StarTech.com ST4300USBM 4-Port Industrial USB 3.0 Hub - 5Gbps - Mountable - Rugged - External
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This industrial USB hub operates via a USB 3.0 Type B host interface, supporting SuperSpeed data transfers up to 5GB/s. All four downstream ports are USB 3.0 compliant, ensuring backward compatibility with USB 2.0 and 1.1 devices while maximizing performance for modern peripherals.
Power management includes a 7-24V DC terminal block for wide-range input flexibility and USB Battery Charging Specification 1.2 support, delivering up to 2.4A per port with a 20W total power budget. The hub measures 6" × 2.30" × 0.90" (152.40 × 58.42 × 22.86 mm) for compact deployment.
Relevant factors for this section include Host Interface, Data Transfer Rate. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This hub stands out with industrial-grade construction and protective features that ensure reliable operation in challenging conditions. The combination of mounting flexibility, robust power options, and comprehensive device protection makes it ideal for environments where standard USB hubs would fail.
Enhanced Device Protection
Built-in ESD protection safeguards connected equipment with 8kV air discharge and 4kV contact discharge ratings, preventing damage from electrostatic events common in industrial settings.
Installation Flexibility
Integrated mounting brackets allow secure attachment to walls, panels, or equipment, keeping the hub positioned exactly where needed without requiring additional mounting hardware.
Power Versatility
The terminal block accepts 7-24V DC input, accommodating various power sources, while USB charging support provides up to 2.4A per port for charging compatible devices.
Deployment / Use Cases
The ST4300USBM excels in environments requiring reliable USB expansion with physical durability. Its industrial design and protective features make it suitable for manufacturing floors, laboratory equipment clusters, point-of-sale systems, and control panel installations where USB peripherals need secure, centralized connectivity.
Common applications include connecting multiple USB devices to industrial PCs, expanding USB ports on embedded systems, charging mobile devices in commercial settings, and organizing USB connections in equipment racks or enclosures. The mountable design keeps cables organized and the hub protected from accidental displacement.
Industrial Automation
Connect USB peripherals to PLCs, HMIs, and industrial computers on manufacturing lines with protection against electrical interference.
Commercial Installations
Expand USB connectivity for POS systems, digital signage players, kiosks, and other fixed commercial equipment with secure mounting.
Physical Profile
The hub features a compact black external enclosure measuring 6" in length, 2.30" in width, and 0.90" in height (152.40 × 58.42 × 22.86 mm). Weighing approximately 10.62 oz (301 g), its slim profile and integrated mounting brackets facilitate installation in space-constrained locations. The rugged construction withstands vibration and environmental factors typical in industrial settings.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.90" (22.86 mm), 2.30" (58.42 mm), 10.62 oz (301 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 2.30" (58.42 mm)
- Height
- 0.90" (22.86 mm)
- Weight
- 10.62 oz (301 g)
- Length
- 6" (152.40 mm)
What's in the Box
The package includes all necessary components for immediate deployment:
Highlights
- Adds four USB 3.0 ports from a single USB connection
- 8kV air and 4kV contact ESD protection for connected devices
- Built-in mounting brackets for secure wall or panel installation
- 7-24V DC terminal block for flexible wide-range power input
- USB Battery Charging Specification 1.2 support up to 2.4A per port
- 5Gbps data transfer rate across all ports
- Rugged industrial design for demanding environments
- TAA compliant and RoHS/REACH/WEEE environmental certifications
- Compact dimensions: 6" × 2.30" × 0.90" (152.40 × 58.42 × 22.86 mm)
- Includes universal power adapter and 6-foot USB 3.0 cable
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | ST4300USBM |
| Brand Name | StarTech.com |
| Product Name | 4 Port Industrial USB 3.0 Hub - Mountable - Rugged USB Hub |
| Packaged Quantity | 1 Each |
| Product Type | USB Hub |
| Technical Information | |
| Host Interface | USB 3.0 Type B |
| Media & Performance | |
| Data Transfer Rate | 5 GB/s |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 4 |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | External |
| Height | 0.90" (22.86 mm) |
| Width | 2.30" (58.42 mm) |
| Length | 6" (152.40 mm) |
| Weight (Approximate) | 10.62 oz (301 g) |
| Miscellaneous | |
| Package Contents | 4-Port Industrial USB 3.0 Hub with ESD Protection 6 ft [1.8 m] USB 3.0 Cable (non-locking) Universal Power Adapter (NA/JP, EU, UK, ANZ) Instruction Manual Terminal Block (2 Wire) |
| Platform Supported | PC |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the data transfer speed of this USB hub?
The StarTech.com ST4300USBM supports USB 3.0 SuperSpeed data transfer rates up to 5 gigabits per second (5Gbps). All four ports operate at this maximum speed when connected to a USB 3.0 host, providing fast data transfers for storage devices, cameras, and other high-speed peripherals while maintaining backward compatibility with USB 2.0 and 1.1 devices.
Can this hub be mounted on a wall or panel?
Yes, the hub includes integrated mounting brackets designed for secure installation on walls, equipment panels, or racks. This mountable design allows permanent placement in industrial, commercial, or organized workspace environments without requiring additional mounting hardware, keeping the hub positioned exactly where needed for cable management and protection.
What type of power input does the hub require?
The hub accepts 7-24V DC input through its included terminal block, providing wide-range power flexibility. This allows compatibility with various power sources commonly available in industrial and commercial settings. The package includes a universal power adapter supporting NA/JP, EU, UK, and ANZ plug configurations for immediate use.
Does this hub provide charging capability for devices?
Yes, the hub supports USB Battery Charging Specification 1.2, delivering up to 2.4 amps per port for charging smartphones, tablets, and other USB-charged devices. The total power budget is 20 watts distributed across the four ports, allowing simultaneous charging of multiple devices while maintaining data connectivity.
What protection features does this industrial USB hub include?
The hub incorporates 8kV air discharge and 4kV contact discharge ESD (electrostatic discharge) protection to safeguard connected devices from static electricity events. This industrial-grade protection is essential in environments where electrostatic buildup could damage sensitive electronics, making the hub suitable for manufacturing, laboratory, and other electrically challenging settings.
What cables and accessories are included with the hub?
The package contains a 6-foot (1.8-meter) USB 3.0 cable for host connection, a universal power adapter with multiple plug types (NA/JP, EU, UK, ANZ), a two-wire terminal block for alternative power input, and an instruction manual. The hub itself includes built-in mounting brackets, requiring no additional hardware for wall or panel installation.
