TP-LINK S4500-16G2F Omada Pro 16-Port Gigabit Smart Managed Switch with 2 SFP Slots - Fanless - Layer 2 - Wall Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates as a Layer 2 managed device, supporting key networking standards including IEEE 802.1Q for VLANs, IEEE 802.1x for port-based authentication, and IEEE 802.3x for flow control. The 16 Gigabit Ethernet ports auto-negotiate speeds of 10/100/1000 Mbps, while the two SFP slots accommodate Gigabit SFP modules for fiber optic connections, extending network reach up to 10 kilometers depending on the module used.
Power efficiency is highlighted by a typical consumption of 12.30 watts, and the switch accepts dual voltage input (120-230 V AC) for global compatibility. The fanless design eliminates moving parts, reducing maintenance needs and ensuring quiet operation in noise-sensitive environments.
Relevant factors for this section include Features, Total Number of Network Ports, Network (RJ-45), Modular. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The S4500-16G2F stands out with its balanced mix of port density, management features, and deployment flexibility. Its smart managed capabilities provide granular control over network traffic, enhancing security and performance without the complexity of fully managed switches.
High-Density Connectivity
Sixteen Gigabit ports handle multiple devices simultaneously, ideal for connecting workstations, printers, IP cameras, and access points in a consolidated footprint.
- 16x 10/100/1000Base-T ports
- 2x SFP slots for fiber uplinks
- Supports twisted pair and optical fiber
Advanced Management
Layer 2 features include IGMP snooping for multicast optimization, port mirroring for traffic analysis, and spanning tree protocol for loop prevention.
- VLAN support (IEEE 802.1Q)
- Port-based authentication (IEEE 802.1x)
- Quality of Service (QoS) prioritization
Quiet and Efficient Operation
Fanless design ensures silent performance, while low power consumption reduces operational costs and heat output in enclosed spaces.
- 12.30 W typical power draw
- Dual voltage input (120/230 V AC)
- Wall or desktop mounting options
Deployment / Use Cases
This switch is well-suited for scenarios requiring reliable wired connectivity with basic management features. Its 16-port layout accommodates growing networks, while the SFP slots offer future-proofing for fiber backbone connections.
Common applications include small office networks where devices like computers, VoIP phones, and surveillance cameras need segregated traffic via VLANs. It also serves as an aggregation switch in retail environments, connecting point-of-sale systems and inventory management terminals with uplinks to a core router.
Relevant factors for this section include Features, Total Number of Network Ports, Network (RJ-45), Modular. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Office Network Expansion
Deploy in office suites to connect employee workstations, network printers, and conference room equipment, using VLANs to separate departmental traffic.
IP Surveillance Backbone
Use as a central switch for IP camera systems, leveraging port mirroring for monitoring and QoS to prioritize video streams.
Physical Profile
The switch measures 17.30" wide, 7.10" deep, and 1.70" high (439.42 x 180.34 x 43.18 mm), fitting standard 19-inch rack shelves with optional brackets. Its slim profile and wall-mount capability allow installation in telecom closets, under desks, or on vertical surfaces, keeping cables organized and out of sight. The desktop form factor also supports standalone placement on shelves or counters.
- Width
- 17.30" (439.42 mm)
- Depth
- 7.10" (180.34 mm)
- Height
- 1.70" (43.18 mm)
Highlights
- 16 Gigabit Ethernet ports for high-density device connections
- 2 SFP slots support fiber optic uplinks for extended reach
- Layer 2 managed with VLAN, QoS, and security features
- Fanless design ensures silent and maintenance-free operation
- Wall mountable and desktop form factors for flexible installation
- Low power consumption at 12.30 W for energy efficiency
- Supports twisted pair and optical fiber media types
- Dual voltage input (120/230 V AC) for global compatibility
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | S450016G2F |
| Brand Name | TP-Link |
| Product Line | Omada Pro |
| Product Model | S4500-16G2F |
| Product Name | Omada Pro 16-Port Gigabit Smart Switch with 2 SFP Slots |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Fanless |
| Interfaces/Ports | |
| Total Number of Network Ports | 16 |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 16 x Gigabit Ethernet Network,2 × Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 2.0 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1p,IEEE 802.3x,IEEE 802.1ab,IEEE 802.1Q,IEEE 802.1x |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply,AC |
| Power Consumption | 12.30 W |
| Physical Characteristics | |
| Form Factor | Wall Mountable,Desktop |
| Height | 1.70" (43.18 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 7.10" (180.34 mm) |
User Manual
FAQ
How many devices can I connect to this switch?
The TP-LINK S4500-16G2F provides 16 Gigabit Ethernet ports, allowing direct connections for up to 16 wired devices such as computers, printers, or IP cameras. Additionally, the two SFP slots can be used for uplinks to other switches or routers, expanding network capacity beyond the base port count.
What are the SFP slots used for?
The two SFP (Small Form-factor Pluggable) slots support Gigabit SFP modules, enabling fiber optic connections for uplinks. This allows you to extend network distances up to 10 kilometers with single-mode fiber or use multi-mode fiber for shorter runs, providing flexibility for backbone or long-distance links in your network infrastructure.
Is this switch fanless, and why does that matter?
Yes, this switch features a fanless design. This eliminates noise from cooling fans, making it suitable for quiet environments like offices or libraries. It also reduces mechanical failure points, enhancing reliability and lowering maintenance needs over time, which is beneficial for always-on network deployments.
Can I mount this switch on a wall?
Absolutely. The switch supports wall mounting, allowing you to install it vertically to save desk or rack space and keep cables organized. It also includes a desktop form factor for placement on flat surfaces, providing versatile installation options to fit your specific network layout and physical constraints.
What Layer 2 features does this switch support?
This smart managed switch supports essential Layer 2 features including IEEE 802.1Q for VLAN segmentation, IEEE 802.1x for port-based network access control, IGMP snooping for efficient multicast traffic handling, port mirroring for monitoring, and spanning tree protocol to prevent network loops. These features enhance security, performance, and manageability in business networks.
What is the power consumption of this switch?
The typical power consumption is 12.30 watts, which is relatively low for a 16-port managed switch. This efficiency helps reduce electricity costs and heat output, making it suitable for energy-conscious deployments. The switch also accepts 120 V AC or 230 V AC input, supporting standard power outlets in North America and many international regions.
