Tapo TAPO C530WS 5MP Outdoor 3K Color Dome Network Camera with Night Vision - 2880 x 1620 - 3. 2mm Lens - Wi-Fi & Ethernet - IP66
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At its core, the C530WS utilizes a 1/3-inch CMOS image sensor paired with a fixed 3.2mm lens, offering a wide 112-degree diagonal field of view for comprehensive coverage. Video is encoded efficiently in H.264 format, balancing high quality with manageable bandwidth and storage requirements. The camera includes a built-in microphone and speaker for two-way audio, enabling live communication and audio monitoring through the connected app or software.
For storage flexibility, it supports local recording via microSD card, allowing for on-device backup without mandatory cloud subscriptions. Network management is streamlined through ONVIF and RTSP protocol support, ensuring compatibility with a wide range of video management systems and third-party NVRs. Power is supplied via a versatile AC/DC input, accommodating standard electrical outlets or PoE adapters for simplified cabling in professional setups.
Key Product Advantages
The Tapo C530WS stands out with its combination of high-resolution imaging, intelligent features, and rugged design tailored for demanding outdoor environments. Its AI-enhanced detection accurately distinguishes between humans, vehicles, and other objects, sending precise alerts and reducing notification fatigue. The color night vision extends usable surveillance into darkness, capturing identifiable details that traditional infrared cameras might miss.
Weatherproof Durability
With an IP66 rating, the dome housing resists water, dust, and extreme temperatures from -22°F to 140°F, ensuring year-round operation in challenging climates.
- Waterproof and dustproof construction
- Heat and rain resistant
- Suitable for outdoor installations
Flexible Connectivity
Dual Wi-Fi and Ethernet options provide installation versatility, while support for ONVIF and RTSP protocols allows seamless integration into existing security ecosystems.
- Wi-Fi for wireless setups
- Ethernet for stable wired connections
- Broad VMS compatibility
Deployment / Use Cases
This camera is ideal for commercial and residential security applications where clear, actionable footage is critical. Its outdoor-rated build and wide field of view make it perfect for monitoring entry points, driveways, retail storefronts, and warehouse perimeters. The AI detection features are particularly valuable for properties requiring specific alerting for human activity or vehicle traffic, enhancing security response efficiency.
For small business owners, the C530WS offers a cost-effective surveillance solution with local storage support, avoiding recurring cloud fees. Home users benefit from easy Wi-Fi setup and integration with virtual assistants like Alexa and Google Assistant for voice-controlled viewing. In educational or institutional settings, the camera's two-way audio enables remote communication, while its durable design handles high-traffic outdoor areas like campuses or parking garages.
Retail & Commercial Security
Monitor storefronts, loading docks, and parking areas with high-resolution video and AI-powered alerts for theft prevention and liability protection.
Residential Property Monitoring
Secure home perimeters, driveways, and backyard spaces with color night vision and easy remote access via smartphone apps.
Physical Profile
The dome-shaped housing measures 4.90" wide by 4.80" deep by 3.50" high, presenting a low-profile aesthetic that blends into architectural environments. Its compact dimensions facilitate discreet installation on walls, ceilings, or poles using the included mounting hardware. The matte finish resists glare and weathering, maintaining a professional appearance over time while the robust construction deters tampering and environmental damage.
- Width
- 4.90" (124.46 mm)
- Depth
- 4.80" (121.92 mm)
- Height
- 3.50" (88.90 mm)
- Length
- 3.2 mm (0.13")
Highlights
- 5-megapixel resolution delivers detailed 2880 x 1620 3K video for clear surveillance footage.
- Color night vision illuminates scenes up to 98 feet, providing identifiable details in low light.
- AI-powered detection distinguishes people, vehicles, and other objects with reduced false alarms.
- IP66-rated weatherproof dome housing withstands rain, dust, and extreme temperatures.
- Dual Wi-Fi and Ethernet connectivity offers flexible installation and reliable network performance.
- Supports local storage via microSD card for on-device recording without cloud subscriptions.
- Wide 112-degree diagonal field of view covers expansive areas with a single camera.
- Two-way audio with built-in microphone and speaker enables live communication.
- ONVIF and RTSP protocol support ensures compatibility with most VMS and NVR systems.
- Works with Alexa, Google Home, and Google Assistant for voice-controlled viewing.
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | TAPO C530WS |
| Brand Name | Tapo |
| Product Model | C530WS |
| Product Name | C530WS Outdoor Pan/Tilt Security Wi-Fi Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | 3K |
| Night Vision | Yes |
| Night Vision Distance | 98 ft (29.87 m) |
| Night Vision Type | Color |
| Virtual Assistant Supported | Alexa,Google Home,Google Assistant |
| AI-powered | Yes |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/3" |
| Color Supported | Color |
| Field of View | 112° (Diagonal), 95°(Horizontal), 53°(Vertical) |
| Effective Camera Resolution | 5 Megapixel |
| Video | |
| Video Formats | H.264 |
| Maximum Video Resolution | 2880 x 1620 |
| Maximum Frame Rate | 30 fps |
| Audio | |
| Audio Support | Yes |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 3.2 mm (0.13") |
| Lens Included | Yes |
| Maximum Aperture | f/1.6 |
| Network & Communication | |
| Connectivity Technology | Wired & Wireless |
| Remote Management | Yes |
| Wireless Technology | Wi-Fi |
| Ethernet Technology | Ethernet |
| Protocols | ONVIF,RTSP |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 100 V AC,240 V AC,9 V DC |
| Power Source Type | AC,DC |
| Physical Characteristics | |
| Mount Type | Wall Mount,Ceiling Mount,Pole Mount |
| Form Factor | Dome |
| Durability | Weather Proof,Water Proof,Dust Proof,Weather Resistant,Heat Resistant,Rain Resistant |
| Height | 3.50" (88.90 mm) |
| Width | 4.90" (124.46 mm) |
| Depth | 4.80" (121.92 mm) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 140°F (60°C) |
| Minimum Operating Humidity (Non-condensing) | 10% |
| Maximum Operating Humidity (Non-condensing) | 90% |
| Minimum Storage Humidity (Non-condensing) | 0% |
| Maximum Storage Humidity (Non-condensing) | 90% |
| Miscellaneous | |
| Features | Vehicle Detection,Motion Detection,Cross Line Detection,Motion Tracking,Built-in Microphone,Built-in Speaker,Human Detection,Wide Dynamic Range,Noise Reduction,3D Noise Reduction,SD Card Local Storage |
| Indoor/Outdoor | Outdoor |
| Ingress Protection Rating | IP66 |
User Manual
FAQ
What is the maximum video resolution of the Tapo C530WS camera?
The Tapo C530WS captures video at a maximum resolution of 2880 x 1620, which is considered 3K. This high resolution provides detailed imagery suitable for identifying faces, license plates, and other critical details in surveillance footage, recorded at a smooth 30 frames per second for realistic motion representation.
How far does the night vision reach, and is it in color?
This camera features color night vision with an effective range of up to 98 feet (29.87 meters). Unlike traditional infrared night vision that produces monochrome images, the color capability allows for better identification of objects and scenes in low-light conditions, enhancing security monitoring during nighttime hours.
Can this camera be used outdoors in all weather conditions?
Yes, the Tapo C530WS is designed for outdoor use with an IP66 ingress protection rating. This means it is fully dust-tight and protected against powerful water jets, making it resistant to rain, snow, dust, and other environmental factors. It operates reliably in temperatures from -22°F to 140°F (-30°C to 60°C).
What connectivity options does the camera support?
The camera offers both wired and wireless connectivity. It includes Wi-Fi for flexible placement without Ethernet cabling, plus an RJ-45 Ethernet port for a stable, high-bandwidth wired connection. This dual approach allows installation in locations where running cables is impractical while ensuring reliable performance where wired networks are preferred.
Does the Tapo C530WS support local storage, and what AI features does it include?
Yes, it supports local storage via a microSD card, allowing video to be recorded directly onto the camera without requiring cloud services. AI features include human detection, vehicle detection, motion tracking, and cross-line detection, which intelligently analyze video to send relevant alerts and reduce false notifications from non-essential movement.
What mounting options are available for this dome camera?
The Tapo C530WS can be mounted on walls, ceilings, or poles using the included hardware. Its dome form factor and compact dimensions make it suitable for discreet installation in various outdoor and indoor settings. The versatile mounting supports adjustable angles to achieve the optimal viewing coverage for your specific surveillance needs.
What storage is included?
The system includes Memory Card of storage for applications, files, and everyday business data.
