Transition Networks S3231-1040-SA Gigabit Ethernet Media Converter - 1x RJ-45 - 2x SFP Slots - Wall/Shelf Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Technically, the S3231-1040-SA operates as a transparent bridge between 100/1000Base-X fiber optic networks and 10/100/1000Base-T copper Ethernet networks. It supports both optical fiber and twisted pair media types, with a maximum data transfer rate of 1000 Mbit/s across a distance of up to 0.10 km (0.06 mile). The device includes two SFP (Small Form-factor Pluggable) expansion slots for flexible fiber optic module selection, allowing network administrators to choose appropriate SFP transceivers based on fiber type, connector, and distance requirements.
The converter features one RJ-45 network port for copper connectivity, plus USB and management port interfaces for configuration and monitoring. Power is supplied via an external power adapter, and the unit supports comprehensive environmental compliance standards including REACH, RoHS, and WEEE directives.
Key Product Advantages
This media converter delivers several distinct advantages for network infrastructure deployment. Its ability to connect optical fiber and copper networks eliminates media compatibility barriers while extending network reach beyond copper distance limitations. The inclusion of two SFP slots provides exceptional flexibility, allowing organizations to use different SFP modules for various fiber types, distances, or connector requirements without changing the base unit.
Flexible Media Support
Simultaneously supports optical fiber and twisted pair connections, enabling seamless integration between different network media types within the same infrastructure.
- Connect fiber to copper networks
- Extend network distance beyond copper limits
- Maintain Gigabit performance across media types
Multiple Mounting Options
Designed for versatile installation with wall mounting, shelf mounting, or standalone placement capabilities to suit various deployment environments.
- Wall mount for space-efficient installation
- Shelf mount for rack or cabinet deployment
- Standalone for temporary or desktop use
Deployment / Use Cases
The S3231-1040-SA media converter is ideally suited for network expansion scenarios where extending copper Ethernet segments via fiber optic cable is necessary. Common deployment environments include connecting buildings across campuses, linking network equipment in industrial settings with electromagnetic interference concerns, or integrating fiber backbone connections with copper-based edge devices.
In data center applications, this converter can bridge between fiber backbone switches and copper-based servers or storage devices. For industrial automation and control systems, it provides reliable media conversion between fiber-optic plant networks and copper-based PLCs or HMIs. The wall-mountable design makes it particularly useful for space-constrained installations such as wiring closets, control panels, or remote equipment cabinets where organized cable management is essential.
Building-to-Building Connectivity
Extend network connections between separate buildings using fiber optic cable for distance and electrical isolation, while maintaining copper connectivity at each endpoint.
Industrial Network Integration
Bridge between fiber-optic plant networks and copper-based industrial control equipment in manufacturing, utilities, or transportation environments.
Physical Profile
The converter features a compact, industrial-grade enclosure measuring 1" (25.40 mm) in height, 3.25" (82.55 mm) in width, and 6.50" (165.10 mm) in depth, with an approximate weight of 2 lb (907.18 g). This slim profile allows for dense installations in rack cabinets, wall-mounted enclosures, or control panels. The unit includes multiple mounting options with provisions for wall mounting, shelf mounting, or standalone placement, providing installation flexibility for various deployment scenarios from data centers to industrial control rooms.
- Width
- 3.25" (82.55 mm)
- Depth
- 6.50" (165.10 mm)
- Height
- 1" (25.40 mm)
- Weight
- 2 lb (907.18 g)
What's in the Box
The package includes all necessary components for immediate deployment of the media converter in your network environment.
Highlights
- Converts between optical fiber and twisted pair media for flexible network integration
- Supports Gigabit Ethernet with 1000 Mbit/s maximum data transfer rate
- Features two SFP expansion slots for customizable fiber optic connectivity
- Includes one RJ-45 network port plus USB and management interfaces
- Wall, shelf, or standalone mounting options for versatile installation
- Extends network distance up to 0.10 km (0.06 mile)
- Compliant with REACH, RoHS, and WEEE environmental standards
- Backed by lifetime limited warranty for long-term reliability
- TAA compliant for government and public sector procurement
- Compact design measures 1"H × 3.25"W × 6.50"D (25.4 × 82.55 × 165.1 mm)
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | S3231-1040-SA |
| Brand Name | Transition Networks |
| Product Line | ION |
| Product Series | S3230 |
| Product Model | S3231-1040 |
| Product Name | S3231-1040 Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Network (RJ-45) | Yes |
| USB | Yes |
| Management Port | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Maximum Data Transfer Rate | 1000 Mbit/s |
| Maximum Distance Supported | 0.10 km (0.06 Mile) |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 100/1000Base-X,10/100/1000Base-T |
| Power Description | |
| Power Source | Power Supply |
| Physical Characteristics | |
| Form Factor | Wall Mountable,Standalone,Shelf Mount |
| Height | 1" (25.40 mm) |
| Width | 3.25" (82.55 mm) |
| Depth | 6.50" (165.10 mm) |
| Weight (Approximate) | 2 lb (907.18 g) |
| Miscellaneous | |
| Package Contents | S3231-1040 Transceiver/Media Converter Power Supply - South Africa |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What types of media does this converter support?
The S3231-1040-SA supports both optical fiber and twisted pair copper cabling. It can convert between 100/1000Base-X fiber optic networks and 10/100/1000Base-T copper Ethernet networks, allowing seamless integration of different media types within your network infrastructure.
How many SFP slots does this media converter have?
This converter includes two SFP (Small Form-factor Pluggable) expansion slots. These slots allow you to install compatible SFP transceiver modules based on your specific fiber type, connector requirements, and distance needs, providing flexible configuration options for various network scenarios.
What is the maximum distance supported by this converter?
The converter supports network connections up to 0.10 km (0.06 mile) in distance. This extended reach capability makes it suitable for connecting network segments across buildings, between floors, or in large facilities where copper cable distance limitations would otherwise require additional networking equipment.
What mounting options are available for this device?
The S3231-1040-SA offers three mounting options: wall mounting, shelf mounting, and standalone placement. The wall-mountable design is particularly useful for space-constrained installations like wiring closets or control panels, while shelf mounting accommodates rack or cabinet deployments, and standalone placement supports temporary or desktop applications.
What is included in the warranty for this product?
Transition Networks provides a lifetime limited warranty for the S3231-1040-SA media converter. This extensive warranty coverage demonstrates the product's reliability and the manufacturer's commitment to long-term performance in network infrastructure applications.
What power source does this converter require?
The converter is powered by an external power supply included in the package. The specific power supply provided is configured for South African electrical standards, ensuring proper operation in that region while maintaining the device's compact form factor and efficient power delivery for continuous network operation.
