Thermaltake View 380 TG ARGB Snow Mid Tower Chassis Tempered Glass For Mini ITX Micro ATX And Motherboards CA-1Z2-00M6WN-00
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Motherboard Supported: Mini ITX,Micro ATX,ATX
Number of Fans Supported: 10
Number of Fans Installed: 4
Fan Size Supported: 4.72" (120 mm)
Installed Fan Size: 4.72" (120 mm)
Features: Cable Management,Dual Chamber
Number of Internal 3.5" Bays: 1
Number of Internal 2.5" Bays: 2
Total Number of Expansion Slots: 7
Total Number of USB Ports: 3
USB Port Details: 1 x USB 3.2 (Gen 2) Type C,2 x USB 3.0
Total Number of Audio In Ports: 1
Total Number of Audio Out Ports: 1
Microphone: Yes
Color Family: White
Product Color: Snow
Product Material: SPCC,Tempered Glass
Cooler Type: Fan Cooler
Form Factor: Mid-tower
Maximum CPU Cooler Height: 6.30" (160 mm)
Maximum PSU Length: 7.87" (200 mm)
Maximum GPU Length: 16.34" (415 mm)
Height: 16.14" (410 mm)
Width: 11.22" (285 mm)
Depth: 17.40" (442 mm)
Weight (Approximate): 6.93 kg
Limited Warranty: 3 Year
- Supports ATX motherboards to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
- For a better airflow, mid-tower structure supports up to 10 fan(s) with ample space to store hardware
[custom-specifications]
| Specifications | |
| Manufacturer | Thermaltake Technology Co., Ltd |
| Manufacturer Part Number | CA-1Z2-00M6WN-00 |
| Manufacturer Website Address | http://www.thermaltake.com |
| Brand Name | Thermaltake |
| Product Line | View |
| Product Model | 380 TG ARGB Snow |
| Product Name | View 380 TG ARGB Snow Mid Tower Chassis |
| Product Type | Computer Case |
| Technical Information | |
| Motherboard Supported | Mini ITX,Micro ATX,ATX |
| Number of Fans Supported | 10 |
| Number of Fans Installed | 4 |
| Fan Size Supported | 4.72" (120 mm) |
| Installed Fan Size | 4.72" (120 mm) |
| Features | Cable Management,Dual Chamber |
| Bays | |
| Number of Internal 3.5" Bays | 1 |
| Number of Internal 2.5" Bays | 2 |
| I/O Expansions | |
| Total Number of Expansion Slots | 7 |
| Interfaces/Ports | |
| Total Number of USB Ports | 3 |
| USB Port Details | 1 x USB 3.2 (Gen 2) Type C,2 x USB 3.0 |
| Total Number of Audio In Ports | 1 |
| Total Number of Audio Out Ports | 1 |
| Microphone | Yes |
| Physical Characteristics | |
| Color Family | White |
| Product Color | Snow |
| Product Material | SPCC,Tempered Glass |
| Cooler Type | Fan Cooler |
| Form Factor | Mid-tower |
| Maximum CPU Cooler Height | 6.30" (160 mm) |
| Maximum PSU Length | 7.87" (200 mm) |
| Maximum GPU Length | 16.34" (415 mm) |
| Height | 16.14" (410 mm) |
| Width | 11.22" (285 mm) |
| Depth | 17.40" (442 mm) |
| Weight (Approximate) | 6.93 kg |
| Warranty | |
| Limited Warranty | 3 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
[/custom-user-manual]
