StarTech. com SPSMLCSC-OS2-15M LC to SC UPC OS2 Single Mode Simplex Fiber Optic Patch Cable - 15m - 49. 2ft - 100Gbps - LSZH Yellow
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This fiber optic patch cable combines advanced optical engineering with practical installation features. The OS2 single-mode fiber provides superior bandwidth and distance capabilities compared to multimode alternatives, with attenuation under 0.35dB/km exceeding industry standards. The bend-insensitive fiber core maintains signal integrity even with tight 10mm bend radii, facilitating routing through congested pathways and enclosures.
The LC and SC UPC connectors feature precise polishing that achieves return loss ≥55dB and insertion loss ≤0.3dB, reducing signal degradation in high-speed applications. The 2mm outer diameter LSZH jacket offers flame-retardant properties while minimizing toxic fume emission if combusted, making this cable appropriate for poorly ventilated spaces and enclosed installations.
Key Product Advantages
This cable provides distinct advantages for network professionals seeking reliable fiber connectivity. The simplex design reduces fiber count requirements while supporting bi-directional transmission through single-fiber NICs and SFPs, optimizing infrastructure density. Backward compatibility with OS1 equipment ensures seamless integration into existing network environments without requiring complete infrastructure overhaul.
Enhanced Signal Integrity
UPC polished connectors and bend-insensitive fiber maintain signal quality even in challenging installation scenarios with tight bends and complex routing paths.
- Ultra Physical Contact polish
- Bend insensitive fiber core
- Aramid-reinforced jacket
Safety Compliance
LSZH jacket material meets environmental and safety standards, including WEEE compliance, for deployment in sensitive environments where fire safety is critical.
- Low smoke zero halogen
- Flame retardant
- Environmentally friendly
Deployment / Use Cases
This LC to SC fiber patch cable serves multiple roles in contemporary network architecture. It functions effectively as an interconnect between network devices with different connector types, such as linking LC-equipped switches to SC-terminated storage arrays or servers. The 15-meter length provides flexibility for rack-to-rack connections within data centers or between equipment in server rooms.
The cable's simplex design makes it particularly valuable for space-constrained installations where minimizing fiber count is essential. It supports point-to-point connections in telecommunications infrastructure, campus networks, and enterprise backbones. Compatibility with 40G/100G networks ensures readiness for high-bandwidth applications including data center interconnects, storage area networks, and high-performance computing clusters.
Highlights
- 15-meter LC to SC UPC OS2 single-mode simplex fiber optic patch cable
- Supports 40G/100G networks with 100 Gbit/s data transfer rate
- Bend-insensitive fiber with 10mm loaded/unloaded bend radius
- LSZH jacket for low smoke and zero halogen emissions
- UPC polished connectors for ≤0.3dB insertion loss and ≥55dB return loss
- 9/125µm core optimized for 1260-1625nm wavelengths
- Backward compatible with OS1 equipment and standards
- Individually tested with included performance report
- Yellow color for easy identification in patch panels
- Lifetime limited warranty from StarTech.com
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SPSMLCSC-OS2-15M |
| Brand Name | StarTech.com |
| Product Name | Fiber Optic Simplex Patch Network Cable |
| Packaged Quantity | 1 |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Fiber Optic |
| Cable Characteristic | Patch Cable |
| Fiber Optic Mode | Single-mode |
| Fiber Type | Simplex |
| Fiber Category | OS2 |
| Cable Length | 49.2 ft (15 m) |
| Connector Type on First End | LC Network - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x LC Network - Male |
| Connector Type on Second End | SC Network - Male |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1 x SC Network - Male |
| Jacket Type | LSZH |
| Device Supported | Network Device,Server,Switch,Storage Device |
| Data Transfer Rate | 100 Gbit/s |
| Features | Ultra Physical Contact (UPC),Bend Insensitive,Flame Retardant,Bend Resistant,Passive |
| Physical Characteristics | |
| Color Family | Yellow |
| Product Color | Yellow |
| Product Material | Polypropylene |
| Jacket Material | Low Smoke Zero Halogen |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the difference between simplex and duplex fiber cables?
Simplex fiber cables contain a single fiber strand and are typically used for bidirectional communication over a single fiber using different wavelengths. Duplex cables contain two fibers, one for transmit and one for receive. This StarTech.com cable is simplex, making it ideal for space-constrained installations and applications using single-fiber BiDi transceivers.
What does OS2 fiber category mean for my network?
OS2 is a single-mode fiber specification designed for long-distance, high-bandwidth applications. It supports higher data rates over longer distances compared to multimode fiber, with lower attenuation characteristics. This cable's OS2 rating ensures compatibility with 40G/100G networks and provides headroom for future network upgrades while maintaining backward compatibility with OS1 equipment.
Why choose LSZH jacket material for fiber optic cables?
LSZH (Low Smoke Zero Halogen) jacket material minimizes toxic fume emission and smoke production if the cable combusts. This enhances safety in enclosed spaces, poorly ventilated areas, and environments with high equipment density like data centers. The LSZH construction also meets environmental compliance standards including WEEE directives.
What applications benefit from LC to SC connector combinations?
LC to SC connections are commonly used to interface equipment with different connector types, such as connecting LC-equipped switches or routers to SC-terminated storage devices, media converters, or legacy equipment. This cable facilitates seamless integration in mixed-connector environments without requiring additional adapters or conversion devices.
How does bend-insensitive fiber improve installation flexibility?
Bend-insensitive fiber maintains signal integrity even when bent tightly around corners or through congested pathways. This cable features a 10mm loaded/unloaded bend radius, allowing installation in space-constrained enclosures, tight cable trays, and complex routing scenarios without significant signal degradation that would occur with standard fiber.
What is included with the cable purchase?
Each StarTech.com SPSMLCSC-OS2-15M cable includes the 15-meter fiber optic patch cable with LC and SC UPC connectors. The cable is individually tested, and a performance test report is included to verify insertion loss, return loss, and other critical parameters meet specifications. The cable carries a lifetime limited warranty from StarTech.com.
