Maxell RK630WALVS StarTech. com 6U Vertical Wall-Mount Server Cabinet - 30 in. Depth - Enclosed Steel Rack with Locking Doors
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This 6U vertical cabinet delivers robust technical specifications tailored for professional IT deployments. The enclosure measures 37 inches in height, 25.40 inches in width, and 11.60 inches in length, with a rack depth of 29.90 inches to fit most server and networking equipment. It supports a static weight capacity of 198.42 lb, ensuring stable operation under load.
The cabinet includes two rack posts and adjustable mounting rails for flexible equipment positioning. A dedicated 2U mounting bracket at the top of the enclosure offers additional organization for patch cables or lightweight accessories. The unit weighs 72.75 lb and requires no assembly, simplifying deployment.
Key Product Advantages
The RK630WALVS combines space-saving design with enterprise-grade security and durability. Its vertical wall-mount form factor reduces floor footprint while keeping equipment accessible and organized.
Enhanced Security
Locking front and side panels protect equipment from unauthorized access, with separate keys for each lock to control entry points independently.
- Key lock on door
- Lockable access panel
- Sturdy steel construction
Simplified Installation
The cabinet comes fully assembled with pre-spaced mounting holes (16 inches apart) and includes all hardware for quick wall mounting and equipment installation.
- No assembly required
- Includes mounting screws and washers
- Pre-drilled hole spacing
Deployment / Use Cases
This vertical server cabinet is optimized for environments where space is at a premium but equipment security remains paramount. Its enclosed design and locking mechanisms make it suitable for shared or public areas where physical access control is necessary.
Common deployments include wall-mounting in network closets to centralize patch panels and switches, installing in small server rooms to house compact servers, or using in office IT areas to organize networking gear. The 6U capacity accommodates a mix of equipment, such as a 1U switch, 2U server, and patch panels, while the 2U top bracket helps manage cable runs.
Physical Profile
The cabinet features a black powder-coated steel finish that resists corrosion and blends into professional settings. Its compact depth of 11.60 inches extends minimally from the wall, while the 25.40-inch width provides ample internal space for cable management. The vented design promotes airflow to prevent overheating, and the robust steel frame ensures long-term stability even under full load.
- Width
- 25.40" (645.16 mm)
- Depth
- 29.90" (759.46 mm)
- Height
- 37" (939.80 mm)
- Weight
- 200 lb (90718.47 g)
- Length
- 11.60" (294.64 mm)
What's in the Box
The cabinet ships complete with all components needed for installation and operation.
Highlights
- 6U vertical wall-mount server cabinet with 30-inch depth for standard-depth equipment
- Enclosed steel construction with locking front and side panels for enhanced security
- Supports up to 200 lb maximum weight capacity with adjustable mounting rails
- Includes a 2U top mounting bracket for organizing patch cables or accessories
- Fully assembled with all hardware included for hassle-free installation
- Vented design promotes airflow to prevent equipment overheating
- Black powder-coated finish for durability and professional appearance
- Backed by a 5-year limited warranty and lifetime technical support
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | RK630WALVS |
| Brand Name | StarTech.com |
| Product Name | 6U Vertical Server Cabinet - 30 in. Depth |
| Packaged Quantity | 1 Each |
| Product Type | Rack Cabinet |
| Technical Information | |
| Rack Type | Enclosed Cabinet |
| Application/Usage | Server,LAN Switch,Patch Panel,Switch |
| Features | Adjustable Mounting Rails,Key Lock,Lockable Door |
| Rack Post Quantity | 2 |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Color Family | Black |
| Product Color | Black |
| Product Material | Steel |
| Maximum Weight Capacity | 200 lb (90718.47 g) |
| Static/Stationary Weight Capacity | 198.42 lb (90000 g) |
| Height | 37" (939.80 mm) |
| Width | 25.40" (645.16 mm) |
| Length | 11.60" (294.64 mm) |
| Rack Height | 6U |
| Rack Depth | 29.90" (759.46 mm) |
| Weight (Approximate) | 72.75 lb (33000 g) |
| Miscellaneous | |
| Package Contents | 1 x Wall-Mount Rack 2 x Door Keys 2 x Front-Panel Keys 24 x 12-24 Screws 24 x Plastic Washers 1 x Instruction Manual |
| Assembly Required | No |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the maximum weight capacity of this wall-mount server cabinet?
The RK630WALVS supports a maximum weight capacity of 200 lb (90718.47 g), with a static/stationary weight capacity of 198.42 lb (90000 g). This ensures it can securely hold a full load of servers, switches, and other rack-mount equipment without compromising stability.
Does this cabinet require assembly before installation?
No, the cabinet comes fully assembled from the factory. It includes all necessary hardware such as screws, washers, and keys, so you can mount it directly to the wall and begin installing your equipment without any additional assembly steps.
What types of equipment are compatible with this 6U vertical cabinet?
This cabinet is designed for servers, LAN switches, patch panels, and other standard rack-mount networking gear. Its 30-inch depth accommodates most server and switch models, while the adjustable mounting rails provide flexibility for different equipment sizes and configurations.
How does the locking mechanism work on this server cabinet?
The cabinet features separate key locks on both the front door and the side access panel. Each lock includes its own set of keys (two door keys and two front-panel keys are provided), allowing you to control access independently for enhanced security in multi-user environments.
What are the dimensions of this vertical wall-mount cabinet?
The cabinet measures 37 inches in height, 25.40 inches in width, and 11.60 inches in length, with a rack depth of 29.90 inches. These dimensions provide a compact footprint while offering 6U of vertical rack space for equipment installation.
What warranty and support does StarTech.com offer for this product?
The RK630WALVS is backed by a 5-year limited warranty from StarTech.com. Additionally, it includes free lifetime 24/5 multi-lingual technical assistance, providing ongoing support for installation, configuration, and troubleshooting throughout the product's lifespan.
