Product Features
Technical Overview
This active adapter cable converts a DisplayPort 1.4 signal to HDMI 2.0b, enabling high-performance video and audio transmission. The cable supports High Bit Rate 3 (HBR3) for data rates up to 18 Gbps, sufficient for 4K 60Hz with HDR. It includes EMI protection for reliable performance in electrically noisy environments.
The cable is shielded to minimize interference, and the connectors are gold-plated for corrosion resistance and optimal signal integrity. The gripping HDMI connector features a textured surface for a secure hold, while the latching DisplayPort connector clicks into place to prevent accidental unplugging. The cable is built with a durable PVC jacket for long-lasting flexibility.
Key Product Advantages
The StarTech 3M-DP-HDMI-4K60-GR adapter cable combines high-performance signal conversion with robust physical design. Its active circuitry ensures reliable conversion from DisplayPort to HDMI without requiring drivers or software, making it compatible with any operating system and GPU (Intel, AMD, Nvidia).
The cable's dual retention features—gripping HDMI and latching DP—are especially valuable in commercial or industrial settings where connections must stay secure. Additionally, the integrated cable reduces clutter and failure points compared to adapter dongle + cable combinations.
Deployment / Use Cases
This adapter cable is ideal for connecting DisplayPort-equipped PCs, laptops, or external GPUs to HDMI monitors, projectors, or TVs. It is particularly useful in conference rooms, digital signage, security systems, and education environments where secure, reliable connections are required.
For IT deployments, the cable supports large-scale rollouts with consistent performance across diverse hardware. It is also suitable for connecting a docking station to an HDMI display or for extending a desktop setup with an additional monitor. The gripping HDMI connector is especially beneficial in high-traffic areas or setups involving frequent plugging/unplugging.
Desktop & Laptop Connectivity
Connect a DisplayPort output from a desktop, laptop, or external GPU to an HDMI monitor or projector for high-resolution display up to 4K 60Hz HDR.
Secure Commercial Installations
Latching DP and gripping HDMI connectors ensure the cable stays connected in environments with vibration or accidental contact, such as digital signage or security control rooms.
Highlights
- 3m (9.8 ft) active DisplayPort 1.4 to HDMI 2.0b adapter cable supports up to 4K 60Hz with HDR
- 18 Gbps HBR3 bandwidth enables 4:4:4 color and 7.1ch audio
- Gripping HDMI connector prevents accidental disconnections from tension or vibration
- Latching DisplayPort connector secures the cable to the source device
- HDCP 1.4 and 2.3 compliant for protected content playback
- Gold-plated connectors and shielding for reliable signal integrity
- No drivers or software required – works with all operating systems and GPUs
- Backed by a 3-year StarTech.com warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | 3M-DP-HDMI-4K60-GR |
| Brand Name | StarTech.com |
| Product Name | 3m DisplayPort to HDMI Cable |
| Packaged Quantity | 1 |
| Product Type | A/V Cable |
| Technical Information | |
| Cable Type | DisplayPort/HDMI |
| Cable Length | 9.8 ft (3 m) |
| Outer Diameter | 0.22" (5.50 mm) |
| Connector Type on First End | DisplayPort 1.4 Digital Audio/Video |
| Connector Gender on First End | Male |
| Connector on First End Details | 1x Displayport 1.4 Digital Audio/Video - Male |
| Connector Type on Second End | HDMI 2.0b Digital Audio/Video |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1x HDMI 2.0b Digital Audio/Video - Male |
| Connector Plating | Gold |
| Shielding | Yes |
| Device Supported | Audio/Video Device,Monitor,Security System,Switch,External GPU,Display,PC |
| Data Transfer Rate | 18 Gbit/s |
| Features | Active,Gripping Connector,HDR Support,High Bit Rate 3 (HBR3),HDCP 1.4,HDCP 2.3,EMI Protection,Latching Connector,Durable |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Product Material | PVC |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Miscellaneous | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
Does this cable require any drivers or software?
No, this is a plug-and-play adapter cable. It uses the capabilities of your existing GPU (Intel, AMD, or Nvidia) without additional software. It is compatible with all major operating systems, including Windows, macOS, and Linux.
Is the cable shielded to prevent interference?
Yes, the cable includes shielding and EMI protection to minimize electromagnetic interference, ensuring stable video and audio transmission even in electrically noisy environments. This is especially important for long cable runs or setups near other electronic equipment.
What connectors does this cable have?
The cable has a male DisplayPort 1.4 connector on one end and a male HDMI 2.0b connector on the other. The DisplayPort connector features a latching mechanism for a secure hold, while the HDMI connector has a gripping texture to prevent accidental disconnections.
Is this cable HDCP compliant?
Yes, it supports both HDCP 1.4 and HDCP 2.3, ensuring compatibility with protected content from streaming services, Blu-ray players, and other HDCP-enabled sources. This allows you to watch 4K HDR content without issues.
What devices can I connect with this adapter cable?
This cable is designed to connect any device with a DisplayPort output (such as PCs, laptops, external GPUs, or docking stations) to an HDMI display, monitor, projector, or TV. It also works with security systems and switches that have DisplayPort outputs.
