Transition Networks M/E-ISW-FX-01(MMLC) M/E-ISW-FX-01 - MMLC Fast Ethernet Media Converter - RJ45 to LC Fiber - 1. 2 Mile - Wall/Rail Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Technically, this media converter features one RJ-45 port for 10/100Base-TX Ethernet connectivity and one LC port for 100Base-FX fiber optic output. It operates on low-voltage DC power, which is common in industrial settings, and supports a wide temperature range for consistent performance in variable conditions.
The device is engineered for 100 Mbps data transfer rates, ensuring efficient network throughput for industrial automation, surveillance systems, or remote connectivity needs. Its environmentally friendly design and robust construction minimize downtime and maintenance requirements in challenging deployments.
Key Product Advantages
This media converter offers several key advantages for network expansion and reliability. Its ability to convert copper to fiber extends network reach beyond the limitations of UTP cabling, while the industrial design ensures durability in tough environments.
Extended Distance Support
Supports fiber optic connections up to 1.2 miles, ideal for long-distance network segments without signal degradation.
- Uses 62.5/125 µm multimode fiber
- 100Base-FX technology for reliable transmission
Flexible Mounting Options
Designed for wall or rail mounting, providing installation versatility in industrial racks, control panels, or outdoor enclosures.
- Compact dimensions for space-constrained areas
- Secure mounting for vibration-prone environments
Industrial Reliability
Built with wide temperature tolerance and low-voltage power, ensuring stable operation in harsh conditions with minimal maintenance.
- Lifetime warranty for long-term support
- Environmentally friendly construction
Deployment / Use Cases
This media converter is well-suited for deployments where extending Ethernet networks over fiber optic cabling is necessary. Common use cases include industrial automation systems, outdoor surveillance networks, and remote site connectivity where environmental factors or distance require robust signal transmission.
In industrial settings, it can connect PLCs, sensors, or HMIs across large facilities or between buildings. For outdoor applications, it provides reliable links for security cameras, access control systems, or wireless access points in parks, campuses, or transportation infrastructure. Its small size and mounting flexibility make it easy to integrate into existing network cabinets or control panels without significant space requirements.
Physical Profile
The converter measures 0.85 inches in height, 1.80 inches in width, and 3.30 inches in depth, making it one of the smaller media converters available for industrial use. This compact size allows for easy installation in tight spaces, such as electrical enclosures or network racks, without occupying excessive room.
Its wall-mountable and rail-mountable design provides multiple installation options, catering to different industrial standards and preferences. The sturdy build ensures it can withstand vibrations, temperature fluctuations, and other environmental stresses common in manufacturing plants, utility sites, or outdoor deployments.
- Width
- 1.80" (45.72 mm)
- Depth
- 3.30" (83.82 mm)
- Height
- 0.85" (21.59 mm)
Highlights
- Converts 10/100Base-TX Ethernet to 100Base-FX fiber optic signals
- Supports distances up to 1.2 miles with 62.5/125 µm multimode fiber
- Features one RJ-45 port and one LC fiber port for flexible connectivity
- Compact design with wall and rail mounting options for easy installation
- Industrial-grade construction with wide temperature range operation
- Low-voltage DC power compatible with industrial power systems
- 100 Mbps data transfer rate for efficient network performance
- Lifetime warranty for reliable long-term use in harsh environments
Specifications
| Specifications | |
|---|---|
| Manufacturer | Transition Networks, Inc |
| Manufacturer Part Number | M/E-ISW-FX-01(MMLC) |
| Brand Name | Transition Networks |
| Product Model | M/E-ISW-FX-01(MMLC) |
| Product Name | M/E-ISW-FX-01(MMLC) Fast Ethernet Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of LC Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Media & Performance | |
| Maximum Distance Supported | 1.2 Mile |
| Fiber Optic Cable Standard | 62.5/125 µm |
| Network & Communication | |
| Network Technology | 10/100Base-TX,100Base-FX |
| Physical Characteristics | |
| Form Factor | Wall Mountable,Rail-mountable |
| Height | 0.85" (21.59 mm) |
| Width | 1.80" (45.72 mm) |
| Depth | 3.30" (83.82 mm) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What does this media converter do?
This media converter converts 10/100Base-TX Ethernet signals from a copper RJ-45 connection to 100Base-FX fiber optic signals over an LC interface. It allows you to extend your network beyond the distance limitations of standard UTP cabling by using fiber optic cable, which is ideal for industrial or outdoor applications where longer runs or harsh conditions are present.
What type of fiber cable is compatible with this converter?
The converter is compatible with 62.5/125 µm multimode fiber optic cable. This is a common multimode fiber standard used in many industrial and enterprise networks for short to medium-distance connections. It supports a maximum distance of 1.2 miles when using this cable type, making it suitable for extending networks across facilities or between buildings.
How is this media converter powered?
It operates on low-voltage DC power, which is typical for industrial networking equipment. This power method provides reliability in environments with fluctuating power conditions and allows for integration with standard industrial power supplies or backup systems, ensuring continuous operation in critical applications.
What mounting options are available for installation?
The converter supports both wall mounting and rail mounting, offering flexibility for different installation scenarios. You can mount it directly on a wall surface or attach it to a DIN rail in an industrial rack or control panel. Its compact dimensions of 0.85" H x 1.80" W x 3.30" D make it easy to fit into tight spaces without compromising on functionality.
