Transition Networks SBFTF1010-130-SA Fast Ethernet Media Converter - 3-Port RJ-45 - 10/100Base-TX - 100 Mbit/s - Twisted Pair - 0. 10 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter operates on Fast Ethernet technology, specifically 10/100Base-TX, which provides backward compatibility with legacy network equipment while supporting modern twisted pair cables. It achieves a maximum distance of 0.10 km (approximately 100 meters) per port, ideal for extending network segments within buildings or across short outdoor runs. The three RJ-45 ports enable multi-point connections, allowing the device to serve as a small hub or converter in star or daisy-chain topologies.
Power efficiency is a key feature, with a low consumption of 2.40 W, reducing operational costs and heat output. The unit supports various mounting options, including standalone placement, rack-mounting, wall mounting, DIN rail mounting, and shelf mounting, offering installation flexibility in server rooms, control panels, or office spaces. Its compact dimensions—1" height, 3.25" width, and 4.80" depth—ensure it fits into tight spaces without compromising performance.
Key Product Advantages
The SBFTF1010-130-SA excels in providing reliable network extension with minimal complexity. Its fault-tolerant design ensures continuous operation, reducing downtime in critical applications. The versatile mounting capabilities allow deployment in almost any environment, from industrial racks to office walls, without requiring additional adapters or kits.
Compliance with TAA (Trade Agreements Act) standards makes this media converter suitable for government and public sector procurement, while its environmental certifications align with corporate sustainability goals. The lifetime warranty underscores the product's durability and the manufacturer's confidence in its long-term performance, offering exceptional value over its lifecycle.
Flexible Deployment
Supports five mounting options: standalone, rack, wall, DIN rail, and shelf, adapting to space constraints and installation preferences.
- Ideal for mixed environments
- No extra hardware needed for basic mounting
Cost-Effective Connectivity
Uses standard twisted pair cables, minimizing cabling costs while extending network reach up to 100 meters per port.
- Reduces infrastructure expenses
- Leverages existing cable investments
Deployment / Use Cases
This media converter is ideal for extending Ethernet networks in scenarios where fiber optic cabling is impractical or cost-prohibitive. Common applications include connecting remote workstations in office buildings, linking devices in manufacturing floors, or integrating network equipment in retail spaces. Its three ports enable it to act as a small converter hub, simplifying wiring in multi-device setups.
In industrial environments, the DIN rail and wall-mount options allow secure installation in control cabinets or along machinery lines. For IT closets or server rooms, the rack-mountable design integrates neatly with other networking gear. The South Africa-optimized power supply ensures reliable operation in regions with specific voltage requirements, making it a practical choice for local deployments.
Office Network Extension
Extend network connectivity to additional desks or conference rooms using existing twisted pair cabling, supporting up to three devices simultaneously.
Industrial Connectivity
Deploy in factory settings to connect PLCs, sensors, or HMIs over Ethernet, with rugged mounting options for harsh environments.
Physical Profile
The SBFTF1010-130-SA features a compact and lightweight design, measuring 1" (25.40 mm) in height, 3.25" (82.55 mm) in width, and 4.80" (121.92 mm) in depth. Weighing approximately 2 lb (907.18 g), it is easy to handle and install. The unit's small footprint allows placement on desks, shelves, or in enclosures without occupying significant space. Its sturdy construction supports multiple mounting orientations, ensuring stability in various installations.
- Width
- 3.25" (82.55 mm)
- Depth
- 4.80" (121.92 mm)
- Height
- 1" (25.40 mm)
- Weight
- 2 lb (907.18 g)
What's in the Box
The package includes all necessary components for immediate deployment.
Highlights
- Three RJ-45 ports for multi-device connectivity
- Supports 10/100Base-TX Fast Ethernet over twisted pair
- Maximum data transfer rate of 100 Mbit/s
- Extends network distance up to 0.10 km (100 meters)
- Versatile mounting: standalone, rack, wall, DIN rail, shelf
- Low power consumption at 2.40 W
- TAA compliant for government procurement
- Environmentally friendly with REACH, RoHS, WEEE compliance
- Includes South Africa-optimized power supply
- Lifetime warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | SBFTF1010-130-SA |
| Brand Name | Transition Networks |
| Product Model | SBFTF1010-130 |
| Product Name | SBFTF1010-130 Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 3 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 3 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Maximum Data Transfer Rate | 100 Mbit/s |
| Maximum Distance Supported | 0.10 km (0.06 Mile) |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Technology | 10/100Base-TX |
| Power Description | |
| Power Source | Power Supply |
| Power Consumption | 2.40 W |
| Physical Characteristics | |
| Form Factor | Standalone,Rack-mountable,Wall Mountable,DIN Rail Mountable,Shelf Mount |
| Height | 1" (25.40 mm) |
| Width | 3.25" (82.55 mm) |
| Depth | 4.80" (121.92 mm) |
| Weight (Approximate) | 2 lb (907.18 g) |
| Miscellaneous | |
| Package Contents | SBFTF1010-130 Transceiver/Media Converter Power Supply - South Africa |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum distance this media converter supports?
The SBFTF1010-130-SA supports a maximum distance of 0.10 km, which is approximately 100 meters or 0.06 miles. This range is typical for twisted pair Ethernet cabling, making it suitable for extending network segments within buildings or across short outdoor runs without signal degradation.
How many devices can I connect to this media converter?
This media converter features three RJ-45 ports, allowing you to connect up to three network devices directly. It can serve as a small hub for multiple connections in star topologies or act as a converter for daisy-chained setups, providing flexibility in network design.
What type of cables does this converter use?
The SBFTF1010-130-SA uses standard twisted pair cables, such as Cat5e or Cat6, which are cost-effective and widely available. It supports 10/100Base-TX Ethernet technology, ensuring compatibility with most existing network infrastructure without requiring specialized fiber optic cabling.
Can this media converter be mounted in a rack?
Yes, this media converter is rack-mountable, along with other options including standalone, wall mountable, DIN rail mountable, and shelf mount. This versatility allows installation in server racks, control panels, or on flat surfaces, adapting to various deployment environments.
What power supply is included with this product?
The package includes a power supply optimized for South African voltage standards, ensuring reliable operation in that region. The converter has a low power consumption of 2.40 W, which reduces energy costs and heat output in continuous use scenarios.
Is this media converter compliant with environmental regulations?
Yes, the SBFTF1010-130-SA is environmentally friendly and complies with REACH, RoHS, and WEEE directives. It is also TAA compliant, making it suitable for government and public sector procurement where these standards are required for sustainability and trade agreements.
