StarTech.com HB31C5A2CME 7-Port Industrial USB 3.2 Gen 2 Hub - 5x USB-A & 2x USB-C 10Gbps - Mountable with Power Adapter & ESD Protection
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This USB hub operates on the USB 3.2 Gen 2 standard, delivering theoretical transfer rates up to 10Gbps with practical throughput reaching 1.25 GB/s. The hub supports RAID configurations and functions as a plug-and-play device without requiring additional drivers, maintaining compatibility across Windows, macOS, Linux, and ChromeOS environments.
The electrical protection system includes ESD protection rated at 15kV air/8kV contact and 350W surge protection, safeguarding connected equipment from electrostatic discharge and power fluctuations. Power delivery is managed through a universal terminal block power adapter that accepts 7-24V DC input, with each port capable of providing 12W (2.4A) up to a total system draw of 40W.
Relevant factors for this section include Host Interface, RAID Supported, Features, Data Transfer Rate. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This industrial USB hub distinguishes itself through robust construction and comprehensive protection features that ensure reliable operation in challenging environments. The steel housing provides physical durability while the integrated ESD and surge protection mechanisms safeguard connected equipment from electrical damage.
Versatile Mounting System
Includes built-in mounting ears and a DIN mounting kit for flexible installation on surfaces, walls, or standard DIN rails, enabling organized deployment in industrial and commercial settings.
- Surface mount capable
- DIN rail compatible
- Wall mount ready
Enhanced Connection Security
Features screw-lock USB-C host connectors on included cables to prevent accidental disconnections, ensuring stable connections in vibration-prone environments.
- Locking USB-C connectors
- 3.3 ft cable length
- Dual cable types included
Broad Compatibility
Maintains backward compatibility with USB 3.0 (5Gbps), USB 2.0, and USB 1.x devices while supporting modern high-speed peripherals through its USB 3.2 Gen 2 architecture.
- OS independent
- No drivers required
- Backward compatible
Deployment / Use Cases
This industrial USB hub is particularly effective in environments requiring multiple peripheral connections with high-speed data transfer capabilities. Its rugged design and mounting flexibility make it ideal for manufacturing floors, laboratory settings, and data centers where equipment must withstand physical and electrical challenges.
The hub excels in connecting storage arrays, with specific optimization for solid-state drives, NVMe enclosures, and RAID enclosures that benefit from the 10Gbps bandwidth. The combination of USB-A and USB-C ports allows simultaneous connection of legacy and modern devices, supporting mixed-device environments without requiring additional adapters.
Data Storage Applications
Ideal for connecting multiple external storage devices including SSDs, hard drive enclosures, and RAID arrays where high-speed data transfer is critical for backup operations, data migration, or expanded storage capacity.
Industrial Peripheral Management
Suitable for connecting printers, scanners, 3D printers, and other manufacturing or laboratory equipment that requires stable, high-speed USB connections in controlled or harsh environments.
Physical Profile
The hub features a compact industrial design measuring 7" in height, 1" in width, and 2.40" in length, with a weight of approximately 10.60 ounces. The black steel construction provides both durability and a professional appearance suitable for visible installations. The form factor supports multiple mounting configurations including surface mounting with the included hardware or DIN rail attachment for integration into standardized industrial control panels and racks.
- Width
- 1" (25.40 mm)
- Height
- 7" (177.80 mm)
- Weight
- 10.60 oz (300.50 g)
- Length
- 2.40" (60.96 mm)
What's in the Box
The package includes all necessary components for immediate deployment and flexible installation options.
Highlights
- 7-port industrial USB 3.2 Gen 2 hub with 10Gbps shared bandwidth
- 5x USB-A and 2x USB-C downstream ports for versatile connectivity
- ESD protection (15kV air/8kV contact) and 350W surge protection
- Surface, wall, or DIN rail mountable with included mounting kit
- Steel construction for durability in harsh environments
- Plug-and-play operation with no drivers required
- Backward compatible with USB 3.0, 2.0, and 1.x devices
- Universal power adapter with 7-24V DC terminal block input
- Includes locking USB-C cables to prevent disconnection
- TAA compliant and RoHS/WEEE environmental compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | HB31C5A2CME |
| Brand Name | StarTech.com |
| Product Name | USB Hub |
| Packaged Quantity | 1 |
| Product Type | USB Hub |
| Technical Information | |
| Host Interface | USB 3.2 Gen 2 |
| RAID Supported | Yes |
| Features | Plug and Play |
| Media & Performance | |
| Data Transfer Rate | 1.25 GB/s,640 MB/s |
| Interfaces/Ports | |
| Total Number of USB Ports | 7 |
| USB Version | 3.2 Gen 2 |
| USB Connector Type | Type-C,Type-A |
| Software | |
| Operating System Supported | Windows,macOS,Linux,ChromeOS |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Product Material | Steel |
| Form Factor | Surface/DIN Rail Mountable |
| Height | 7" (177.80 mm) |
| Width | 1" (25.40 mm) |
| Length | 2.40" (60.96 mm) |
| Weight (Approximate) | 10.60 oz (300.50 g) |
| Miscellaneous | |
| Package Contents | USB Hub 1 x 3.3 ft [1 m] USB-C to USB-C Locking Cable 1 x 3.3 ft [1 m] USB-A to USB-C Locking Cable 1 x Universal Terminal Block Power Adapter 1 x DIN Mounting Kit 1 x Quick Start Guide |
| Application/Usage | Printer,Scanner,Solid State Drive,Enclosure |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the maximum data transfer speed of this USB hub?
This USB hub supports USB 3.2 Gen 2 with a maximum theoretical transfer rate of 10Gbps. In practical applications, it achieves data transfer rates up to 1.25 GB/s (10 Gbps), making it suitable for high-speed storage devices, external SSDs, and RAID arrays that require fast data throughput for efficient operations.
Can this hub be mounted in industrial environments?
Yes, the hub is specifically designed for industrial mounting applications. It includes built-in mounting ears and comes with a DIN mounting kit, allowing installation on surfaces, walls, or standard DIN rails. This makes it ideal for organized deployments in manufacturing facilities, data centers, or commercial settings where space optimization and secure mounting are important considerations.
What type of power supply does this USB hub require?
The hub includes a universal terminal block power adapter that accepts 7-24V DC input. This flexible power input range allows compatibility with various power sources commonly found in industrial and commercial environments. The hub can provide 12W (2.4A) on each port up to a total system draw of 40W, supporting both data transfer and device charging functions.
Is this USB hub compatible with RAID configurations?
Yes, the hub supports RAID configurations and is particularly effective when used with external RAID enclosures. The 10Gbps bandwidth ensures that multiple drives in a RAID array can maintain optimal performance during simultaneous data transfers, making this hub suitable for backup solutions, expanded storage capacity, and data redundancy applications that require reliable high-speed connectivity.
What protection features does this industrial USB hub include?
The hub incorporates comprehensive electrical protection including ESD (electrostatic discharge) protection rated at 15kV air/8kV contact and 350W surge protection. These features safeguard connected equipment from electrostatic discharge and power fluctuations that can occur in industrial environments, ensuring reliable operation and protecting sensitive electronics from potential damage.
What operating systems are supported by this USB hub?
This hub is compatible with Windows, macOS, Linux, and ChromeOS operating systems. It functions as a plug-and-play device without requiring additional drivers or software installation, making it immediately usable across different computing environments. The OS-independent design ensures broad compatibility in mixed-OS deployments commonly found in business and industrial settings.
