TP-LINK S4500-16GP Omada Pro 16-Port Gigabit Smart Switch - 8 PoE+ Ports - 120W Budget - Layer 2 Managed - Fanless
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates as a Layer 2 managed device, supporting essential networking standards including IEEE 802.3at and 802.3af for PoE, IEEE 802.1Q for VLANs, IEEE 802.1x for port-based authentication, and IEEE 802.3x for flow control. It uses twisted pair cabling for data transfer up to 100 meters, ensuring compatibility with standard Ethernet infrastructure.
The 8 PoE+ ports deliver up to 30W per port, sufficient for high-power devices, while the total PoE budget of 120W allows flexible power allocation across connected equipment. With a power consumption of 146.50W and a power adapter source, the switch balances energy efficiency with robust performance for continuous operation.
Relevant factors for this section include Features, Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The S4500-16GP offers distinct advantages for businesses seeking a scalable and manageable network solution. Its combination of PoE+ support and smart features reduces cabling complexity and enhances network control.
PoE+ Flexibility
Eight PoE+ ports provide power to connected devices, eliminating the need for separate power adapters and simplifying installation for VoIP systems, wireless access points, and surveillance cameras.
- 30W per PoE+ port
- 120W total budget
- IEEE 802.3at/af compliant
Management Capabilities
As a smart managed switch, it supports features like IGMP snooping for multicast traffic optimization, port mirroring for network analysis, and spanning tree protocol for loop prevention, giving administrators granular control over network performance and security.
Silent Operation
The fanless design ensures noiseless performance, making it ideal for environments where quiet operation is essential, such as offices, classrooms, or healthcare facilities.
Deployment / Use Cases
This switch is well-suited for deployments where a balance of PoE power and management features is required. Its 16-port configuration and 120W PoE budget make it a practical choice for expanding network capacity while powering essential devices.
Common use cases include small office networks where it can connect computers, printers, and IP phones; retail environments supporting POS systems and security cameras; and educational settings linking classrooms with powered devices like projectors or access points. The wall-mountable option allows for tidy cable management in space-constrained areas, while desktop placement offers flexibility for temporary setups or testing environments.
Small Business Networks
Ideal for offices needing to connect multiple devices with PoE support, reducing clutter and improving reliability for daily operations.
Surveillance Systems
Power IP cameras and network video recorders directly through PoE ports, simplifying installation and maintenance for security setups.
Physical Profile
The switch features a compact design with dimensions of 11.30" wide, 4.40" deep, and 1" high, allowing it to fit easily on a desktop or mount on a wall. Its low-profile height of 1" (25.40 mm) makes it suitable for installation in tight spaces or on wall brackets, while the desktop form factor provides stability for standalone use. The build supports efficient heat dissipation without fans, contributing to its durable and maintenance-free operation in various environments.
- Width
- 11.30" (287.02 mm)
- Depth
- 4.40" (111.76 mm)
- Height
- 1" (25.40 mm)
Highlights
- 16 Gigabit Ethernet ports with 8 PoE+ ports for device powering
- 120W total PoE budget supporting high-power devices like access points and cameras
- Layer 2 smart managed switch with VLAN, QoS, and security features
- Fanless design for silent operation in office or classroom settings
- Wall mountable or desktop placement for flexible installation
- Supports twisted pair cabling up to 100 meters for standard Ethernet networks
- IEEE 802.3at/af compliant for PoE device compatibility
- Compact size: 11.30" x 4.40" x 1" for space-efficient deployment
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | S4500-16GP |
| Brand Name | TP-Link |
| Product Line | Omada Pro |
| Product Model | S4500-16GP |
| Product Name | Omada Pro 16-Port Gigabit Smart Switch with 8-Port PoE+ |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Fanless |
| Interfaces/Ports | |
| Total Number of Network Ports | 16 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+,8 × Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3at,IEEE 802.3af,IEEE 802.1p,IEEE 802.3x,IEEE 802.1ab,IEEE 802.1Q,IEEE 802.1x |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 120 W |
| Power Source | Power Adapter |
| Power Consumption | 146.50 W |
| Physical Characteristics | |
| Form Factor | Wall Mountable,Desktop |
| Height | 1" (25.40 mm) |
| Width | 11.30" (287.02 mm) |
| Depth | 4.40" (111.76 mm) |
User Manual
FAQ
How many PoE+ ports does this switch have, and what is the total PoE budget?
The TP-LINK S4500-16GP includes 8 PoE+ ports that support the IEEE 802.3at standard, delivering up to 30W per port. The total PoE budget is 120W, allowing you to power multiple devices such as IP phones, wireless access points, or security cameras simultaneously without overloading the switch.
Is this switch manageable, and what Layer does it operate at?
Yes, this is a smart managed switch operating at Layer 2. It provides management capabilities including VLAN support, QoS prioritization, port mirroring, IGMP snooping, and spanning tree protocol. These features give network administrators control over traffic flow, security, and performance optimization for efficient network operation.
Can this switch be wall-mounted, and what are its dimensions?
The switch is designed for both wall mounting and desktop placement. Its dimensions are 11.30 inches wide, 4.40 inches deep, and 1 inch high (287.02 mm x 111.76 mm x 25.40 mm). This compact size allows for flexible installation in space-constrained areas, with wall mounting helping to organize cables and reduce desk clutter.
What type of cabling does this switch support, and what is the maximum distance?
This switch supports twisted pair Ethernet cabling, compatible with standard Cat5e, Cat6, or higher cables. It uses 10/100/1000Base-T technology, allowing data transfer speeds up to 1 Gbps over distances up to 100 meters per connection, making it suitable for typical office or building network layouts.
Does the switch have a fan, and how does it handle cooling?
The S4500-16GP features a fanless design, meaning it operates silently without any moving parts for cooling. It relies on passive heat dissipation through its chassis, making it ideal for environments where noise reduction is important, such as offices, classrooms, or quiet workspaces, while maintaining reliable performance.
What networking standards does this switch comply with?
This switch complies with key IEEE networking standards including 802.3at and 802.3af for PoE, 802.1Q for VLAN tagging, 802.1x for network access control, 802.3x for flow control, 802.1p for QoS prioritization, and 802.1ab for LLDP. These standards ensure interoperability with other network devices and support advanced features for managed networking.
