Transition Networks S2220-1040-EU Media Converter - 1 x RJ-45 - 1 x SFP Slot - Fast/Gigabit Ethernet - Twisted Pair/Fiber - Standalone/Wall/DIN Rail
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The S2220-1040-EU supports media conversion between twisted pair copper cables and optical fiber, accommodating both 100Base-X and 10/100/1000Base-T network technologies. With a maximum data transfer rate of 1000 Mbit/s, it handles Gigabit Ethernet traffic while maintaining backward compatibility with Fast Ethernet networks.
The device supports transmission distances up to 0.10 km (0.06 miles) depending on the media type and SFP module used. Power is supplied through an external power adapter included in the package, ensuring reliable operation in various environments.
This section brings together practical product details such as Total Number of Ports, Network (RJ-45), USB, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This media converter delivers reliable network extension and media conversion with enterprise-grade features in a compact form factor. The combination of copper and fiber support with flexible mounting options makes it adaptable to diverse installation requirements.
Media Flexibility
Convert between twisted pair copper and optical fiber networks using the RJ-45 port and SFP slot, supporting various cable types and distances.
- Supports both copper and fiber media
- SFP slot for module flexibility
- 0.10 km maximum distance
Deployment Versatility
Multiple mounting options including standalone, wall mountable, DIN rail mountable, and shelf mount configurations provide installation flexibility for different environments.
- Four mounting options
- Compact 1" height
- Industrial-grade construction
Management & Compliance
USB management port enables easy configuration, while environmental certifications ensure compliance with industry standards and regulations.
- USB management interface
- REACH/RoHS/WEEE compliant
- TAA compliant for government use
Deployment / Use Cases
The S2220-1040-EU media converter is ideal for extending network segments between buildings, connecting fiber backbone networks to copper-based edge devices, or integrating legacy equipment with modern fiber infrastructure. Its compact size and multiple mounting options make it suitable for space-constrained environments like network closets, industrial control panels, or telecommunications cabinets.
Common applications include connecting fiber optic backbone networks to copper-based switches or routers in office environments, extending network connectivity in industrial settings where electromagnetic interference requires fiber optic media, and providing media conversion in educational or healthcare facilities where network infrastructure spans multiple buildings with different cabling types.
Physical Profile
Measuring 1" (25.40 mm) in height, 3.25" (82.55 mm) in width, and 6.50" (165.10 mm) in depth, the S2220-1040-EU features a compact design that conserves space in installation environments. The 2 lb (907.18 g) weight ensures stability when mounted while remaining lightweight enough for flexible deployment. The device's form factor supports four mounting configurations: standalone placement on flat surfaces, wall mounting for vertical installations, DIN rail mounting for industrial control panels, and shelf mounting for standard equipment racks.
- Width
- 3.25" (82.55 mm)
- Depth
- 6.50" (165.10 mm)
- Height
- 1" (25.40 mm)
- Weight
- 2 lb (907.18 g)
What's in the Box
The package includes all necessary components for immediate deployment of the media converter in European power environments.
Highlights
- Converts between twisted pair copper and optical fiber media
- Single RJ-45 port and SFP slot for flexible connectivity
- Supports Fast Ethernet and Gigabit Ethernet standards
- USB port for management and configuration
- Multiple mounting options: standalone, wall, DIN rail, shelf
- Maximum data transfer rate of 1000 Mbit/s
- Supports transmission distances up to 0.10 km
- Environmental compliance: REACH, RoHS, WEEE
- TAA compliant for government procurement
- Lifetime limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | S2220-1040-EU |
| Brand Name | Transition Networks |
| Product Line | ION |
| Product Series | S2220 |
| Product Model | S2220-1040 |
| Product Name | S2220-1040 Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Network (RJ-45) | Yes |
| USB | Yes |
| Management Port | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Maximum Data Transfer Rate | 1000 Mbit/s |
| Maximum Distance Supported | 0.10 km (0.06 Mile) |
| I/O Expansions | |
| Total Number of Expansion Slots | 1 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 1 |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet,Gigabit Ethernet |
| Network Technology | 100Base-X,10/100/1000Base-T |
| Power Description | |
| Power Source | Power Supply |
| Physical Characteristics | |
| Form Factor | Standalone,Wall Mountable,DIN Rail Mountable,Shelf Mount |
| Height | 1" (25.40 mm) |
| Width | 3.25" (82.55 mm) |
| Depth | 6.50" (165.10 mm) |
| Weight (Approximate) | 2 lb (907.18 g) |
| Miscellaneous | |
| Package Contents | S2220-1040 Transceiver/Media Converter Power Supply - Europe |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What types of media does this converter support?
The S2220-1040-EU supports both twisted pair copper cables and optical fiber media. It features one RJ-45 port for copper connectivity and one SFP slot that accepts various fiber optic modules, allowing conversion between different media types within your network infrastructure.
What Ethernet speeds does this media converter support?
This converter supports both Fast Ethernet (100 Mbps) and Gigabit Ethernet (1000 Mbps) standards. It is compatible with 100Base-X and 10/100/1000Base-T network technologies, providing flexibility for mixed-speed network environments and ensuring backward compatibility with existing infrastructure.
How is this device managed and configured?
The S2220-1040-EU includes a USB management port for configuration and monitoring. This allows network administrators to access the device's settings, monitor performance metrics, and make adjustments as needed without requiring dedicated management network infrastructure.
What mounting options are available for installation?
This media converter offers four mounting configurations: standalone placement on flat surfaces, wall mounting for vertical installations, DIN rail mounting for industrial control panels, and shelf mounting for standard equipment racks. The compact 1" height and multiple mounting points provide flexibility for various deployment scenarios.
What is the maximum transmission distance supported?
The converter supports transmission distances up to 0.10 km (0.06 miles). The actual achievable distance depends on the specific media type being used and the SFP module installed in the expansion slot, with fiber optic connections typically supporting longer distances than copper.
What compliance certifications does this product have?
The S2220-1040-EU is environmentally compliant with REACH, RoHS, and WEEE directives. It is also TAA compliant, making it suitable for government procurement. The device comes with a lifetime limited warranty and includes a European power supply in the package.
