StarTech.com DKT30CHVSDPD 9-in-1 USB-C Docking Station - 100W PD - 4K HDMI/VGA - Gigabit Ethernet - SD/microSD Reader - Space Gray
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This docking station connects via a USB 3.1 Gen 1 Type-C host interface, providing 5Gbps data transfer speeds. The video subsystem supports a single external display at resolutions up to 4K (4096 x 2160 or 3840 x 2160) at 30Hz through HDMI, with VGA support for legacy monitors. DisplayPort Alt Mode is required for video functionality.
The power architecture implements USB Power Delivery 3.0 with 100W total capacity, allocating up to 85W for laptop charging while reserving 15W for stable adapter operation. Network connectivity includes Gigabit Ethernet with PXE boot and Wake-on-LAN support. The integrated memory card readers handle both SD and microSD formats.
Relevant factors for this section include Connectivity Technology, Number of Displays Supported, Supported Resolutions, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This docking station stands out with its balanced combination of high-power delivery, comprehensive connectivity, and intelligent design for reliable daily use. Unlike basic hubs that can overdraw power, the dedicated 15W reserve ensures consistent performance across all connected devices.
Extended Reach Design
The 12-inch attached cable provides flexibility for devices on riser stands or in docking stations, reducing mechanical stress on laptop USB-C ports.
- Reduces port strain
- Accommodates various setups
- 30cm working length
Broad Device Compatibility
Works with USB-C laptops, Ultrabooks, Chromebooks, and Thunderbolt 3/4 systems from major manufacturers including HP, Dell, Lenovo, Apple MacBooks (Intel and M1), and Microsoft Surface devices.
- USB-C and Thunderbolt
- Cross-platform support
- Enterprise device coverage
Deployment / Use Cases
This versatile docking station serves multiple professional scenarios where expanded connectivity and single-cable simplicity are paramount. The compact form factor and complete port selection make it equally suitable for permanent desk setups and mobile work environments.
For hybrid office workers, the docking station enables quick transitions between home and office workspaces with consistent peripheral connections. IT departments can standardize on this solution for employees using various laptop models, while business travelers benefit from the lightweight design that consolidates multiple adapters into one reliable unit.
Desktop Expansion
Convert any USB-C laptop into a full workstation with external monitor, wired network, peripherals, and charging through a single connection.
Mobile Professional Kit
Carry one compact adapter instead of multiple dongles for presentations, hotel workstations, or client site visits with varying connectivity needs.
Physical Profile
Measuring 12.80 inches wide by 0.60 inches tall, the docking station presents a low-profile footprint that fits discreetly on any workspace. The Space Gray aluminum housing provides durability for frequent transport while maintaining a professional appearance that complements business laptops and accessories.
At just 4.80 ounces, the lightweight design adds minimal bulk to laptop bags. The portable form factor and included 12-inch cable make positioning flexible whether used on a desk, mounted under a monitor, or placed alongside a laptop on riser stands.
- Width
- 12.80" (325.12 mm)
- Height
- 0.60" (15.24 mm)
- Weight
- 4.80 oz (136.08 g)
Highlights
- 9-in-1 connectivity with HDMI 4K, VGA, Gigabit Ethernet, USB ports, and SD/microSD readers
- 100W USB Power Delivery 3.0 with up to 85W laptop charging capacity
- 12-inch attached USB-C cable reduces port strain on devices
- Intelligent power management reserves 15W to prevent video flickering
- Compatible with USB-C and Thunderbolt 3/4 laptops from HP, Dell, Lenovo, Apple, Microsoft
- Works with Windows, macOS, ChromeOS, iPadOS, and Android operating systems
- Portable aluminum construction in Space Gray for professional mobility
- Includes StarTech.com connectivity tools for enhanced performance and security
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | DKT30CHVSDPD |
| Brand Name | StarTech.com |
| Product Name | Docking Station |
| Product Type | Docking Station |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Displays Supported | 1 |
| Supported Resolutions | 4096 x 2160,3840 x 2160,1920 x 1080 |
| Screen Mode Supported | 4K |
| Memory Card Reader | Yes |
| Memory Card Supported | SD,microSD |
| Device Supported | Monitor,Tablet,Notebook |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Host Interface | USB 3.1 (Gen 1) Type C |
| Number of USB 3.1 Gen 1 Type-A Ports | 2 |
| USB Type-C | Yes |
| USB Type-C Detail | USB Type-C (24 pin, 5Gbps), USB Type-C (24 pin) USB Power Delivery only, USB Type-C (24 pin) |
| USB Type-A | Yes |
| Network (RJ-45) | Yes |
| VGA | Yes |
| HDMI | Yes |
| Software | |
| Operating System Supported | macOS 14,Windows 7,Windows 8,Windows 8.1,Windows 10,Windows 11,Mac OS X 10.9 Mavericks,Mac OS X 10.15 Catalina,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Mac OS X 13.0 Ventura,ChromeOS |
| Power Description | |
| Maximum Power Supply Wattage | 100 W |
| Physical Characteristics | |
| Product Color | Space Gray |
| Form Factor | Portable |
| Height | 0.60" (15.24 mm) |
| Width | 12.80" (325.12 mm) |
| Weight (Approximate) | 4.80 oz (136.08 g) |
| Miscellaneous | |
| Compatibility | Fully compatible with USB-C laptops, Ultrabooks & Chromebooks, plus Thunderbolt 3/4 laptops from HP, Dell, Lenovo, MacBooks (Intel processor and M1 chip), and Surface; works w/ Windows, macOS, iPadOS, Android and Chrome OS |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
User Manual
FAQ
What video resolutions does this docking station support?
The docking station supports a single external display at resolutions up to 4K, specifically 4096 x 2160 and 3840 x 2160 at 30Hz through HDMI, plus 1920 x 1080 Full HD. VGA output is also available for legacy monitors. DisplayPort Alt Mode capability in your laptop's USB-C port is required for video functionality.
How much power can this docking station deliver to my laptop?
The docking station features 100W USB Power Delivery 3.0, with up to 85W available for charging your laptop. The system intelligently reserves 15W for the adapter's own operation to ensure stable performance and prevent the power overdraw issues common in less sophisticated hubs.
What devices are compatible with this USB-C docking station?
This docking station is fully compatible with USB-C laptops, Ultrabooks, and Chromebooks, plus Thunderbolt 3 and 4 laptops from major manufacturers including HP, Dell, Lenovo, Apple MacBooks (both Intel processor and M1 chip models), and Microsoft Surface devices. It works across Windows, macOS, iPadOS, Android, and ChromeOS operating systems.
Does this docking station include an Ethernet port?
Yes, it includes a Gigabit Ethernet (RJ-45) port that provides wired network connectivity with support for PXE boot and Wake-on-LAN functionality. This is particularly valuable in corporate environments where wired connections offer more security and reliability than Wi-Fi.
What memory card formats does the built-in reader support?
The integrated memory card reader supports both SD and microSD card formats. This dual-format capability accommodates most common memory cards used in cameras, smartphones, and other portable devices without requiring separate adapters.
Is this docking station portable enough for travel?
Absolutely. With dimensions of 12.80 x 0.60 inches and weighing only 4.80 ounces, the compact aluminum design is specifically engineered for portability. The Space Gray finish provides durability for frequent transport in laptop bags between office, home, and business travel locations.
