Product Features
Technical Overview
This SFP+ module operates on the 10GBASE-LRM standard, providing 10 Gbps data transfer over multimode fiber with a 1310nm wavelength. The LC duplex connector ensures secure fiber optic connections, while the hot-pluggable, hot-swappable form factor allows for installation and replacement without powering down network devices. Digital Diagnostic Monitoring (DDM) enables real-time monitoring of temperature, voltage, laser bias, and optical power, facilitating proactive network management.
The module is fully compliant with Multi-Source Agreement (MSA) standards, ensuring interoperability with a wide range of networking hardware. It supports multimode fiber (MMF) and is optimized for short to medium-distance deployments up to 200 meters. The compact dimensions of 0.50" x 0.50" x 2.30" and lightweight design at 0.70 oz make it suitable for high-density switch environments.
Key Product Advantages
This transceiver module delivers enterprise-grade performance with broad compatibility and robust support. It is rigorously tested for OEM host compatibility, ensuring reliable operation in Cisco routers and switches without voiding OEM support agreements. The lifetime warranty covers the module for its entire lifespan, providing long-term value and peace of mind.
Wide Compatibility
Works with Cisco switches like Firepower, ASR9000, C9300, C3850, C9500, and other MSA-compliant switches from Ubiquiti, D-Link, Netgear, Supermicro, and TP-Link.
- Tested for OEM host compatibility
- Hot-swappable in Cisco devices
- MSA compliant for broad interoperability
Advanced Monitoring
Digital Diagnostic Monitoring (DDM) provides real-time status reporting to SNMP tools, enabling proactive network management and troubleshooting.
- Monitors temperature, voltage, laser bias
- Integrates with SNMP management tools
- Enhances network visibility
Deployment / Use Cases
This SFP+ module is ideal for upgrading or expanding 10 Gigabit Ethernet networks in data centers, enterprise campuses, and service provider environments. It supports optical network and data networking applications where multimode fiber infrastructure is already deployed or preferred for cost-effective high-speed connectivity.
Common use cases include connecting switches to servers, storage arrays, or aggregation points within a building or campus. The 200-meter distance support makes it suitable for intra-building links, while the hot-swappable design allows for maintenance and upgrades without network downtime. It is also used in network segmentation, backbone extensions, and high-performance computing clusters requiring reliable 10GbE links.
Data Center Upgrades
Enhance network performance by deploying 10GbE links between switches and servers in existing multimode fiber environments.
Enterprise Network Expansion
Extend 10GbE connectivity across floors or buildings using multimode fiber, supported by Cisco and MSA-compliant switches.
Physical Profile
The module features a compact, industry-standard SFP+ form factor with dimensions of 0.50" (12.70 mm) in height, 0.50" (12.70 mm) in width, and 2.30" (58.42 mm) in depth. It weighs approximately 0.70 oz (19.84 g), making it lightweight and suitable for high-density switch installations. The hot-pluggable design allows for easy insertion and removal, while the robust construction ensures durability in demanding networking environments.
- Width
- 0.50" (12.70 mm)
- Depth
- 2.30" (58.42 mm)
- Height
- 0.50" (12.70 mm)
- Weight
- 0.70 oz (19.84 g)
Highlights
- 100% compatible with Cisco SFP-10G-LRM and switches like Firepower, ASR9000, C9300, C3850, C9500
- 10GBASE-LRM 10 Gbps multimode fiber LC transceiver with 1310nm wavelength
- Digital Diagnostic Monitoring (DDM) for real-time status reporting to SNMP tools
- Hot-swappable, MSA compliant design for easy deployment and broad interoperability
- Supports distances up to 200 meters (656 feet) over multimode fiber
- Lifetime warranty backed by StarTech.com technical support
- Works with MSA-compliant switches from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link
- Compact dimensions: 0.50" x 0.50" x 2.30", weight 0.70 oz
- Environmentally friendly and manufactured in Taiwan
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SFP10GLRMST |
| Brand Name | StarTech.com |
| Product Name | Cisco SFP-10G-LRM Compatible SFP+ Transceiver Module - 10GBASE-LRM |
| Product Type | SFP+ |
| Packaged Quantity | 1 Each |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-LRM Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-LRM |
| Physical Characteristics | |
| Form Factor | Hot-pluggable,Hot-swappable |
| Height | 0.50" (12.70 mm) |
| Width | 0.50" (12.70 mm) |
| Depth | 2.30" (58.42 mm) |
| Weight (Approximate) | 0.70 oz (19.84 g) |
| Miscellaneous | |
| Compatibility | MSA Compliant Cisco Firepower Switches: ASR9000 C9300 C3850 C9500 |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum distance this SFP+ module supports?
This module supports distances up to 200 meters (656 feet) over multimode fiber when used with the 10GBASE-LRM standard. It is optimized for short to medium-range deployments within buildings or campuses, providing reliable 10 Gbps connectivity without requiring single-mode fiber infrastructure.
Is this transceiver compatible with non-Cisco switches?
Yes, this transceiver is MSA compliant and works with a wide range of networking equipment beyond Cisco. It is compatible with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link, and other manufacturers that accept uncoded MSA-compliant SFP+ modules, ensuring flexibility in mixed-vendor environments.
Does this module support Digital Diagnostic Monitoring (DDM)?
Yes, this SFP+ module includes Digital Diagnostic Monitoring (DDM) functionality. It reports real-time parameters such as temperature, voltage, laser bias, and optical power to most SNMP network management tools, enabling proactive monitoring, troubleshooting, and performance optimization in your network infrastructure.
What type of fiber connector does this transceiver use?
This transceiver uses an LC duplex connector, which is a standard small-form-factor connector for fiber optic cables. The LC connector provides secure, low-loss connections for multimode fiber, making it ideal for high-density networking applications where space is at a premium.
Can this module be hot-swapped during operation?
Yes, this SFP+ module is hot-pluggable and hot-swappable, allowing you to install, remove, or replace it without powering down your switch or router. This feature minimizes network downtime during maintenance, upgrades, or troubleshooting, ensuring continuous operation in critical environments.
What warranty does StarTech.com offer for this transceiver?
StarTech.com provides a lifetime warranty for this SFP+ module, covering the transceiver for its entire lifespan. The warranty is specific to the module itself and does not void your OEM support agreements. Additionally, technical support is available from StarTech.com's Tech Advisors to assist with deployment and compatibility questions.
