TP-LINK TL-SG108-M2 8-Port 2.5 Gigabit Desktop Switch - Layer 2 - Metal Case - Wall Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The TL-SG108-M2 features eight auto-negotiating 2.5 Gigabit Ethernet ports that automatically detect and adjust to connected device speeds of 100 Mbps, 1 Gbps, or 2.5 Gbps. This ensures backward compatibility with existing network equipment while maximizing performance with newer 2.5G-capable devices.
It supports key networking standards including IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, and 802.3bz, providing reliable data transfer with flow control for reduced packet loss. The switch is non-manageable, operating as a plug-and-play solution that requires no configuration or software installation.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This switch delivers significant advantages for users upgrading their network infrastructure. The 2.5 Gigabit ports provide 2.5 times the bandwidth of standard Gigabit Ethernet, future-proofing your network for emerging applications and devices.
Cost-Effective Upgrade
Achieve 2.5 Gbps performance using existing Cat5e or Cat6 cabling, eliminating the need for expensive rewiring while maximizing your current infrastructure investment.
- Works with existing Cat5e/Cat6 cables
- No wiring upgrades required
- Reduces deployment costs
Quiet Operation
The fanless design ensures completely silent operation, making this switch ideal for noise-sensitive environments like home offices, living spaces, or recording studios.
- Zero noise emission
- No moving parts
- Ideal for quiet environments
Flexible Placement
With both desktop and wall-mounting capabilities, this switch can be installed in various locations to optimize space utilization and cable management.
- Desktop or wall placement
- Includes rubber feet
- Compact footprint
Deployment / Use Cases
The TL-SG108-M2 is particularly well-suited for environments where multiple high-bandwidth devices need to communicate simultaneously. Its 2.5 Gigabit ports provide the necessary throughput for modern networking demands.
Common deployment scenarios include connecting 2.5G WiFi 6 access points, network-attached storage devices, gaming computers, media servers, and workstations that require fast data transfer. The switch serves as an ideal backbone for home offices, small businesses, and creative studios handling large multimedia files.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Home Office Network
Connect multiple computers, NAS devices, and printers with sufficient bandwidth for simultaneous 4K video conferencing, file sharing, and backup operations.
Media & Gaming Setup
Support high-resolution video streaming, game downloads, and real-time gameplay with minimal latency, ensuring smooth performance across all connected devices.
Physical Profile
Measuring 8.90 inches wide, 5.20 inches deep, and 1.40 inches high, this compact switch fits easily on desks, shelves, or mounted on walls. The sturdy metal casing provides excellent heat dissipation and physical protection, while the included rubber feet prevent sliding on smooth surfaces. The wall-mount capability allows for clean cable management and space optimization in rack-constrained environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.40" (35.56 mm), 8.90" (226.06 mm), 5.20" (132.08 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 8.90" (226.06 mm)
- Depth
- 5.20" (132.08 mm)
- Height
- 1.40" (35.56 mm)
What's in the Box
The package includes all necessary components for immediate deployment of the switch in your network environment.
Highlights
- Eight 2.5 Gigabit Ethernet ports with 40 Gbps total switching capacity
- Auto-negotiation supports 100 Mbps, 1 Gbps, and 2.5 Gbps device speeds
- Works with existing Cat5e/Cat6 cabling - no wiring upgrades required
- Fanless metal design for silent, reliable operation
- Plug-and-play setup with no configuration needed
- Desktop or wall-mount placement options
- IEEE 802.3x flow control for reliable data transfer
- 3-year limited warranty with RoHS environmental compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | TL-SG108-M2 |
| Brand Name | TP-Link |
| Product Model | TL-SG108-M2 |
| Product Name | 8-Port 2.5G Desktop Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 x 2.5 Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Network Technology | 2.5GBase-T |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3x,IEEE 802.1p,IEEE 802.3bz |
| Management & Protocols | |
| Manageable | No |
| Power Description | |
| Power Source | Power Adapter |
| Power Consumption | 15.65 W |
| Physical Characteristics | |
| Product Material | Metal |
| Form Factor | Wall Mountable,Desktop |
| Height | 1.40" (35.56 mm) |
| Width | 8.90" (226.06 mm) |
| Depth | 5.20" (132.08 mm) |
| Miscellaneous | |
| Package Contents | 8-Port 2.5G Desktop Switch Power Adapter Installation Guide Rubber Feet |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
How many devices can I connect to this TP-Link switch?
The TL-SG108-M2 provides eight 2.5 Gigabit Ethernet ports, allowing you to connect up to eight network devices simultaneously. This includes computers, printers, NAS devices, access points, and other Ethernet-enabled equipment. All ports support auto-negotiation for compatibility with devices running at 100 Mbps, 1 Gbps, or 2.5 Gbps speeds.
What is the maximum data transfer speed of this switch?
Each port supports 2.5 Gigabit Ethernet (2.5GBase-T) with a maximum data rate of 2.5 Gbps per port. The switch has a total switching capacity of 40 Gbps, allowing all eight ports to operate at full speed simultaneously without congestion. This provides 2.5 times the bandwidth of standard Gigabit Ethernet switches.
Does this switch require special network cables?
No, the TL-SG108-M2 works with standard twisted pair Ethernet cables including Cat5e, Cat6, and Cat6a. You can achieve 2.5 Gbps performance using your existing Cat5e or Cat6 cabling infrastructure, eliminating the need for expensive rewiring. The switch automatically negotiates the optimal speed based on cable quality and connected device capabilities.
Is this a managed or unmanaged switch?
This is an unmanaged Layer 2 switch that operates as a plug-and-play device. It requires no configuration, software installation, or management interface. The switch automatically handles network traffic using standard Ethernet protocols, making it ideal for users who need simple, reliable connectivity without advanced networking features.
Can this switch be mounted on a wall?
Yes, the TL-SG108-M2 supports both desktop placement and wall mounting. The metal casing includes mounting points for secure wall installation, and the package includes rubber feet for stable desktop use. This flexibility allows you to optimize space utilization and cable management in various environments.
What warranty coverage does this switch include?
TP-Link provides a 3-year limited warranty for the TL-SG108-M2 switch. The product is also RoHS (Restriction of Hazardous Substances) compliant, meeting environmental standards for reduced hazardous materials. The fanless design with metal construction contributes to long-term reliability and durability in continuous operation.
