Product Features
Technical Overview
This adapter cable implements DisplayPort 1.4 to HDMI 2.0b conversion with HBR3 signaling, enabling 4K 60Hz output with HDR metadata pass-through. The active circuitry handles protocol conversion internally, ensuring compatibility with DisplayPort sources that lack native HDMI output capability.
The cable supports HDCP 2.3 content protection for streaming 4K HDR content from services like Netflix and Disney+. It also maintains backward compatibility with HDCP 1.4 for legacy content. Audio support includes 7.1-channel uncompressed PCM, ensuring complete AV synchronization without separate audio cables.
This section brings together practical product details such as Cable Type, Cable Length, Connector Type on First End, Color Family, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
This integrated adapter cable solution reduces points of failure compared to separate cable and adapter combinations. The active design ensures signal integrity over the full cable length, with adaptive receiver equalization that optimizes input signals and amplifies output to maintain display compatibility across different systems.
Universal Compatibility
Works with any DisplayPort source including desktops from Dell, HP, Lenovo, and others. Compatible with integrated Intel graphics, AMD Radeon, and NVIDIA GeForce GPUs without requiring additional drivers or software.
- No driver installation needed
- Works with any operating system
- Utilizes GPU capabilities directly
Enhanced Signal Integrity
Cage shielding prevents electromagnetic interference (EMI) that can cause signal degradation or visual artifacts. The latching DisplayPort connector ensures a secure connection that won't accidentally disconnect during use.
- EMI protection maintains signal quality
- Latching connector for reliability
- Gold plating reduces corrosion
Deployment / Use Cases
This cable is essential for connecting modern workstations with DisplayPort outputs to HDMI 2.0b monitors, televisions, or projectors. It's particularly valuable in corporate environments where employees need to connect laptops or desktops to conference room displays that typically feature HDMI inputs.
For content creators and video editors, the HDR support ensures accurate color representation when working with HDR content. The 4K 60Hz capability makes it suitable for gaming setups where high refresh rates and resolution are priorities. In digital signage applications, the reliable active conversion ensures consistent display output without signal dropouts.
Professional Workstations
Connect CAD/CAM workstations, video editing rigs, or financial trading desks to 4K reference monitors with full HDR capability and color accuracy.
Conference Room AV
Simplify laptop-to-display connections in meeting rooms where presenters need reliable 4K output without compatibility issues between different device brands.
Physical Profile
The cable features a durable PVC jacket that provides flexibility while protecting internal conductors. The black color blends discreetly with most office and home theater environments. At 4.70 ounces (133.24 grams), the cable has substantial build quality without excessive weight that could strain connectors.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4.70 oz (133.24 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 4.70 oz (133.24 g)
- Length
- 9.8 ft (3 m)
Highlights
- Active DisplayPort to HDMI 2.0b adapter cable with integrated conversion
- Supports 4K resolution at 60Hz refresh rate with HDR metadata pass-through
- 18 Gbps bandwidth enables 4:4:4/RGB color space and 8-bit color with dithering
- HDCP 2.3 content protection for streaming 4K HDR services
- 7.1-channel uncompressed audio support without separate cables
- 9.8-foot (3-meter) length provides flexible placement options
- Gold-plated connectors with latching DisplayPort for reliable connections
- EMI shielding prevents signal interference in electrically noisy environments
- Backward compatible with 4K 30Hz, 1080p, and lower resolutions
- RoHS compliant and backed by 3-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | 10F-DP-HDMI-4K60-HDR |
| Brand Name | StarTech.com |
| Product Name | DisplayPort/HDMI A/V Cable |
| Packaged Quantity | 1 |
| Product Type | A/V Cable |
| Technical Information | |
| Cable Type | DisplayPort/HDMI |
| Cable Length | 9.8 ft (3 m) |
| Connector Type on First End | DisplayPort 1.4 Digital Audio/Video - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x DisplayPort 1.4 Digital Audio/Video - Male |
| Connector Type on Second End | HDMI 2.0b Digital Audio/Video - Male |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1 x HDMI 2.0b Digital Audio/Video - Male |
| Connector Plating | Gold |
| Shielding | Yes |
| Device Supported | Audio/Video Device,Monitor,Computer,Graphic Card,Display |
| Data Transfer Rate | 18 Gbit/s |
| Supported Resolution | 4096 x 2160 |
| Features | HDR Support,Active,HDCP 1.4,HDCP 2.3,EMI Protection |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Product Material | PVC |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Weight (Approximate) | 4.70 oz (133.24 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the difference between this active adapter cable and a passive DisplayPort to HDMI cable?
This is an active adapter cable with integrated circuitry that converts DisplayPort signals to HDMI 2.0b protocol. Passive cables only work when the DisplayPort source has native HDMI compatibility (DisplayPort++). The active design ensures compatibility with all DisplayPort sources, including those without native HDMI output capability, and maintains signal integrity over the full 9.8-foot length.
Does this cable support HDR content from streaming services like Netflix?
Yes, the cable supports HDR metadata pass-through and HDCP 2.3 content protection, which is required for streaming 4K HDR content from services like Netflix, Disney+, and Amazon Prime Video. The active conversion preserves HDR information while maintaining the necessary copy protection protocols for premium content playback.
What audio formats does this cable support?
The cable supports 7.1-channel uncompressed PCM audio, allowing multi-channel audio to pass through alongside video without requiring separate audio cables. This includes support for Dolby Digital and DTS formats when the source device encodes them as PCM. The audio is synchronized with video output for a complete AV experience.
Will this cable work with my gaming PC and 4K monitor?
Yes, the cable is ideal for gaming setups, supporting 4K resolution at 60Hz refresh rate with HDR. The 18 Gbps bandwidth ensures sufficient data throughput for gaming at this resolution. It works with NVIDIA GeForce, AMD Radeon, and Intel integrated graphics cards that have DisplayPort outputs, connecting them to HDMI 2.0b gaming monitors or televisions.
How does the EMI shielding improve performance?
The cage shielding around the cable conductors prevents electromagnetic interference from nearby power cables, motors, or wireless devices that can cause signal degradation, visual artifacts, or sync issues. This is particularly important in office environments with dense electronics or industrial settings where electrical noise is common, ensuring consistent 4K video transmission.
What is the warranty coverage for this adapter cable?
StarTech.com provides a 3-year limited warranty for this adapter cable, covering defects in materials and workmanship. The cable is also RoHS compliant, meaning it's manufactured without hazardous substances like lead, mercury, and cadmium, making it environmentally responsible for corporate and institutional purchasing.
What resolution or display format is specified?
It features a display specification of 4096 x 2160, giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
