StarTech. com NLWH-7F-CAT6A-PATCH CAT6a Ethernet Patch Cable - 7ft White S/FTP Shielded 10GbE 100W PoE++ Snagless RJ-45
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This CAT6a patch cable meets ANSI/TIA-568.2-D standards and is ETL verified for compliance. The S/FTP shielding configuration features individual foil shielding around each twisted pair plus an overall braided shield, providing comprehensive protection against EMI/RFI interference.
The 27 AWG stranded copper construction supports multi-gigabit speeds from 1GbE to 10GbE with minimized near-end crosstalk. Snagless molded boots with strain relief protect the connector latches from damage during installation and cable management.
Shielding Architecture
S/FTP (Shielded/Foil Twisted Pair) design combines foil shielding on individual pairs with an overall braided shield for maximum noise rejection in dense network environments.
- Individual pair foil shielding
- Overall braided shield
- Shielded RJ-45 connectors
Performance Validation
Tested to CAT6a specifications with Fluke certification and ETL verification, ensuring reliable performance across the full 500 MHz bandwidth.
- ANSI/TIA-568.2-D compliant
- Fluke tested
- ETL verified
Key Product Advantages
This cable combines multiple professional features that distinguish it from basic patch cords. The LSZH jacket material represents a safety upgrade over standard PVC, producing less dense and less corrosive smoke while maintaining excellent durability.
Enhanced PoE Performance
100% stranded copper conductors deliver stable power for PoE++ devices up to 100W, avoiding the voltage drop issues common with copper-clad aluminum alternatives.
- IEEE 802.3bt compliant
- Supports Type 4 PoE
- Stable power delivery
Durability Features
Multiple construction elements extend cable life in high-use environments where frequent connection changes and cable movement occur.
- Snagless molded boots
- Strain relief design
- Bend-resistant construction
Deployment / Use Cases
This shielded CAT6a patch cable is ideal for connecting network equipment in environments where electrical interference or PoE requirements demand higher performance. The 7-foot length makes it suitable for rack-to-rack connections within server cabinets or between adjacent network devices.
Common applications include connecting switches to PoE++ access points, security cameras, and VoIP phones in commercial installations. The white color blends well with office environments while the LSZH jacket meets building code requirements for plenum-rated spaces in many jurisdictions.
Commercial Network Infrastructure
Deploy in office buildings, retail spaces, and educational facilities where reliable 10GbE connectivity and PoE power delivery are essential for modern network devices.
- Conference room installations
- Security system connections
- Wireless access point links
Data Center Edge Connections
Use for final connections between top-of-rack switches and servers or storage devices where shielded cabling prevents interference from adjacent equipment.
- Server room patching
- Network closet terminations
- Equipment rack interconnects
Physical Profile
The cable features a clean white LSZH jacket that maintains flexibility while resisting damage from bending and crushing. At 2.80 ounces (79.38 grams), it provides substantial construction without excessive weight that could strain port connections.
- Weight
- 2.80 oz (79.38 g)
- Length
- 7 ft (2.13 m)
Highlights
- CAT6a Ethernet patch cable supporting 10GbE data transfer speeds
- 7-foot length (2.13 m) with snagless RJ-45 connectors on both ends
- S/FTP shielding with foil and braid for maximum EMI/RFI protection
- Supports 100W PoE++ (IEEE 802.3bt) for powering connected devices
- LSZH (Low Smoke Zero Halogen) jacket for enhanced fire safety
- 100% stranded copper conductors with gold-plated contacts
- ETL verified and compliant with ANSI/TIA-568.2-D standards
- White color with durable, bend-resistant construction
- Includes strain relief and latch protection features
- Backed by StarTech.com lifetime warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | NLWH-7F-CAT6A-PATCH |
| Brand Name | StarTech.com |
| Product Name | Cat.6a S/FTP Patch Network Cable |
| Packaged Quantity | 1 |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Category 6a |
| Cable Characteristic | Patch Cable |
| Cable Length | 7 ft (2.13 m) |
| Connector Type on First End | RJ-45 Network - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Contact Plating | Gold |
| Shielding | Yes |
| Jacket Type | LSZH |
| Device Supported | Network Device |
| American Wire Gauge | 27 AWG |
| Data Transfer Rate | 10 Gbit/s |
| Boot Type | Snagless,Molded |
| Number of Pairs | 4 |
| Features | PoE,PoE++,Stranded,EMI/RF Protection,Snag Resistant,Strain Relief,Minimized Near-End Crosstalk (NEXT),PVC Free,Damage Resistant,Bend Resistant,Noise Protection,Latch Protection |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Product Material | Copper,Ethylene Vinyl Acetate (EVA),Aluminum Hydroxide |
| Shielding Material | Foil |
| Weight (Approximate) | 2.80 oz (79.38 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the difference between CAT6 and CAT6a cable?
CAT6a cable supports 10 Gigabit Ethernet at the full 100-meter distance, while standard CAT6 is limited to 55 meters for 10GbE. CAT6a also provides improved alien crosstalk performance and operates at 500 MHz bandwidth compared to CAT6's 250 MHz. This StarTech.com cable meets CAT6a specifications with S/FTP shielding for maximum performance in demanding environments.
Does this cable support Power over Ethernet?
Yes, this cable fully supports Power over Ethernet up to 100W PoE++ (IEEE 802.3bt Type 4). The 100% stranded copper construction ensures stable power delivery without voltage drop issues. It's backward compatible with earlier PoE standards including PoE (802.3af) and PoE+ (802.3at) for connecting a wide range of powered devices.
What does S/FTP shielding mean?
S/FTP stands for Shielded/Foil Twisted Pair. This cable has individual foil shielding around each of the four twisted pairs (FTP) plus an overall braided shield around all pairs (S). This dual-layer shielding provides superior protection against electromagnetic interference (EMI) and radio frequency interference (RFI) compared to unshielded or single-shielded cables.
Why choose an LSZH jacket over standard PVC?
LSZH (Low Smoke Zero Halogen) jackets produce significantly less smoke and toxic halogen gases when exposed to fire compared to PVC jackets. This makes them safer for commercial installations, particularly in enclosed spaces like plenums, server rooms, and office buildings where smoke inhalation poses a serious risk during fire events.
What are the snagless boots for?
The snagless molded boots protect the RJ-45 connector latches from breaking when cables are pulled through tight spaces or around obstacles. The boot design includes strain relief to prevent cable bending at the connection point, extending the cable's lifespan in environments where frequent connection changes occur.
Is this cable compatible with my existing network equipment?
This CAT6a cable is fully backward compatible with CAT6, CAT5e, and earlier Ethernet standards. It will work with any standard RJ-45 port on switches, routers, computers, and network devices. The 10GbE capability ensures it won't bottleneck future network upgrades while working perfectly with current 1GbE and 2.5GbE equipment.
