StarTech.com 5G4AINDNP-USB-A-HUB 4-Port Industrial USB 3.0 Hub - 5Gbps - ESD Protection - DIN/Wall/Desk Mountable - USB-A Expansion
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This industrial USB hub operates on USB 3.2 Gen 1 technology, providing 5Gbps shared bandwidth across four downstream-facing USB-A ports. The host connection uses a USB 3.2 Type B interface with a secure screw-lock mechanism, complemented by a 6-foot USB-A to USB-B cable included in the package. Advanced power management features include BC 1.2 charging support delivering up to 12W (2.4A) per port when externally powered, with overcurrent protection safeguarding connected devices.
The hub's electrostatic discharge protection meets industrial standards with 8kV air gap and 4kV contact protection, preventing damage from static electricity in manufacturing or workshop environments. Environmental compliance includes RoHS and WEEE directives, while the 2-year limited warranty provides assurance of industrial-grade reliability.
Relevant factors for this section include Host Interface, Total Number of USB Ports, Number of USB 3.2 Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This industrial USB hub distinguishes itself through robust construction and specialized features tailored for challenging deployment environments. The metal housing provides superior durability compared to consumer-grade plastic hubs, while the comprehensive ESD protection safeguards sensitive equipment from electrostatic discharge events common in industrial settings.
Industrial-Grade Mounting
Three mounting options—DIN rail, wall, and desk—provide installation flexibility for control panels, equipment racks, workstations, and machinery interfaces. The included DIN rail brackets and mounting screws enable quick integration into standard industrial enclosures.
- DIN rail mounting hardware included
- Built-in wall/desk brackets
- Screw-lock port connectors
Flexible Power Configuration
Dual power input options allow deployment in varied electrical environments. Use the standard DC barrel connector or the industrial terminal block for direct wiring to power sources ranging from 5 to 24V DC.
- Barrel connector or terminal block input
- 5-24V DC range
- Optional power adapter available
Deployment / Use Cases
This industrial USB hub serves critical expansion needs in environments where standard consumer hubs would fail. Manufacturing facilities benefit from the ESD protection when connecting measurement instruments, barcode scanners, or programmable logic controller interfaces. The DIN rail mounting makes it ideal for control panel integration, while the rugged construction suits automotive diagnostic stations, laboratory equipment clusters, and outdoor kiosks.
In industrial automation applications, the hub reliably expands USB connectivity for multiple peripherals like touchscreens, keyboards, mice, and data acquisition devices. The screw-lock connectors prevent accidental disconnections in vibrating machinery environments, while the metal enclosure dissipates heat effectively during continuous operation. IT administrators can deploy these hubs in server rooms or network closets where space constraints require wall or rack mounting solutions.
Physical Profile
The hub's compact black metal enclosure measures 7 inches long by 2.30 inches wide by 0.90 inches high (177.80 x 58.42 x 22.86 mm), with a weight of approximately 9.88 ounces (280 grams). This slender profile fits easily on desktops, mounts discreetly on walls, or integrates into crowded DIN rail enclosures. The all-black finish maintains a professional appearance across industrial and office environments.
- Width
- 2.30" (58.42 mm)
- Height
- 0.90" (22.86 mm)
- Weight
- 9.88 oz (280 g)
- Length
- 7" (177.80 mm)
What's in the Box
The package includes all components needed for immediate deployment in various mounting configurations.
Highlights
- 4-port industrial USB 3.0 hub with 5Gbps data transfer speed
- Metal enclosure with ESD protection (8kV air / 4kV contact)
- Flexible mounting: DIN rail, wall, or desk installation
- Screw-lock connectors on host and device ports for secure connections
- Dual power input: barrel connector or terminal block (5-24V DC)
- BC 1.2 charging support with 12W (2.4A) per port
- Overcurrent protection for connected device safety
- Includes 6-foot USB-A to USB-B host cable
- RoHS and WEEE compliant with 2-year warranty
- USB Event Monitoring utility available for download
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | 5G4AINDNP-USB-A-HUB |
| Brand Name | StarTech.com |
| Product Name | USB Hub |
| Packaged Quantity | 1 |
| Product Type | USB Hub |
| Technical Information | |
| Host Interface | USB 3.2 (Gen 1) Type B |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 3.2 Ports | 4 |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Wall/Desktop/DIN Rail Mountable |
| Height | 0.90" (22.86 mm) |
| Width | 2.30" (58.42 mm) |
| Length | 7" (177.80 mm) |
| Weight (Approximate) | 9.88 oz (280 g) |
| Miscellaneous | |
| Package Contents | USB Hub 1 x 6 ft [1.8 m] USB-A to USB-B Cable 1 x Terminal Block Connector (Attached) 1 x DIN Rail Mounting Brackets (With Mounting Screws) 1 x Quick-Start Guide |
| Platform Supported | PC |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What type of USB ports does this industrial hub provide?
The hub provides four downstream-facing USB 3.0 Type-A ports, all supporting USB 3.2 Gen 1 technology with 5Gbps data transfer speeds. These are standard USB-A ports compatible with most USB peripherals, arranged in a single row for easy access. The host connection uses a USB 3.2 Type B port with a screw-lock mechanism for secure attachment.
How does the ESD protection work on this USB hub?
This industrial hub incorporates integrated electrostatic discharge safeguards that protect connected devices up to 8kV for air gap discharges and 4kV for contact discharges. This level of ESD protection is essential in industrial environments where static electricity buildup can damage sensitive electronics. The protection circuitry is built into the hub's design, requiring no additional components or configuration.
What mounting options are included with this hub?
The hub supports three mounting methods: DIN rail, wall, and desk installation. The package includes DIN rail mounting brackets with screws for industrial rack integration, while built-in brackets allow direct wall or desk mounting. Screw-lock connectors on both the host port and device ports ensure connections remain secure even in vibrating environments.
What power sources can I use with this industrial USB hub?
The hub accepts 5-24V DC power through either a standard DC barrel connector or an attached terminal block for direct wiring. This dual-input design provides flexibility for different power supply scenarios. The hub does not include a power adapter, but an optional adapter (ITB20D3250) is available separately for terminal block power delivery.
Does this hub support charging of connected devices?
Yes, when connected to an external power source, the hub supports BC 1.2 charging technology, delivering up to 12W (2.4A) per port. This enables faster charging of smartphones, tablets, and other USB-powered devices compared to standard USB power delivery. Overcurrent protection prevents connected devices from drawing excessive power that could damage the hub or peripherals.
What is included in the package with this USB hub?
The complete package includes the USB hub unit, a 6-foot USB-A to USB-B host cable for connection to your computer, an attached terminal block connector for alternative power wiring, DIN rail mounting brackets with screws, and a quick-start guide. All necessary hardware for wall, desk, or DIN rail installation is provided, allowing immediate deployment in various environments.
