?
Yes, this cable features a CMG-rated PVC jacket, which indicates it is suitable for use in plenum spaces where fire safety regulations apply. The CMG rating means the cable meets specific flame-retardant and low-smoke requirements for installation in air handling spaces. However, always verify compliance with local building codes and regulations before installation in plenum areas.
What warranty coverage does this cable include?
This StarTech.com shielded Cat5e patch cable includes a lifetime limited warranty. This warranty covers defects in materials and workmanship for the life of the product when used under normal conditions. The warranty provides assurance of long-term reliability and performance, supporting the cable's use in both temporary and permanent network installations.
