Product Features
Technical Overview
This 1000BASE-T SFP transceiver operates at Gigabit Ethernet speeds using the 1000BASE-TX standard over Category 5e or Category 6 copper cabling. The module features a single RJ-45 port that supports auto-negotiation and auto-MDI/MDIX, simplifying deployment in diverse network environments.
Built to exacting specifications, the transceiver maintains signal integrity across the full 100-meter distance while consuming minimal power. The compact SFP form factor fits standard SFP slots in switches and routers, with dimensions optimized for high-density installations.
This section brings together practical product details such as Application/Usage, Total Number of Ports, Connector Type, Interfaces/Ports Details, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This SFP module delivers certified compatibility with HPE networking infrastructure while offering the reliability and support of StarTech.com's lifetime warranty. The transceiver undergoes rigorous testing to ensure interoperability with HPE switches without voiding OEM warranties.
Verified HPE Compatibility
Specifically engineered to match the electrical and mechanical specifications of the HPE 453154-B21 transceiver, ensuring reliable performance in HPE 6120XG, 6120G, Flex Fabric, and BLc 7000 switches.
- Tested in HPE switch environments
- Maintains OEM warranty compliance
- Direct replacement for HPE 453154-B21
Extended Third-Party Support
Beyond HPE equipment, this MSA-compliant module works with switches from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link, and other manufacturers that accept standard uncoded SFP modules.
- MSA compliance ensures broad compatibility
- Works with uncoded SFP slots
- Ideal for multi-vendor environments
Deployment / Use Cases
This copper SFP transceiver is ideal for extending Gigabit Ethernet connectivity in data centers, enterprise networks, and commercial installations where fiber infrastructure isn't available or practical. The RJ-45 interface allows integration with existing copper cabling plants, providing a cost-effective upgrade path to Gigabit speeds.
Common deployment scenarios include connecting switches to servers, uplinking network segments, or providing high-speed access to network-attached storage. The module's compact size makes it suitable for high-density switch configurations where space is at a premium.
Data Center Connectivity
Deploy in top-of-rack switches to connect servers via copper cabling, leveraging existing infrastructure while achieving Gigabit performance without fiber conversion equipment.
Enterprise Network Expansion
Extend network segments across buildings or floors using standard Cat5e/Cat6 cabling, maintaining 1 Gbps speeds up to 100 meters between network devices.
Physical Profile
The transceiver measures 0.60 inches in height and width, with a depth of 2.90 inches, conforming to the standard SFP form factor for universal slot compatibility. Weighing just 0.80 ounces, the module adds minimal load to switch chassis while maintaining robust construction for reliable operation in varied environmental conditions.
- Width
- 0.60" (15.24 mm)
- Depth
- 2.90" (73.66 mm)
- Height
- 0.60" (15.24 mm)
- Weight
- 0.80 oz (22.68 g)
Highlights
- 100% compatible with HPE 453154-B21 SFP transceiver specifications
- 1 Gbps Gigabit Ethernet over RJ-45 copper connections
- Supports distances up to 100 meters on Cat5e/Cat6 cabling
- Hot-swappable design for installation without network downtime
- MSA compliant for broad third-party switch compatibility
- Works with HPE 6120XG, 6120G, Flex Fabric, and BLc 7000 switches
- Also compatible with Ubiquiti, D-Link, Netgear, and other MSA-compliant switches
- Lifetime warranty backed by StarTech.com technical support
- TAA compliant for government and educational procurement
- RoHS, REACH, and WEEE compliant for environmental responsibility
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | 453154B21ST |
| Brand Name | StarTech.com |
| Product Name | HP 453154-B21 Compatible SFP Transceiver Module - 1000BASE-T |
| Product Type | SFP (mini-GBIC) |
| Packaged Quantity | 1 Each |
| Technical Information | |
| Application/Usage | Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | RJ-45 |
| Interfaces/Ports Details | 1 x RJ-45 1000Base-TX LAN |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-TX |
| Physical Characteristics | |
| Form Factor | Hot-pluggable,Hot-swappable |
| Height | 0.60" (15.24 mm) |
| Width | 0.60" (15.24 mm) |
| Depth | 2.90" (73.66 mm) |
| Weight (Approximate) | 0.80 oz (22.68 g) |
| Miscellaneous | |
| Compatibility | Multi-Source Agreement Compliant HP BladeSystem c-Class Product HPE Switches: 6120XG 6120G Flex Fabric BLc 7000 |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What HPE switches is this SFP module compatible with?
This StarTech.com SFP module is specifically designed as a replacement for the HPE 453154-B21 transceiver and is compatible with HPE switches including the 6120XG, 6120G, Flex Fabric, and BLc 7000 series, as well as HP BladeSystem c-Class products. The module undergoes compatibility testing to ensure reliable operation in these HPE networking environments.
What type of network connection does this SFP module provide?
This is a 1000BASE-T copper SFP module that provides Gigabit Ethernet connectivity through an RJ-45 port. It supports data transfer speeds up to 1 Gbps over standard twisted-pair copper cabling (Category 5e or Category 6) with a maximum distance of 100 meters between connected devices.
Can I use this SFP module with non-HPE networking equipment?
Yes, this MSA-compliant SFP module works with various third-party switches that accept standard uncoded SFP modules, including equipment from Ubiquiti, D-Link, Netgear, Supermicro, and TP-Link. The Multi-Source Agreement compliance ensures electrical and mechanical compatibility with a wide range of networking devices beyond the HPE ecosystem.
Is this SFP module hot-swappable?
Yes, this SFP module features a hot-pluggable, hot-swappable design that allows you to install or replace the transceiver without powering down your switch or router. This capability minimizes network downtime during maintenance, upgrades, or module replacement, making it ideal for mission-critical networking environments.
What warranty does this SFP module include?
StarTech.com backs this SFP module with a lifetime warranty that covers the module itself for its operational lifespan. This warranty does not affect your OEM switch warranty, and the module is supported by StarTech.com's technical advisory team available five days a week, 24 hours a day for troubleshooting assistance.
What compliance standards does this SFP module meet?
This SFP module is TAA compliant for government and educational procurement, and meets multiple environmental standards including RoHS (Restriction of Hazardous Substances), REACH (Registration, Evaluation, Authorization and Restriction of Chemicals), and WEEE (Waste Electrical and Electronic Equipment Directive). The module is manufactured in Taiwan with these compliance certifications.
