Transition Networks SM24TAT4XB-OZ Layer 3 Switch - 24 Port Gigabit PoE+ - 4x SFP+ 10GbE Uplinks - Managed
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Built on a 10 Gigabit Ethernet backbone, the SM24TAT4XB-OZ provides 24 Gigabit RJ-45 ports with PoE+ support, each capable of delivering up to 25.5W per port. Four dedicated SFP+ slots offer 10GbE uplink connectivity for high-speed aggregation to core switches or servers.
Layer 3 routing functionality enables inter-VLAN routing, policy-based routing, and dynamic routing protocols for scalable network designs. The switch supports a comprehensive suite of networking standards including IEEE 802.3at/af for PoE, IEEE 802.1Q for VLANs, IEEE 802.3ad for link aggregation, and IEEE 802.1x for network access control.
This section brings together practical product details such as Total Number of Network Ports, Network (RJ-45), Modular, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
This switch delivers enterprise-grade features in a compact 1U form factor, making it ideal for space-constrained deployments. The combination of high PoE budget and 10GbE uplinks provides exceptional flexibility for growing networks.
High-Density PoE+
With 24 PoE+ ports and 370W total budget, this switch can power multiple PoE devices simultaneously while maintaining data connectivity.
- IEEE 802.3at compliant
- 25.5W per port maximum
- Auto-sensing for PoE detection
10GbE Ready
Four SFP+ ports provide 10 Gigabit Ethernet connectivity for high-bandwidth applications and future network expansion.
- Supports 10GBase-SR/LR optics
- Backward compatible with 1GbE SFPs
- Hot-swappable modules
Advanced Management
Complete management capabilities including CLI, web interface, and SNMP support for comprehensive network monitoring and configuration.
- Quality of Service (QoS)
- Port security features
- Traffic monitoring and statistics
Deployment / Use Cases
The SM24TAT4XB-OZ excels in medium to large business environments where reliable switching, PoE power delivery, and network segmentation are required. Its Layer 3 capabilities make it suitable for distribution layer deployments in hierarchical network designs.
Ideal for office networks supporting VoIP systems, wireless deployments, and security camera installations. The 10GbE uplinks provide sufficient bandwidth for connecting to storage systems, virtualization hosts, or core network infrastructure.
This section brings together practical product details such as Total Number of Network Ports, Network (RJ-45), Modular, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Office Network Core
Serve as the main switching platform for office floors, providing connectivity to workstations, printers, and wireless access points with PoE power delivery.
IP Surveillance Backbone
Power and connect multiple IP cameras while providing high-bandwidth uplinks to network video recorders and monitoring stations.
Physical Profile
The switch features a standard 1U rack-mountable design with dimensions of 1.73" (44mm) height, 17.40" (442mm) width, and 8.31" (211mm) depth. Front-panel LED indicators provide at-a-glance status monitoring for power, system, and port activity.
Dual redundant power supplies with auto-failover capability ensure continuous operation. The unit operates on 100-240V AC power with universal input compatibility for global deployment.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.73" (43.94 mm), 17.40" (441.96 mm), 8.31" (211.07 mm), 8.38 lb (3801.10 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.40" (441.96 mm)
- Depth
- 8.31" (211.07 mm)
- Height
- 1.73" (43.94 mm)
- Weight
- 8.38 lb (3801.10 g)
What's in the Box
The package includes everything needed for immediate deployment and operation.
Highlights
- 24 Gigabit Ethernet ports with PoE+ support for connected devices
- 370W total PoE budget powers multiple IP phones, cameras, and access points
- Four SFP+ slots provide 10GbE uplink connectivity for high-speed aggregation
- Layer 3 routing capabilities for scalable network designs
- Managed switch with comprehensive monitoring and configuration options
- 1U rack-mountable design for standard 19" rack installations
- Lifetime warranty for long-term deployment confidence
- Environmental compliance with RoHS, REACH, and WEEE directives
Specifications
| Specifications | |
|---|---|
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | SM24TAT4XB-OZ |
| Brand Name | Transition Networks |
| Product Series | SM24TAT4XB |
| Product Name | SM24TAT4XB Layer 3 Switch |
| Product Type | Layer 3 Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Stack Port | No |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network PoE+,4 x 10 Gigabit Ethernet |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP+ |
| Shared SFP Slot | No |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3at,IEEE 802.1ab,IEEE 802.3af,IEEE 802.1Q,IEEE 802.1w,IEEE 802.1D,IEEE 802.3u,IEEE 802.3az,IEEE 802.1s,IEEE 802.3x,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3,IEEE 802.1ad,IEEE 802.3z,IEEE 802.1p |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 370 W |
| Input Voltage | 230 V AC,120 V AC |
| Power Source | PoE+,AC |
| Power Consumption | 450 W |
| Physical Characteristics | |
| Height | 1.73" (43.94 mm) |
| Width | 17.40" (441.96 mm) |
| Depth | 8.31" (211.07 mm) |
| Weight (Approximate) | 8.38 lb (3801.10 g) |
| Miscellaneous | |
| Package Contents | SM24TAT4XB Layer 3 Switch Power Cord Australia |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the total PoE budget of this switch?
The Transition Networks SM24TAT4XB-OZ provides a 370W total PoE budget. This allows the switch to power multiple PoE+ devices simultaneously, with each of the 24 ports capable of delivering up to 25.5W. The budget is managed dynamically across all ports to optimize power allocation based on connected device requirements.
How many 10GbE uplink ports does this switch have?
This switch includes four SFP+ slots that support 10 Gigabit Ethernet uplinks. These ports accept standard SFP+ transceivers for either copper or fiber connectivity, providing high-speed connections to core switches, servers, or storage systems. The uplinks operate independently from the 24 Gigabit Ethernet ports.
What Layer 3 routing features are supported?
The switch supports full Layer 3 routing capabilities including static routing, RIP v1/v2, OSPF, and policy-based routing. It enables inter-VLAN routing without requiring an external router, supports Access Control Lists (ACLs) for traffic filtering, and provides Quality of Service (QoS) for prioritizing critical network traffic.
What management interfaces are available?
Multiple management interfaces are supported including web-based GUI, command line interface (CLI) via console port or Telnet/SSH, and SNMP v1/v2c/v3. The switch also supports RMON for network monitoring, syslog for event logging, and port mirroring for traffic analysis without disrupting network operations.
What are the physical dimensions for rack mounting?
The switch measures 1.73 inches (44mm) in height, 17.40 inches (442mm) in width, and 8.31 inches (211mm) in depth, making it a standard 1U rack-mountable device. It includes mounting ears for installation in 19-inch equipment racks and weighs approximately 8.38 pounds (3.8kg) for easy handling during deployment.
What type of warranty comes with this switch?
Transition Networks provides a lifetime warranty for this switch, covering defects in materials and workmanship for the product's operational life. The warranty includes advance replacement service and technical support. The switch also complies with environmental standards including RoHS, REACH, and WEEE directives.
What uplink, SFP, fiber, or media support detail is listed?
The warranty or support detail listed is Optical Fiber,Twisted Pair, giving buyers a clearer picture of expected coverage after purchase.
Does the product support PoE or wireless networking?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
