StarTech. com CDP2VGAW USB-C to VGA Adapter - White - Thunderbolt 3 Compatible - 1080p/1920 x 1200 Video Converter - Reversible USB 3. 1 Type-C
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This video adapter performs a digital-to-analog conversion, taking the digital video signal from a USB-C or Thunderbolt 3 source and outputting it as an analog VGA signal. It utilizes a USB 3.1 Type C male connector (24-pin) on the host end and provides a standard HD-15 female VGA port (15-pin) for display connectivity.
The adapter is designed to work seamlessly with devices that support DisplayPort Alt Mode over USB-C, which includes most modern laptops, tablets, and smartphones. Its compatibility with Thunderbolt 3 ports expands its utility across a wider range of high-performance workstations and ultrabooks.
This section brings together practical product details such as Adapter Type, Connector Type on First End, Connector on First End Details, Color Family, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The CDP2VGAW adapter prioritizes user convenience and reliable performance in a universal connectivity tool. Its design eliminates common pain points associated with adapter use in dynamic office and remote work environments.
Universal Compatibility
Connects USB-C and Thunderbolt 3 laptops, tablets, and phones to thousands of existing VGA monitors, projectors, and large displays in offices, schools, and homes.
- Works with MacBook Pro, Dell XPS, Surface Pro, and more
- Thunderbolt 3 port compatible for broader device support
User-Friendly Design
The reversible USB-C connector allows insertion in either orientation, saving time and reducing wear on device ports. The compact, lightweight form factor is easy to carry in a laptop bag or pocket.
- Reversible connector for hassle-free connection
- Lightweight at 0.80 oz for maximum portability
Clear Video Output
Delivers high-definition video quality up to 1920x1200 resolution, ensuring presentations, spreadsheets, and multimedia content appear sharp and legible on the connected display.
- Crystal-clear picture quality at 1080p
- Supports common business and presentation resolutions
Deployment / Use Cases
This adapter is deployed anywhere a quick, reliable connection between a modern computer and a VGA display is needed. It serves as an essential tool for maintaining productivity and presentation capabilities in mixed-technology environments.
In corporate and educational settings, it enables users to connect their laptops to older projectors in meeting rooms or lecture halls. For remote workers and digital nomads, it provides a lightweight way to extend their desktop to a secondary monitor at a co-working space or home office. IT departments value it as a standard-issue adapter for supporting a diverse fleet of employee devices without requiring monitor upgrades.
Business Presentations
Connect a USB-C laptop to a conference room projector for delivering slideshows, reports, and video conferences without compatibility issues.
Desktop Extension
Add a second VGA monitor to a USB-C laptop to expand screen real estate for multitasking with applications like spreadsheets, coding IDEs, or design software.
Physical Profile
The adapter features a clean white finish that matches modern computer aesthetics. Its minimalistic design has a small footprint, with no bulky casing or cables integrated, making it one of the most portable VGA solutions available. Weighing only 0.80 ounces, it adds negligible weight to a travel kit. The construction complies with EU RoHS, REACH, and WEEE environmental standards, reflecting responsible manufacturing practices.
- Weight
- 0.80 oz (22.68 g)
Highlights
- Converts USB-C or Thunderbolt 3 to VGA for monitors and projectors
- Supports high-definition video up to 1920x1200 or 1080p resolution
- Reversible USB-C connector for easy, frustration-free plug-in
- Lightweight and compact design for maximum portability (0.80 oz)
- Thunderbolt 3 port compatible for use with high-performance laptops
- Plug-and-play operation requires no drivers or external power
- White color matches modern computer and peripheral aesthetics
- Backed by a 3-year limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | CDP2VGAW |
| Brand Name | StarTech.com |
| Product Name | USB-C to VGA adapter - USB Type-C to VGA Video Converter - White |
| Packaged Quantity | 1 Each |
| Product Type | Video Adapter |
| Technical Information | |
| Adapter Type | USB-C/VGA |
| Connector Type on First End | HD-15 - Female |
| Connector on First End Details | 1 x 15-pin HD-15 - Female |
| Connector Type on Second End | USB 3.1 Type C - Male |
| Connector on Second End Details | 1 x 24-pin USB 3.1 Type C - Male |
| Features | Reversible |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Weight (Approximate) | 0.80 oz (22.68 g) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What devices are compatible with this USB-C to VGA adapter?
The adapter is compatible with laptops, tablets, and smartphones that have a USB-C port supporting DisplayPort Alt Mode. This includes most modern devices from Apple (MacBook Pro, MacBook Air), Dell (XPS, Latitude), Lenovo (ThinkPad, Yoga), Microsoft (Surface Pro, Surface Laptop), and many others. It also works with Thunderbolt 3 ports, which are common on high-performance workstations and ultrabooks.
Does the adapter require external power or software drivers?
No, the adapter is plug-and-play and does not require external power or the installation of software drivers. It draws minimal power directly from the host device's USB-C port. Simply connect it between your USB-C device and the VGA display; the video signal should be detected automatically by most operating systems.
What does 'reversible USB-C connector' mean?
The USB-C connector on the adapter can be inserted into your device's port in either orientation—right-side up or upside down. This eliminates the frustration of trying to plug it in the correct way, saving time and reducing physical wear on both the adapter and your device's port from repeated incorrect insertion attempts.
Can I use this adapter with a Thunderbolt 3 port?
Yes, the adapter is fully compatible with Thunderbolt 3 ports. Since Thunderbolt 3 uses the USB-C physical connector and supports DisplayPort video signals, this adapter will function correctly when plugged into a Thunderbolt 3 port on laptops like certain MacBook Pro models, Dell Precision workstations, or Lenovo ThinkPad X1 devices.
What is included in the warranty and environmental compliance?
The adapter is backed by a 3-year limited warranty from StarTech.com, covering defects in materials and workmanship. It is also environmentally compliant, meeting EU RoHS (Restriction of Hazardous Substances), REACH, and WEEE (Waste Electrical and Electronic Equipment) directives, ensuring it is manufactured with reduced hazardous materials and designed for responsible disposal.
What refresh rate or brightness details are available?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
What input or connectivity options are listed?
Connectivity options include HD-15 - Female, helping the product integrate into common office or home setups.
Does the display support VESA mounting or adjustment features?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
