TP-LINK INSIGHT S485(2. 8MM) InSight S485 8MP 4K Turret Network Camera - Color - 98. 43 ft Infrared/Color Night Vision - H. 265+ - 2. 8mm Lens - IP67
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera captures 4K Ultra HD video at 3840 x 2160 resolution with a maximum frame rate of 25 fps, ensuring detailed surveillance footage suitable for identification and evidence purposes. The 1/2.7" CMOS image sensor delivers clear images with accurate color reproduction, while the f/1.6 maximum aperture provides strong low-light performance.
Advanced imaging features include 3D digital noise reduction, wide dynamic range, and automatic white balance to optimize video quality across varying lighting conditions. The camera supports multiple network protocols including TCP/IP, HTTP/HTTPS, RTSP, and IPv4/IPv6 for seamless integration into existing security infrastructures.
Relevant factors for this section include HD Recording, Recording Formats, Night Vision, Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The InSight S485 distinguishes itself with intelligent analytics capabilities that enhance security monitoring efficiency. The camera features people and vehicle detection with classification, allowing for targeted alerts and reduced false alarms. Smart video enhancement technology automatically adjusts settings to deliver optimal image quality in real-time.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Advanced Analytics, Enhanced Surveillance Features.
Advanced Analytics
Human and vehicle classification enables precise event detection and filtering, while alarm triggering provides immediate notification of security events.
- People Detection
- Vehicle Detection
- Smart Classification
Enhanced Surveillance Features
Active defense capabilities include two-way audio communication and built-in microphone for interactive security applications.
- Two-Way Audio
- Built-in Microphone
- Day/Night Operation
Deployment / Use Cases
The turret form factor and versatile mounting options make this camera suitable for a wide range of surveillance applications. The discreet design blends well with architectural elements while providing comprehensive monitoring coverage.
Ideal for retail environments, the S485 supports people counting and loitering detection to enhance loss prevention efforts. For residential security, the camera's 24-hour full-color capability with infrared/color night vision ensures continuous monitoring regardless of lighting conditions.
Commercial Security
Deploy in retail stores, office buildings, and warehouses for perimeter protection, entrance monitoring, and inventory security with detailed 4K footage for identification purposes.
Residential Protection
Install around homes and apartment complexes to monitor driveways, yards, and entry points with reliable performance in all weather conditions thanks to the IP67 rating.
Physical Profile
The camera features a compact turret design measuring 4.40" x 4.40" x 3.30" (111.76 mm x 111.76 mm x 83.82 mm) with a weight of approximately 1.06 lb (480 g). The metal construction provides durability while the IP67 rating ensures protection against dust ingress and temporary immersion in water up to 1 meter for 30 minutes.
- Width
- 4.40" (111.76 mm)
- Height
- 3.30" (83.82 mm)
- Weight
- 1.06 lb (480 g)
- Length
- 2.8 mm (0.11")
What's in the Box
The camera ships with all necessary components for immediate installation and operation.
Highlights
- 8MP 4K Ultra HD resolution for detailed surveillance footage
- 98.43 ft (30 m) infrared/color night vision for 24-hour monitoring
- H.265+ compression technology reduces bandwidth and storage requirements
- People and vehicle detection with smart classification
- IP67 weatherproof rating for reliable outdoor operation
- 12V DC or PoE power options for flexible installation
- Wide 134° diagonal field of view for comprehensive coverage
- Two-way audio with built-in microphone for interactive security
- Metal construction with ceiling and wall mounting options
- Supports memory card storage for local recording
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | INSIGHT S485(2.8MM) |
| Brand Name | TP-Link |
| Product Line | InSight |
| Product Model | InSight S485 |
| Product Name | VIGI 4MP Full-Color Turret Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | 4K |
| Night Vision | Yes |
| Night Vision Distance | 98.43 ft (30 m) |
| Night Vision Type | Infrared/Color |
| Number of IR LEDs | 4 |
| Infrared (IR) Cut-off Filter | Yes |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.7" |
| Color Supported | Color |
| Field of View | Horizontal FOV: 111.4°, Vertical FOV: 58.8°, Diagonal FOV: 134° |
| Effective Camera Resolution | 8 Megapixel |
| Video | |
| Video Formats | H.265+,H.265,H.264,H.264+,H.264H,H.265M |
| Maximum Video Resolution | 3840 x 2160 |
| Maximum Frame Rate | 25 fps |
| Audio | |
| Audio Support | Yes |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 2.8 mm (0.11") |
| Lens Included | Yes |
| Lens Mount Type | M12-mount |
| Maximum Aperture | f/1.6 |
| Exposure | |
| Shortest Shutter Speed | 1/10000 Second |
| Longest Shutter Speed | 1/3 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | TCP/IP,UDP,ICMP,HTTP,HTTPS,DHCP,DNS,RTSP,NTP,UPnP,SSL/TLS,FTP,SFTP,RTP,IPv4,IPv6,ARP |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 12.50 W |
| Input Voltage | 12 V DC |
| Power Source Type | DC,PoE |
| Physical Characteristics | |
| Product Material | Metal |
| Mount Type | Ceiling Mount,Wall Mount |
| Form Factor | Turret |
| Durability | Water Proof,Weather Proof |
| Height | 3.30" (83.82 mm) |
| Width | 4.40" (111.76 mm) |
| Length | 4.40" (111.76 mm) |
| Diameter | 4.37" (111 mm) |
| Weight (Approximate) | 1.06 lb (480 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 140°F (60°C) |
| Maximum Operating Humidity (Non-condensing) | 95% |
| Maximum Storage Humidity (Non-condensing) | 95% |
| Miscellaneous | |
| Features | Alarm Triggering,Vehicle Detection,Human Detection,Wide Dynamic Range,3D Digital Noise Reduction,Noise Reduction,White Balance,Built-in Microphone,Day/Night,Mirror |
| Package Contents | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
| Ingress Protection Rating | IP67 |
User Manual
FAQ
What is the maximum resolution of the TP-Link InSight S485 camera?
The TP-Link InSight S485 captures 8-megapixel 4K Ultra HD video at 3840 x 2160 resolution with a maximum frame rate of 25 frames per second. This high resolution provides exceptional detail for identification purposes and evidence-quality footage in surveillance applications.
How far does the night vision reach on this camera?
The camera features infrared/color night vision with an effective distance of 98.43 feet (30 meters). This extended range, combined with four IR LEDs and an infrared cut-off filter, ensures clear monitoring in low-light conditions while maintaining color information when possible.
What power options are available for the InSight S485?
The camera supports both 12V DC power and Power over Ethernet (PoE) connectivity. This dual power capability provides installation flexibility, allowing you to choose the most convenient power source based on your infrastructure. Maximum power consumption is 12.50 watts.
Is this camera suitable for outdoor installation?
Yes, the InSight S485 features an IP67 ingress protection rating, making it waterproof and weatherproof for reliable outdoor operation. The camera can withstand temporary immersion in water and operates in temperatures ranging from -22°F to 140°F (-30°C to 60°C).
What video compression formats does this camera support?
The camera supports H.265+, H.265, H.264, H.264+, H.264H, and H.265M compression formats. H.265+ technology provides superior compression efficiency, reducing bandwidth and storage requirements by up to 50% compared to standard H.264 while maintaining high video quality.
What mounting options are available for this turret camera?
The InSight S485 supports both ceiling and wall mounting with included mounting accessories. The turret form factor provides a discreet profile that blends with architectural elements while offering a 134° diagonal field of view for comprehensive surveillance coverage.
